Heavy Industrial Panel PC
Modular Panel PC
* 15”~24" Panel PC with 8th Generation LGA 1151 Intel® Core™ i7/i5/i3
and Pentium® processor
* Four hot-swappable and accessible HDD drive bays, support RAID
0/1/5/10
* Two PCIe 3.0 by 4 and two PCIe 3.0 by 8 slots
* Dual M.2 2280 PCIe Gen 3.0 x4 NVMe™ SSD support
CPU / Chipset Display Expansion I/O Features
PPC-F15C-Q370
Compare products

8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ... 8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370 		LCD Size: 15”
Brightness(cd/m2): 450
Max Resolution: 1024x768 LCD Size: 15”
Brightness(cd/m2): 450
Max Resolution: 1024x768 		2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ... 2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm) 		6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ... 6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
PPC-F17C-Q370
Compare products

8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ... 8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370 		LCD Size: 17”
Brightness(cd/m2): 350
Max Resolution: 1280x1024 LCD Size: 17”
Brightness(cd/m2): 350
Max Resolution: 1280x1024 		2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ... 2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm) 		6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ... 6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
PPC-FW15C-Q370
Compare products

8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ... 8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370 		LCD Size: 15.6”
Brightness(cd/m2): 400
Max Resolution: 1366x768 LCD Size: 15.6”
Brightness(cd/m2): 400
Max Resolution: 1366x768 		2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ... 2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm) 		6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ... 6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
PPC-FW19C-Q370
Compare products

8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ... 8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370 		LCD Size: 18.5”
Brightness(cd/m2): 400
Max Resolution: 1366x768 LCD Size: 18.5”
Brightness(cd/m2): 400
Max Resolution: 1366x768 		2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ... 2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm) 		6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ... 6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
PPC-FW22C-Q370
Compare products

8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ... 8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370 		LCD Size: 21.5”
Brightness(cd/m2): 250
Max Resolution: 1920x1080 LCD Size: 21.5”
Brightness(cd/m2): 250
Max Resolution: 1920x1080 		2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ... 2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm) 		6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ... 6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
PPC-FW24C-Q370
Compare products

8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ... 8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370 		LCD Size: 23.8”
Brightness(cd/m2): 250
Max Resolution: 1920x1080 LCD Size: 23.8”
Brightness(cd/m2): 250
Max Resolution: 1920x1080 		2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ... 2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm) 		6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ... 6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
Rugged Panel PC
Including UPC series panel PCs amd INOX.
*Fanless Design
*Sturdy & Durable
*High Waterproof Grade
CPU / Chipset Display Expansion I/O Features
INOX-F15C-ULT3
Compare products

6th generation Intel® Core™ i5 and Celeron® ULT processor,Intel® Skylake UL ... 6th generation Intel® Core™ i5 and Celeron® ULT processor,Intel® Skylake ULT 15” LCD
Brightness (cd/m²): 450
Max Resolution: 1024 x 768 15” LCD
Brightness (cd/m²): 450
Max Resolution: 1024 x 768 		1 x Full-size PCIe Mini card slot (SATA 6Gb/s)1 x Full-size/half-size (PCIe ... 1 x Full-size PCIe Mini card slot (SATA 6Gb/s)
1 x Full-size/half-size (PCIe x1 and USB 2.0 signals)
1 x M.2 B-key slot (2242/2260/2280 with USB 3.0, PCIe x2 and SATA signals) 		2 x 8-pin M12 connector for RS-232/422/4852 x 8-pin M12 X-Code connector fo ... 2 x 8-pin M12 connector for RS-232/422/485
2 x 8-pin M12 X-Code connector for GbE LAN
2 x 8-pin M12 connector for two USB 2.0
1 x 5-pin M12 connector for DC jack (9-36V DC)
1 x Power switch with power LED indicator
1 x Pressure relief valve
UPC-F12C-ULT3
Compare products

6th generation Intel® Core™ i5 and Celeron® ULT processor, SOC 6th generation Intel® Core™ i5 and Celeron® ULT processor, SOC 12.1”, 600nits, 1024x768 12.1”, 600nits, 1024x768 1 x M.2 (B key 2242 with USB 2.0 and SATA signal) 1 x M.2 (B key 2242 with USB 2.0 and SATA signal) M12 Type:1 x 8-pin M12 connector for RS-2321 x 8-pin M12 connector for RS-2 ... M12 Type:
1 x 8-pin M12 connector for RS-232
1 x 8-pin M12 connector for RS-232/422/485
1 x 8-pin M12 connector for GbE LAN
2 x 8-pin M12 connector for two USB 2.0
1 x 5-pin M12 connector for DC jack (12V~36V DC)

Standard Type:
1 x DC jack (12V-36V DC)
1 x DC-in terminal block
(12V-36V DC)
1 x HDMI
1 x VGA
1 x RS-232 (COM1 RJ-45)
1 x RS-232/422/485 (COM2 RJ-45)
2 x LAN
2 x USB 2.0
2 x USB 3.0
Fanless Panel PC
IEI is dedicated to developing impeccable industrial panel PC products.The PPC and PPC-F series industrial panel PCs not only keep rugged design of IP65 protection but also enrich aesthetic experience by implementing the seamless mounting method. The projected capacitive touch option is added to these new series of products to provide up to 2 points multi-touch solution! Additionally, we also provide high performance H81 series and low power consumption Bay Trail series to meet customers’requests.
CPU / Chipset Display Expansion I/O Features
PPC-3708A-N26
Compare products

Intel® Atom™ N2600 dual-core processor 1.6GHz
Intel® NM10 Intel® Atom™ N2600 dual-core processor 1.6GHz
Intel® NM10 		LCD Size:8.4""
Brightness(cd/m2):450
Max Resolution:800(W) x 600(H) LCD Size:8.4""
Brightness(cd/m2):450
Max Resolution:800(W) x 600(H) 		Expansion Slots:1 x PCIe Mini card Expansion Slots:1 x PCIe Mini card 1 x Power In (12V DC jack) 1 x HDMI 2 x LAN (RJ-45) 1 x Line in 1 x Line ou ... 1 x Power In (12V DC jack)
1 x HDMI
2 x LAN (RJ-45)
1 x Line in
1 x Line out
1 x Mic
1 x Power Switch
2 x RS-232
1 x RS-422/485
2 x USB2.0
2 x USB3.0
1 x VGA
PPC-3712A-N26
Compare products

Intel® Atom™ N2600 dual-core processor 1.6GHz
Intel® NM10 Intel® Atom™ N2600 dual-core processor 1.6GHz
Intel® NM10 		LCD Size:12.1""
Brightness(cd/m2):500
Max Resolution:1024(W) x 768(H) LCD Size:12.1""
Brightness(cd/m2):500
Max Resolution:1024(W) x 768(H) 		Expansion Slots:1 x PCIe Mini card Expansion Slots:1 x PCIe Mini card 1 x Power In (9-28V DC Jack) 1 x HDMI 2 x LAN (RJ-45) 1 x Line in 1 x Line ... 1 x Power In (9-28V DC Jack)
1 x HDMI
2 x LAN (RJ-45)
1 x Line in
1 x Line out
1 x Mic
1 x Power Switch
2 x RS-232
1 x RS-422/485
2 x USB2.0
2 x USB3.0
1 x VGA
PPC-3712A-N270
Compare products

Intel® Atom™ N270 1.6GHz CPU
Intel® 945GSE + ICH7M Intel® Atom™ N270 1.6GHz CPU
Intel® 945GSE + ICH7M 		LCD Size:12.1""
Brightness(cd/m2):500
Max Resolution:1024(W) x 768(H) LCD Size:12.1""
Brightness(cd/m2):500
Max Resolution:1024(W) x 768(H) 		Expansion Slots:1 x PCIe Mini card Expansion Slots:1 x PCIe Mini card 1 x Power In (12V DC jack) 2 x LAN (RJ-45) 1 x Line in 1 x Line out 1 x Mic ... 1 x Power In (12V DC jack)
2 x LAN (RJ-45)
1 x Line in
1 x Line out
1 x Mic
1 x PS/2
1 x Power Switch
2 x RS-232
1 x RS-422/485
2 x USB2.0
1 x VGA
PPC-F06B-BT
Compare products

IntelR CeleronR N2807
dual-core processor, 1.58GHz IntelR CeleronR N2807
dual-core processor, 1.58GHz 		LCD Size:5.7”(4:3)
Brightness(cd/m2):550
Max Resolution:640(W) x 480(H) LCD Size:5.7”(4:3)
Brightness(cd/m2):550
Max Resolution:640(W) x 480(H) 		Expansion Slots:1 x Full-size PCIe Mini slot
(with mSATA, PCIe/USB signal) Expansion Slots:1 x Full-size PCIe Mini slot
(with mSATA, PCIe/USB signal) 		1 x LAN ((RJ-45)) 1 x Power Switch 1 x RS-232 (((DB-9))) 1 x RS-422/485 1 x ... 1 x LAN ((RJ-45))
1 x Power Switch
1 x RS-232 (((DB-9)))
1 x RS-422/485
1 x Reset Button
2 x USB2.0
2 x USB3.0
1 x AT/ATX Switch
1 x Audio (((line-out)))
1 x Power In ((9-30V Lockable power jack))
PPC-F08B-BT
Compare products

IntelR CeleronR J1900 quad-core on-board SoC, 2GHz IntelR CeleronR J1900 quad-core on-board SoC, 2GHz LCD Size:8”(4:3)
Brightness(cd/m2):500
Max Resolution:800(W) x 600(H) LCD Size:8”(4:3)
Brightness(cd/m2):500
Max Resolution:800(W) x 600(H) 		Expansion Slots:1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)1 ... Expansion Slots:1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)
1 x Half-size PCIe Mini slot for Wi-Fi modules 		2 x LAN ((GbE)) 1 x Power Switch 1 x RS-232 ((RJ-45)) 1 x RS-422/485 ((DB-9 ... 2 x LAN ((GbE))
1 x Power Switch
1 x RS-232 ((RJ-45))
1 x RS-422/485 ((DB-9))
1 x Reset Button
2 x USB2.0
2 x USB3.0
1 x AT/ATX Switch
1 x Audio (((line-out)))
1 x Power In ((9-30V Lockable power jack))
PPC-F10B-BT
Compare products

IntelR CeleronR J1900 quad-core on-board SoC, 2GHz IntelR CeleronR J1900 quad-core on-board SoC, 2GHz LCD Size:10.4”
Brightness(cd/m2):400
Max Resolution:800(W) x 600(H) LCD Size:10.4”
Brightness(cd/m2):400
Max Resolution:800(W) x 600(H) 		Expansion Slots:1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)1 ... Expansion Slots:1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)
1 x Half-size PCIe Mini slot for Wi-Fi modules 		2 x LAN ((GbE)) 1 x Power Switch 1 x RS-232 ((RJ-45)) 1 x RS-422/485 ((DB-9 ... 2 x LAN ((GbE))
1 x Power Switch
1 x RS-232 ((RJ-45))
1 x RS-422/485 ((DB-9))
1 x Reset Button
2 x USB2.0
2 x USB3.0
1 x AT/ATX Switch
1 x Audio (((line-out)))
1 x Power In ((9-30V Lockable power jack))
PPC-F12B-BT
Compare products

Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) LCD Size:12.1""""(4:3) Brightness(cd/m2):600 Max Resolution:1024 (W) x 768 ... LCD Size:12.1""""(4:3)
Brightness(cd/m2):600
Max Resolution:1024 (W) x 768 (H) 		1 x Full-size PCIe Mini card slot (with PCIe and USB signal)1 x Full-size P ... 1 x Full-size PCIe Mini card slot (with PCIe and USB signal)
1 x Full-size PCIe Mini card slot co-lay mSATA (SATA2 only) (with PCIe and USB signal) 		2 x RJ-45 LAN port2 x USB 3.02 x USB 2.01 x HDMI2 x RS-2321 x RS-232/422/48 ... 2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out (PPC-F15B and PPC-17B only)
1 x Power switch
PPC-F15B-BT
Compare products

Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) LCD Size:15""""(4:3) Brightness(cd/m2):400 Max Resolution:1024 (W) x 768 (H ... LCD Size:15""""(4:3)
Brightness(cd/m2):400
Max Resolution:1024 (W) x 768 (H) 		1 x Full-size PCIe Mini card slot (with PCIe and USB signal)1 x Full-size P ... 1 x Full-size PCIe Mini card slot (with PCIe and USB signal)
1 x Full-size PCIe Mini card slot co-lay mSATA (SATA2 only) (with PCIe and USB signal) 		2 x RJ-45 LAN port2 x USB 3.02 x USB 2.01 x HDMI2 x RS-2321 x RS-232/422/48 ... 2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out (PPC-F15B and PPC-17B only)
1 x Power switch
PPC-F17B-BT
Compare products

Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) LCD Size:17""""(5:4) Brightness(cd/m2):350 Max Resolution:1280 (W) x 1024 ( ... LCD Size:17""""(5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H) 		1 x Full-size PCIe Mini card slot (with PCIe and USB signal)1 x Full-size P ... 1 x Full-size PCIe Mini card slot (with PCIe and USB signal)
1 x Full-size PCIe Mini card slot co-lay mSATA (SATA2 only) (with PCIe and USB signal) 		2 x RJ-45 LAN port2 x USB 3.02 x USB 2.01 x HDMI2 x RS-2321 x RS-232/422/48 ... 2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out (PPC-F15B and PPC-17B only)
1 x Power switch
PPC-F19B-BT
Compare products

Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) LCD Size:19” (5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H) LCD Size:19” (5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H) 		1 x Full-size PCIe Mini slot ( mSATA/PCIe/USB signal)1 x Full-size/half-siz ... 1 x Full-size PCIe Mini slot ( mSATA/PCIe/USB signal)
1 x Full-size/half-size PCIe Mini slot (PCIe/USB signal) 		2 x RJ-45 LAN port2 x USB 3.02 x USB 2.01 x HDMI2 x RS-2321 x RS-232/422/48 ... 2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out
1 x Power switch
UPC-V312-D525
Compare products

Intel® Atom™ D525 1.8GHz dual-core processor
Intel® ICH8M Intel® Atom™ D525 1.8GHz dual-core processor
Intel® ICH8M 		LCD Size:12.1""
Brightness(cd/m2):600
Max Resolution:1024(W) x 768(H) LCD Size:12.1""
Brightness(cd/m2):600
Max Resolution:1024(W) x 768(H) 		Expansion Slots:PCIe Mini slot for Wi-Fi module
PCIe Mini slot Expansion Slots:PCIe Mini slot for Wi-Fi module
PCIe Mini slot 		1 x AT/ATX Switch 1 x CAN-bus ((3-pin terminal block)) 1 x LAN (RJ-45 for G ... 1 x AT/ATX Switch
1 x CAN-bus ((3-pin terminal block))
1 x LAN (RJ-45 for Gbe)
1 x Line out
1 x Mic
2 x Power In (DC jack/terminal block)
1 x RS-232 ((DB-9))
1 x RS-422/485 ((4-pin box header))
1 x Reset Button
4 x USB2.0
VGA ((DB-15))
UPC-V315-QM77
Compare products

IntelR CeleronR 1047UE processor
Mobile IntelR QM77 Express Chipset IntelR CeleronR 1047UE processor
Mobile IntelR QM77 Express Chipset 		LCD Size:15""
Brightness(cd/m2):400
Max Resolution:1024(W) x 768(H) LCD Size:15""
Brightness(cd/m2):400
Max Resolution:1024(W) x 768(H) 		Expansion Slots:1 x PCIe Mini card Expansion Slots:1 x PCIe Mini card 1 x AT/ATX Switch 1 x CAN-bus 1 x HDMI 2 x LAN (GbE LAN) 1 x Line out 1 x M ... 1 x AT/ATX Switch
1 x CAN-bus
1 x HDMI
2 x LAN (GbE LAN)
1 x Line out
1 x Mic
2 x Power In (9-36V DC jack/9-36V terminal block)
3 x RS-232 ((RJ-45))
1 x RS-422/485 ((RJ-45))
1 x Reset Button
2 x USB3.0
2 x USB2.0
1 x Video
Panel PC with Active Fan
15”~24" Panel PC with active fan
CPU / Chipset Display Expansion I/O Features
PPC-5150A-H61
Compare products

2nd/3rd generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processor ... 2nd/3rd generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processor, up to TDP 65W CPU
Intel® H61 		LCD Size:15""
Brightness(cd/m2):400
Max Resolution:1024(W) x 768(H) LCD Size:15""
Brightness(cd/m2):400
Max Resolution:1024(W) x 768(H) 		Expansion Slots:Either 1 x PCI slot or 1 x PCIe slot,
1 x PCIe Mini card Expansion Slots:Either 1 x PCI slot or 1 x PCIe slot,
1 x PCIe Mini card 		1 x AT/ATX Switch 4 x LAN ((RJ-45) x 2/SFP fiber LAN x 2) 1 x Line out 1 x ... 1 x AT/ATX Switch
4 x LAN ((RJ-45) x 2/SFP fiber LAN x 2)
1 x Line out
1 x Mic
1 x Power In
4 x RS-232
1 x RS-422/485
4 x USB2.0
2 x USB3.0
1 x VGA
PPC-5170A-H61
Compare products

2nd/3rd generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processor ... 2nd/3rd generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processor, up to TDP 65W CPU
Intel® H61 		LCD Size:17""
Brightness(cd/m2):1280(W) x 1024(H)
Max Resolution:350 LCD Size:17""
Brightness(cd/m2):1280(W) x 1024(H)
Max Resolution:350 		Expansion Slots:Either 1 x PCI slot or 1 x PCIe slot
1 x PCIe Mini card Expansion Slots:Either 1 x PCI slot or 1 x PCIe slot
1 x PCIe Mini card 		1 x AT/ATX Switch 4 x LAN ((RJ-45) x2 /SFP fiber LAN x 2) 1 x Line out 1 x ... 1 x AT/ATX Switch
4 x LAN ((RJ-45) x2 /SFP fiber LAN x 2)
1 x Line out
1 x Mic
1 x Power Switch
4 x RS-232
1 x RS-422/485
4 x USB2.0
2 x USB3.0
1 x VGA
PPC-5190A-H61
Compare products

2nd/3rd generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processor ... 2nd/3rd generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processor, up to TDP 65W
Intel® H61 		LCD Size:19""
Brightness(cd/m2):350
Max Resolution:1280(W) x 1024(H) LCD Size:19""
Brightness(cd/m2):350
Max Resolution:1280(W) x 1024(H) 		Expansion Slots:Either 1 x PCI slot or 1 x PCIe slot
1 x PCIe Mini card Expansion Slots:Either 1 x PCI slot or 1 x PCIe slot
1 x PCIe Mini card 		1 x AT/ATX Switch 4 x LAN ((RJ-45) x 2/SFP fiber LAN x 2) 1 x Line in 1 x L ... 1 x AT/ATX Switch
4 x LAN ((RJ-45) x 2/SFP fiber LAN x 2)
1 x Line in
1 x Line out
1 x Power Switch
4 x RS-232
1 x RS-422/485
4 x USB2.0
2 x USB3.0
1 x VGA
PPC-F15A-H81
Compare products

LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processo ... LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP LCD Size:15”(4:3)
Brightness(cd/m2):400
Max Resolution:1024 (W) x 768 (H) LCD Size:15”(4:3)
Brightness(cd/m2):400
Max Resolution:1024 (W) x 768 (H) 		1 x Full-size PCIe Mini card1 x Full-size PCIe Mini card co-lay mSATA (SATA ... 1 x Full-size PCIe Mini card
1 x Full-size PCIe Mini card co-lay mSATA (SATA2 only) 		2 x RJ-45 LAN Port2 x USB 3.04 x USB 2.01 x HDMI output4 x RS-2321 x RS-422 ... 2 x RJ-45 LAN Port
2 x USB 3.0
4 x USB 2.0
1 x HDMI output
4 x RS-232
1 x RS-422/485
1 x MIC-in
1 x Line-out
1 x VGA output
1 x AC/DC power plug
(DC model is by build to order manufacturing)
1 x AT/ATX switch
1 x Clear CMOS
1 x Reset button
1 x Power switch
PPC-F17A-H81
Compare products

LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processo ... LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP LCD Size:17”(5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H) LCD Size:17”(5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H) 		1 x Full-size PCIe Mini card1 x Full-size PCIe Mini card co-lay mSATA (SATA ... 1 x Full-size PCIe Mini card
1 x Full-size PCIe Mini card co-lay mSATA (SATA2 only) 		2 x RJ-45 LAN Port2 x USB 3.04 x USB 2.01 x HDMI output4 x RS-2321 x RS-422 ... 2 x RJ-45 LAN Port
2 x USB 3.0
4 x USB 2.0
1 x HDMI output
4 x RS-232
1 x RS-422/485
1 x MIC-in
1 x Line-out
1 x VGA output
1 x AC/DC power plug
(DC model is by build to order manufacturing)
1 x AT/ATX switch
1 x Clear CMOS
1 x Reset button
1 x Power switch
PPC-F22A-H81
Compare products

LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processo ... LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP LCD Size:21.5”(16:9) Brightness(cd/m2):250 Max Resolution:1920 (W) x 1080 ( ... LCD Size:21.5”(16:9)
Brightness(cd/m2):250
Max Resolution:1920 (W) x 1080 (H) 		1 x Full-size PCIe Mini card1 x Full-size PCIe Mini card co-lay mSATA (SATA ... 1 x Full-size PCIe Mini card
1 x Full-size PCIe Mini card co-lay mSATA (SATA2 only) 		2 x RJ-45 LAN Port2 x USB 3.04 x USB 2.01 x HDMI output4 x RS-2321 x RS-422 ... 2 x RJ-45 LAN Port
2 x USB 3.0
4 x USB 2.0
1 x HDMI output
4 x RS-232
1 x RS-422/485
1 x MIC-in
1 x Line-out
1 x VGA output
1 x AC/DC power plug
(DC model is by build to order manufacturing)
1 x AT/ATX switch
1 x Clear CMOS
1 x Reset button
1 x Power switch
PPC-F24A-H81
Compare products

LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processo ... LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP LCD Size:24”(16:9)
Brightness(cd/m2):250
Max Resolution:1920 (W) x 1080 (H) LCD Size:24”(16:9)
Brightness(cd/m2):250
Max Resolution:1920 (W) x 1080 (H) 		1 x Full-size PCIe Mini card1 x Full-size PCIe Mini card co-lay mSATA (SATA ... 1 x Full-size PCIe Mini card
1 x Full-size PCIe Mini card co-lay mSATA (SATA2 only) 		2 x RJ-45 LAN Port2 x USB 3.04 x USB 2.01 x HDMI output4 x RS-2321 x RS-422 ... 2 x RJ-45 LAN Port
2 x USB 3.0
4 x USB 2.0
1 x HDMI output
4 x RS-232
1 x RS-422/485
1 x MIC-in
1 x Line-out
1 x VGA output
1 x AC/DC power plug
(DC model is by build to order manufacturing)
1 x AT/ATX switch
1 x Clear CMOS
1 x Reset button
1 x Power switch
Light Industrial Panel PC
Fanless Panel PC
AFOLUX Series Panel PCs
CPU / Chipset Display Expansion I/O Features
AFL-07A-LX
Compare products

AMD Geode™ LX 800 (500Mhz)
AMD LX800 + AMD CS5536 AMD Geode™ LX 800 (500Mhz)
AMD LX800 + AMD CS5536 		1 x Audio ((line-out)) 1 x DC Input Jack LAN (RJ-45 for 10/100Mbps LAN) 1 x ... 1 x Audio ((line-out))
1 x DC Input Jack
LAN (RJ-45 for 10/100Mbps LAN)
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
2 x USB 2.0 		Size:Wide 7""
Resolution:800 x 480
Brightness (cd/m2):500 Size:Wide 7""
Resolution:800 x 480
Brightness (cd/m2):500
AFL-07A-N270
Compare products

Intel® Atom™ Processor
N270 1.6GHz CPU
Intel® 945GSE +
ICH7M Intel® Atom™ Processor
N270 1.6GHz CPU
Intel® 945GSE +
ICH7M 		1 x Audio ((line-out)) 1 x DC Input Jack 1 x Extemal SATA 1 x LAN (RJ-45 fo ... 1 x Audio ((line-out))
1 x DC Input Jack
1 x Extemal SATA
1 x LAN (RJ-45 for Gbe)
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
2 x USB 2.0 		Size:7""
Resolution:800 x 480
Brightness (cd/m2):500 Size:7""
Resolution:800 x 480
Brightness (cd/m2):500
AFL-08A-N26
Compare products

Intel® Atom™ N2600 dual core 1.6 GHz CPU
Intel® NM10 Intel® Atom™ N2600 dual core 1.6 GHz CPU
Intel® NM10 		1 x AT/ATX switch 1 x DC Input Jack (9-28V Lockable DC Jack) 2 x LAN (GbE L ... 1 x AT/ATX switch
1 x DC Input Jack (9-28V Lockable DC Jack)
2 x LAN (GbE LAN)
1 x Line out
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
2 x USB 2.0
1 x VGA 		Size:8.4""
Resolution:800 x 600
Brightness (cd/m2):450 Size:8.4""
Resolution:800 x 600
Brightness (cd/m2):450
AFL-08AH-LX
Compare products

AMD Geode™ LX 800 (500MHz)
AMD LX 800 + AMD CS5536 AMD Geode™ LX 800 (500MHz)
AMD LX 800 + AMD CS5536 		1 x DC Input Jack 2 x LAN (RJ-45 for 10/100Mbps LAN) 1 x Power Switch 1 x R ... 1 x DC Input Jack
2 x LAN (RJ-45 for 10/100Mbps LAN)
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
2 x USB 2.0 		Size:8.4""
Resolution:800 x 600
Brightness (cd/m2):450 Size:8.4""
Resolution:800 x 600
Brightness (cd/m2):450
AFL-08AH-N270
Compare products

Intel® Atom™ N270 1.6GHz CPU
Intel® 945GSE + ICH7M Intel® Atom™ N270 1.6GHz CPU
Intel® 945GSE + ICH7M 		1 x Audio 1 x DC Input Jack 1 x Extemal SATA 2 x LAN (RJ-45 for Gbe) 1 x Po ... 1 x Audio
1 x DC Input Jack
1 x Extemal SATA
2 x LAN (RJ-45 for Gbe)
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
2 x USB 2.0 		Size:8.4""
Resolution:800 x 600
Brightness (cd/m2):450 Size:8.4""
Resolution:800 x 600
Brightness (cd/m2):450
AFL-08B-N270
Compare products

Intel® Atom™ Processor N270 (512K L2 Cache, 1.60 GHz, 533 MHz FSB) Intel® 9 ... Intel® Atom™ Processor N270 (512K L2 Cache, 1.60 GHz, 533 MHz FSB)
Intel® 945GSE + ICH7M 		1 x Audio 1 x DC Input Jack 1 x Extemal SATA 2 x LAN (RJ-45 for Gbe) 1 x Po ... 1 x Audio
1 x DC Input Jack
1 x Extemal SATA
2 x LAN (RJ-45 for Gbe)
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
2 x USB 2.0 		Size:8""
Resolution:800 x 600
Brightness (cd/m2):250 Size:8""
Resolution:800 x 600
Brightness (cd/m2):250
AFL-10A-N270
Compare products

Intel® Atom™ processor N270 1.6GHz CPU
Intel® 945GSE + ICH7M Intel® Atom™ processor N270 1.6GHz CPU
Intel® 945GSE + ICH7M 		1 x Audio 1 x DC Input Jack 1 x Extemal SATA 2 x LAN (RJ-45 for Gbe) 2 x US ... 1 x Audio
1 x DC Input Jack
1 x Extemal SATA
2 x LAN (RJ-45 for Gbe)
2 x USB 2.0
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button 		Size:10.4”
Resolution:800 x 600
Brightness (cd/m2):400 Size:10.4”
Resolution:800 x 600
Brightness (cd/m2):400
AFL-12A-N26
Compare products

Intel® Atom™ N2600 dual core 1.6 GHz CPU
Intel® NM10 Intel® Atom™ N2600 dual core 1.6 GHz CPU
Intel® NM10 		1 x AT/ATX switch 1 x DC Input Jack (9-28V Lockable DC Jack) 2 x LAN (GbE L ... 1 x AT/ATX switch
1 x DC Input Jack (9-28V Lockable DC Jack)
2 x LAN (GbE LAN)
1 x Line out
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
4 x USB 2.0
1 x VGA 		Size:12.1”
Resolution:1024 x 768
Brightness (cd/m2):500 Size:12.1”
Resolution:1024 x 768
Brightness (cd/m2):500
AFL-12A-N270
Compare products

Intel® Atom™ processor N270 1.6GHz CPU
Intel® 945GSE + ICH7M Intel® Atom™ processor N270 1.6GHz CPU
Intel® 945GSE + ICH7M 		1 x Audio 1 x DC Input Jack 1 x Extemal SATA 2 x LAN (RJ-45 for Gbe) 1 x Po ... 1 x Audio
1 x DC Input Jack
1 x Extemal SATA
2 x LAN (RJ-45 for Gbe)
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
4 x USB 2.0 		Size:12.1”
Resolution:1024 x 768
Brightness (cd/m2):500 Size:12.1”
Resolution:1024 x 768
Brightness (cd/m2):500
AFL-15AE-N270
Compare products

Intel® Atom™ N270 1.6GHz processor
Intel® 945GSE + ICH7M Intel® Atom™ N270 1.6GHz processor
Intel® 945GSE + ICH7M 		1 x Audio ((line-out)) 1 x DC Input Jack 2 x LAN (GbE LAN (RJ-45)) 1 x Powe ... 1 x Audio ((line-out))
1 x DC Input Jack
2 x LAN (GbE LAN (RJ-45))
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
4 x USB 2.0
1 x VGA 		Size:15”
Resolution:1024 x 768
Brightness (cd/m2):250 Size:15”
Resolution:1024 x 768
Brightness (cd/m2):250
AFL-W07A-N26
Compare products

Intel® Atom™ N2600
dual core 1.6 GHz CPU
Intel® NM10 Intel® Atom™ N2600
dual core 1.6 GHz CPU
Intel® NM10 		1 x AT/ATX switch 1 x DC Input Jack (9-28V Lockable DC Jack) 2 x LAN (Gbe L ... 1 x AT/ATX switch
1 x DC Input Jack (9-28V Lockable DC Jack)
2 x LAN (Gbe LAN)
1 x Line out
1 x Power Switch
1 x RS-232 (RJ-45)
1 x RS-422/485
1 x Reset Button
2 x USB 2.0
1 x VGA 		Size:Wide 7""
Resolution:800 x 480
Brightness (cd/m2):500 Size:Wide 7""
Resolution:800 x 480
Brightness (cd/m2):500
AFL2-08A-N26
Compare products

Intel® Atom™ N2600 dual core 1.6 GHz CPU
Intel® NM10 Intel® Atom™ N2600 dual core 1.6 GHz CPU
Intel® NM10 		1 x AT/ATX switch 1 x Clear CMOS Button 1 x DC Input Jack 1 x MicroSD card ... 1 x AT/ATX switch
1 x Clear CMOS Button
1 x DC Input Jack
1 x MicroSD card slot (on front panel)
1 x Mini USB 2.0 (on front panel)
1 x Power Switch
1 x Reset Button 		Size:8""
Resolution:800 x 600
Brightness (cd/m2):350 Size:8""
Resolution:800 x 600
Brightness (cd/m2):350
AFL2-10A-N28
Compare products

Intel® Atom™ N2800 dual core 1.86 GHz CPU
Intel® NM10 Intel® Atom™ N2800 dual core 1.86 GHz CPU
Intel® NM10 		1 x AT/ATX switch 1 x Clear CMOS Button 1 x DC Input Jack 1 x MicroSD card ... 1 x AT/ATX switch
1 x Clear CMOS Button
1 x DC Input Jack
1 x MicroSD card slot (on front panel)
1 x Mini USB 2.0 (on front panel)
1 x Power Switch
1 x Reset Button 		Size:10.4""
Resolution:800 x 600
Brightness (cd/m2):400 Size:10.4""
Resolution:800 x 600
Brightness (cd/m2):400
AFL2-12A-D525
Compare products

Intel® Atom™ D525 1.8GHz dual core processor
Intel® ICH8M Intel® Atom™ D525 1.8GHz dual core processor
Intel® ICH8M 		1 x AT/ATX switch 1 x Audio ((line-out)) 1 x Clear CMOS Button 1 x DC Input ... 1 x AT/ATX switch
1 x Audio ((line-out))
1 x Clear CMOS Button
1 x DC Input Jack
2 x LAN (GbE LAN (RJ-45))
1 x MicroSD card slot (on front panel)
1 x Mini USB 2.0 (on front panel)
1 x Power Switch
2 x RS-232 ((DB-9)/(RJ-45))
1 x RS-422/485 ((4-pin box header))
1 x Reset Button
4 x USB 2.0
1 x VGA ((DB-15)) 		Size:12.1""
Resolution:1024 x 768
Brightness (cd/m2):600 Size:12.1""
Resolution:1024 x 768
Brightness (cd/m2):600
AFL2-W07A-N26
Compare products

Intel® Atom™ N2600 dual core 1.6 GHz CPU
Intel® NM10 Intel® Atom™ N2600 dual core 1.6 GHz CPU
Intel® NM10 		1 x Audio 1 x Display Port 1 x LAN (GbE LAN (RJ-45)) 1 x RS-232 (COM Port ( ... 1 x Audio
1 x Display Port
1 x LAN (GbE LAN (RJ-45))
1 x RS-232 (COM Port (DB-9))
1 x RS-422/485 (COM Port (RJ-11))
2 x USB 2.0
2 x USB 3.0 		Size:Wide 7""
Resolution:800 x 480
Brightness (cd/m2):400 Size:Wide 7""
Resolution:800 x 480
Brightness (cd/m2):400
AFL2-W10A-N28
Compare products

Intel® Atom™ N2800 dual core 1.86 GHz CPU
Intel® NM10 Intel® Atom™ N2800 dual core 1.86 GHz CPU
Intel® NM10 		1 x Display Port 2 x RS-232 ((DB-9 connector/RJ-45)) 1 x RS-422/485 ((RJ45 ... 1 x Display Port
2 x RS-232 ((DB-9 connector/RJ-45))
1 x RS-422/485 ((RJ45 connector))
2 x USB 2.0
2 x USB 3.0
1 x Audio
1 x LAN (Gbe(RJ-45)) 		Size:Wide 10.2”
Resolution:1024 (W) x 600 (H)
Brightness (cd/m2):400 cd/m² Size:Wide 10.2”
Resolution:1024 (W) x 600 (H)
Brightness (cd/m2):400 cd/m²
AFL2-W15B-H61
Compare products

2nd/3rd Generation Intel® Core™ i7/i5/i3 and Pentium® processors Intel® ICH ... 2nd/3rd Generation Intel® Core™ i7/i5/i3 and Pentium® processors
Intel® ICH61 		1 x VGA port1 x HDMI port1 x Power switch1 x AT/ATX switch1 x Reset button1 ... 1 x VGA port
1 x HDMI port
1 x Power switch
1 x AT/ATX switch
1 x Reset button
1 x Clear CMOS button
1 x 9 ~ 36V DC jack
1 x Type K connector 		Size:15.6""(16:9)
Resolution:1366 x 768
Brightness (cd/m2):300 Size:15.6""(16:9)
Resolution:1366 x 768
Brightness (cd/m2):300
AFL3-08A-BT
Compare products

IntelR CeleronR J1900 (quad core, 2.0 GHz) IntelR CeleronR J1900 (quad core, 2.0 GHz) 1 x RS-232 ((RJ45 connector)) 1 x RS-422/485 ((DB-9 connector)) 2 x USB 2.0 ... 1 x RS-232 ((RJ45 connector))
1 x RS-422/485 ((DB-9 connector))
2 x USB 2.0
2 x USB 3.0
1 x LAN (Gbe)
1 x DC Input Jack (9-30V Lockable)
1 x Reset Button
1 x Power Switch
1 x AT/ATX switch
1 x Audio ((line-out)) 		Size:8.4”
Resolution:800 x 600 (4:3)
Brightness (cd/m2):450 Size:8.4”
Resolution:800 x 600 (4:3)
Brightness (cd/m2):450
AFL3-12A-BT
Compare products

IntelR CeleronR J1900 (quad core, 2.0 GHz) IntelR CeleronR J1900 (quad core, 2.0 GHz) 1 x AT/ATX switch 1 x Audio ((line-out)) 1 x DC Input Jack (9-30V lockable ... 1 x AT/ATX switch
1 x Audio ((line-out))
1 x DC Input Jack (9-30V lockable power jack)
2 x LAN (RJ-45 for GbE LAN)
1 x Power Switch
1 x RS-232 (COM port (RJ-45 connector))
1 x RS-422/485 (COM port (DB-9 connector)(RI/5V/12V))
1 x Reset Button
2 x USB 2.0
2 x USB 3.0 		Size:12.1""
Resolution:1024 x 768
Brightness (cd/m2):500 Size:12.1""
Resolution:1024 x 768
Brightness (cd/m2):500
AFL3-12C-ULT3
Compare products

Intel® Core™ i5 and Celeron® ULT Processor Intel® Core™ i5 and Celeron® ULT Processor 1 x RS-232/422/485 (DB-9)1 x RS232 (RJ-45)2 x GbE LAN2 x USB 2.02 x USB 3.0 ... 1 x RS-232/422/485 (DB-9)
1 x RS232 (RJ-45)
2 x GbE LAN
2 x USB 2.0
2 x USB 3.0
1 x DC jack (12-30V DC)
1 x HDMI
1 x Power switch
1 x Reset button
1 x AT/ATX switch 		Size: 12.1＂
Resolution: 1024 x 768
Brightness (cd/m2): 500 Size: 12.1＂
Resolution: 1024 x 768
Brightness (cd/m2): 500
AFL3-W07A-BT
Compare products

IntelR CeleronR N2807 (dual core, 1.58 GHz) IntelR CeleronR N2807 (dual core, 1.58 GHz) 1 x AT/ATX switch 1 x DC Input Jack (9-30V Lockable power jack) 2 x LAN 1 x ... 1 x AT/ATX switch
1 x DC Input Jack (9-30V Lockable power jack)
2 x LAN
1 x Power Switch
2 x RS-232 (COM port (DB-9 connector))
1 x Reset Button
2 x USB 3.0 		Size:7""
Resolution:1024 x 600
Brightness (cd/m2):500 Size:7""
Resolution:1024 x 600
Brightness (cd/m2):500
AFL3-W10A-BT
Compare products

Intel® Celeron® J1900 (quad core, 2.0 GHz) Intel® Celeron® J1900 (quad core, 2.0 GHz) 1 x RS-232 COM port (RJ-45 connector)1 x RS-232/422/485 COM port (DB-9 conn ... 1 x RS-232 COM port (RJ-45 connector)
1 x RS-232/422/485 COM port (DB-9 connector)(RI/5V/12V)
2 x USB 3.0
2 x USB 2.0
2 x RJ-45 for GbE LAN
1 x Power switch
1 x Audio port (line-out)
1 x Reset button
1 x AT/ATX switch
1 x 9-30V DC lockable power jack 		Size:10.1”
Resolution:1280 x 800 (16:10)
Brightness (cd/m²):350 Size:10.1”
Resolution:1280 x 800 (16:10)
Brightness (cd/m²):350
AFL3-W15A-BT
Compare products

IntelR CeleronR J1900 (quad core, 2 GHz)
N/A IntelR CeleronR J1900 (quad core, 2 GHz)
N/A 		1 x AT/ATX switch 1 x Audio ((line-out)) 1 x DC Input Jack (9-30V lockable ... 1 x AT/ATX switch
1 x Audio ((line-out))
1 x DC Input Jack (9-30V lockable power jack)
2 x LAN (GbE LAN)
1 x Power Switch
1 x RS-232 ((RJ-45 connector))
1 x RS-422/485 (COM port(DB-9 connector) (RI/5V/12V))
1 x Reset Button
2 x USB 2.0
2 x USB 3.0 		Size:15.6""
Resolution:1366 x 768
Brightness (cd/m2):300 Size:15.6""
Resolution:1366 x 768
Brightness (cd/m2):300
AFL3-W15C-ULT3
Compare products

Intel Core™ i7/i5/i3 and Celeron® on-board Processor Intel Core™ i7/i5/i3 and Celeron® on-board Processor 1 x RS-232 by DB-9 (RI/5V/12V)1 x RS-232/422/485 by DB-9 (RI/5V/12V)2 x GbE ... 1 x RS-232 by DB-9 (RI/5V/12V)
1 x RS-232/422/485 by DB-9 (RI/5V/12V)
2 x GbE LAN
4 x USB3.0
1 x HDMI output
1 x Power Switch
1 x Reset Button
1 x AT/ATX switch
1 x 9-30V Lockable Power Jack 		Size:15.6”
Resolution:1366 x 768 (16:9)
Brightness (cd/m²):300 Size:15.6”
Resolution:1366 x 768 (16:9)
Brightness (cd/m²):300
AFL3-W19A-AL
Compare products

Intel® Celeron® J3455 ( quad core , 1.5GHz up to 2.3 GHz) Intel® Celeron® J3455 ( quad core , 1.5GHz up to 2.3 GHz) 1 x RS-232/422/485 (RJ-45)1 x RS232 (RJ-45)2 x GbE LAN2 x USB 2.02 x USB 3. ... 1 x RS-232/422/485 (RJ-45)
1 x RS232 (RJ-45)
2 x GbE LAN
2 x USB 2.0
2 x USB 3.0
1 x DC jack (12-30V DC)
1 x HDMI
1 x Power switch
1 x Reset button
1 x AT/ATX switch
1 x Line out 		Size:18.5”
Resolution:1366 x 768
Brightness (cd/m2):250 Size:18.5”
Resolution:1366 x 768
Brightness (cd/m2):250
AFL3-W19C-ULT3
Compare products

Intel® Core™ i5 and Celeron® ULT Processor Intel® Core™ i5 and Celeron® ULT Processor 1 x RS-232 by DB-9 (RI/5V/12V)1 x RS-232/422/485 by DB-9 (RI/5V/12V)2 x GbE ... 1 x RS-232 by DB-9 (RI/5V/12V)
1 x RS-232/422/485 by DB-9 (RI/5V/12V)
2 x GbE LAN
4 x USB 3.0
1 x HDMI output
1 x Power switch
1 x Reset button
1 x AT/ATX switch
1 x 9-30V lockable power jack 		Size:18.5”
Resolution:1366 x 768 (16:9)
Brightness (cd/m²):250 Size:18.5”
Resolution:1366 x 768 (16:9)
Brightness (cd/m²):250
AFL3-W22C-ULT3
Compare products

Intel® Core™ i5 and Celeron® ULT Processor Intel® Core™ i5 and Celeron® ULT Processor 1 x RJ-11 for barcode module (1D/2D) 4 x USB 2.0 (2 for side) 4 x USB 3.0 p ... 1 x RJ-11 for barcode module (1D/2D)
4 x USB 2.0 (2 for side)
4 x USB 3.0 port
1 x HDMI output
2 x GbE LAN port
1 x RS-232/422/485
1 x 12~28V DC jack 		Size: 21.5”
Resolution: 1920 x 1080
Brightness(cd/m²): 250 Size: 21.5”
Resolution: 1920 x 1080
Brightness(cd/m²): 250
Panel PC with Fan
15”~22" Panel PC with fan
CPU / Chipset Display Expansion I/O Features
AFL-15i-HM55
Compare products

Intel® Core™ i7/i5/i3/Celeron® Processor
Intel® HM55 Intel® Core™ i7/i5/i3/Celeron® Processor
Intel® HM55 		1 x Line out 1 x RS-232 1 x RS-422/485 4 x USB 2.0 1 x HDMI 1 x VGA 2 x LAN ... 1 x Line out
1 x RS-232
1 x RS-422/485
4 x USB 2.0
1 x HDMI
1 x VGA
2 x LAN (Gbe(RJ-45))
1 x DC Input Jack
1 x Reset Button
1 x Power Switch 		Size:15”
Resolution:1024 x 768
Brightness (cd/m2):450 Size:15”
Resolution:1024 x 768
Brightness (cd/m2):450
AFL-17i-HM55
Compare products

Intel® Core™ i7/i5/i3/Celeron® Processor
Intel® HM55 Intel® Core™ i7/i5/i3/Celeron® Processor
Intel® HM55 		1 x Audio ((line-out)) 1 x DC Input Jack 1 x HDMI 2 x LAN (GbE LAN (RJ-45)) ... 1 x Audio ((line-out))
1 x DC Input Jack
1 x HDMI
2 x LAN (GbE LAN (RJ-45))
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
4 x USB 2.0
1 x VGA 		Size:17""
Resolution:1280 x 1024
Brightness (cd/m2):350 Size:17""
Resolution:1280 x 1024
Brightness (cd/m2):350
AFL-19i-HM55
Compare products

Intel® Core™ i7/i5/i3/Celeron® Processor
Intel® HM55 Intel® Core™ i7/i5/i3/Celeron® Processor
Intel® HM55 		1 x Audio ((line-out)) 1 x DC Input Jack 1 x HDMI 2 x LAN (GbE LAN (RJ-45)) ... 1 x Audio ((line-out))
1 x DC Input Jack
1 x HDMI
2 x LAN (GbE LAN (RJ-45))
1 x Power Switch
1 x RS-232
1 x RS-422/485
1 x Reset Button
4 x USB 2.0
1 x VGA 		Size:19""
Resolution:1280 x 1024
Brightness (cd/m2):350 Size:19""
Resolution:1280 x 1024
Brightness (cd/m2):350
AFL2-12A-HM65
Compare products

Intel® Atom™ D525 1.8GHz dual core processor
Intel® ICH8M Intel® Atom™ D525 1.8GHz dual core processor
Intel® ICH8M 		1 x AT/ATX switch 1 x Audio ((line-out)) 1 x Clear CMOS Button 1 x DC Input ... 1 x AT/ATX switch
1 x Audio ((line-out))
1 x Clear CMOS Button
1 x DC Input Jack
1 x HDMI
2 x LAN (GbE LAN (RJ-45))
1 x MicroSD card slot (on front panel)
1 x Mini USB 2.0 (on front panel)
1 x Power Switch
2 x RS-232 ((DB-9)/(RJ-45))
1 x RS-422/485 ((4-pin box header))
1 x Reset Button
2 x USB 2.0
2 x USB 3.0 		Size:12.1""
Resolution:1024 x 768
Brightness (cd/m2):600 Size:12.1""
Resolution:1024 x 768
Brightness (cd/m2):600
AFL2-17A-H61
Compare products

2nd/3rd Generation Intel® Core™ i7/i5/i3 and Pentium® processors Intel® ICH ... 2nd/3rd Generation Intel® Core™ i7/i5/i3 and Pentium® processors
Intel® ICH61 		2 x LAN (GbE LAN (one on the bottom, one on the left)) 1 x Line out 1 x Mic ... 2 x LAN (GbE LAN (one on the bottom, one on the left))
1 x Line out
1 x MicroSD card slot (on front panel)
1 x Mini USB 2.0 (on front panel)
2 x RS-232 ((DB-9))
1 x RS-422/485 ((DB-9))
3 x USB 2.0 ((two on the bottom, one on the left))
2 x USB 3.0 		Size:17""(4:3)
Resolution:1280 x 1024
Brightness (cd/m2):350 Size:17""(4:3)
Resolution:1280 x 1024
Brightness (cd/m2):350
AFL2-W21A-H61
Compare products

Intel® Core™ i7/i5/i3 and Pentium® processors
Intel® ICH61 Intel® Core™ i7/i5/i3 and Pentium® processors
Intel® ICH61 		1 x AT/ATX switch 1 x Clear CMOS Button 1 x DC Input Jack (9-36V DC jack) 1 ... 1 x AT/ATX switch
1 x Clear CMOS Button
1 x DC Input Jack (9-36V DC jack)
1 x HDMI
2 x LAN (GbE LAN (RJ-45 connector))
1 x Line out
1 x Mic
1 x Power Switch
2 x RS-232 ((DB-9))
1 x RS-422/485 ((DB-9))
1 x Reset Button
1 x Type K connector
3 x USB 2.0
2 x USB 3.0
1 x VGA ((DB-15)) 		Size:W21.5""(16:9)
Resolution:1920 x 1080
Brightness (cd/m2):250 Size:W21.5""(16:9)
Resolution:1920 x 1080
Brightness (cd/m2):250
AFL3-W15B-H81
Compare products

Intel® Core™ i7/i5/i3, Pentium®, Celeron® processor (TDP 35W)
Intel® H81 Intel® Core™ i7/i5/i3, Pentium®, Celeron® processor (TDP 35W)
Intel® H81 		1 x AT/ATX switch 1 x Audio ((line-out)) 1 x DC Input Jack (9-30V Lockable ... 1 x AT/ATX switch
1 x Audio ((line-out))
1 x DC Input Jack (9-30V Lockable power jack)
1 x HDMI (output)
2 x LAN (GbE LAN)
1 x Power Switch
1 x RS-232 (COM port (DB-9 connector))
1 x RS-422/485 (COM portDB-9 connector) (RI/5V/12V))
1 x Reset Button
4 x USB 2.0
2 x USB 3.0 		Size:15.6""
Resolution:1366 x 768
Brightness (cd/m2):300 Size:15.6""
Resolution:1366 x 768
Brightness (cd/m2):300
RISC-based Panel PC
7 inch Panel PC
IOVU Series 7”RISC-based Panel PCs integrate high capacity memory, and operate under the easy-to-use Android OS for achieving optimized computing capability.
CPU / Chipset Display Expansion I/O Features
IOVU-207AR-RK39
Compare products

Rockchip RK3399 (Dual-core Cortex-A72 up to 1.8GHz + Quad-core Cortex-A53 ... Rockchip RK3399
(Dual-core Cortex-A72 up to 1.8GHz + Quad-core Cortex-A53 up to 1.5GHz) 		Size: 7” TFT LCD Resolution: 720*1280 Brightness (cd/m²): 300 Touch : 5 poi ... Size: 7” TFT LCD
Resolution: 720*1280
Brightness (cd/m²): 300
Touch : 5 points Projected Capacitive 		1 x GbE RJ45 by RTL8211E 1 x USB 3.0 Type A 1 x USB 2.0 Type A 1 x Micro SD ... 1 x GbE RJ45 by RTL8211E
1 x USB 3.0 Type A
1 x USB 2.0 Type A
1 x Micro SD slot
1 x DC Jack(φ2.5/5.5mm) 		* OS: Android 7.1* CPU: Rockchip RK3399 (Dual-core Cortex-A72 up to 2.0GHz. ... * OS: Android 7.1
* CPU: Rockchip RK3399 (Dual-core Cortex-A72 up to 2.0GHz. Quad-core Cortex-A53 up to 1.5GHz)
* Boot Flash: 16G eMMC Nand Flash
* RAM: 2GB LPDDR3-1866
* 1 x SOS Key (with red bar): Press for calling help in case emergency
* 2 x Function Keys ( with green bar ): Default hot key by AP programming
10 inch Panel PC
IOVU Series 10”RISC-based Panel PCs integrate high capacity memory, and operate under the easy-to-use Android OS for achieving optimized computing capability.
CPU / Chipset Display Expansion I/O Features
IOVU-210AD-RK39
Compare products

Rockchip RK3399 (Dual-core Cortex-A72 up to 1.8GHz + Quad-core Cortex-A53 ... Rockchip RK3399
(Dual-core Cortex-A72 up to 1.8GHz + Quad-core Cortex-A53 up to 1.5GHz) 		Size:10.1” TFT LCDResolution:800(RGB) x 1280Brightness (cd/m²):250Touch : 1 ... Size:10.1” TFT LCD
Resolution:800(RGB) x 1280
Brightness (cd/m²):250
Touch : 10 points Projected Capacitive 		1 x RS-232 (DB-9) 1 x RS-232/422/485 (DB-9)4 bit GPIO (2 in, 2 out)1 x GbE ... 1 x RS-232 (DB-9)
1 x RS-232/422/485 (DB-9)
4 bit GPIO (2 in, 2 out)
1 x GbE RJ45 by RTL8211E w/ PoE (PD)
1 x USB 3.0 Type A
2 x USB 2.0 Type A
1 x DC Jack (φ2.5/5.5mm)
1 x 2 pin terminal block 		* 10.1” 1280x800 LCD* Project Capacitive Touch Screen* CPU: Rockchip RK3399 ... * 10.1” 1280x800 LCD
* Project Capacitive Touch Screen
* CPU: Rockchip RK3399 (Dual-core Cortex-A72 up to 2.0GHz. Quad-core Cortex-A53 up to 1.5GHz)
* OS: Android 7.1
* Boot Flash: 16GB eMMC Nand Flash
* RAM: 2GB LPDDR3
IOVU-210AR-RK39
Compare products

Rockchip RK3399 (Dual-core Cortex-A72 up to 1.8GHz + Quad-core Cortex-A53 ... Rockchip RK3399
(Dual-core Cortex-A72 up to 1.8GHz + Quad-core Cortex-A53 up to 1.5GHz) 		Size:10.1” TFT LCDResolution:800(RGB) x 1280Brightness (cd/m²):250Touch : 1 ... Size:10.1” TFT LCD
Resolution:800(RGB) x 1280
Brightness (cd/m²):250
Touch : 10 points Projected Capacitive 		1 x 4 bit (2 in, 2 out) 2 x 2 bit (1 in, 1 out)1 x GbE RJ45 by RTL8211E wit ... 1 x 4 bit (2 in, 2 out)
2 x 2 bit (1 in, 1 out)
1 x GbE RJ45 by RTL8211E with PoE (PD)
1 x GbE RJ45 by RTL8211E
1 x USB 3.0 Type A
1 x USB 2.0 Type A
3 x I²C sensor connectors (3V)
1 x RS-232 (4 pin terminal block)
1 x RS-232/422/485 (4 pin wafer connector)
1 x Micro SD slot
1 x DC Jack (φ2.5/5.5mm) 		* 10.1” 1280x800 LCD* Project Capacitive Touch Screen* CPU: Rockchip RK3399 ... * 10.1” 1280x800 LCD
* Project Capacitive Touch Screen
* CPU: Rockchip RK3399 (Dual-core Cortex-A72 up to 2.0GHz. Quad-core Cortex-A53 up to 1.5GHz)
* OS: Android 7.1
* Boot Flash: 16GB eMMC Nand Flash
* RAM: 2GB LPDDR3-1866
* Grove Interface IOT Sensor connectors
Healthcare Panel PC
Medical Panel PC
IEI POC medical panel PCs provide big screen size for medical use, optimizing the applications as an information processing terminal. IEI POC medical panel PCs offer superior CPU performance and various peripherals to increase functionality and to suit the requirements of medical application.
CPU / Chipset Display Expansion I/O Features
POC-17C-ULT3
Compare products

Intel® Skylake-ULT platform Core™ i5-6300U and Celeron® 3955U Intel® Skylake-ULT platform Core™ i5-6300U and Celeron® 3955U 1 x PCIe Mini reserved 1 x PCIe Mini reserved 1 x RJ-11 for barcode module (1D/2D)4 x USB 2.0 (2 for side)4 x USB 3.0 por ... 1 x RJ-11 for barcode module (1D/2D)
4 x USB 2.0 (2 for side)
4 x USB 3.0 port
1 x HDMI output
2 x GbE LAN port
1 x RS-232/422/485
1 x 12~28V DC jack 		Size:17”(5:4)
Resolution:1280 x 1024
Brightness (cd/m²):350 Size:17”(5:4)
Resolution:1280 x 1024
Brightness (cd/m²):350
POC-W22A-H81
Compare products

Intel® desktop Core™ i7/i5/i3/Pentium®/Celeron® CPU with Intel® H81 chipset ... Intel® desktop Core™ i7/i5/i3/Pentium®/Celeron® CPU with Intel® H81 chipset (Up to TDP 35W CPU)
Intel® H81 		Size:21.5""
Resolution:1920 (W) x 1080 (H)
Brightness (cd/m2):250 Size:21.5""
Resolution:1920 (W) x 1080 (H)
Brightness (cd/m2):250
POC-W24C-ULT3
Compare products

6th generation Intel® mobile ULT Core™ i7-6600U / Core™ i5-6300U /Celeron® ... 6th generation Intel® mobile ULT Core™ i7-6600U / Core™ i5-6300U /Celeron® 3855U
7th generation Intel® mobile ULT Kaby Lake on-board SoC (by project base) 		1 x PCIe Mini reserved for E-Window expansion 1 x PCIe Mini reserved for E-Window expansion 1 x RJ-11 for 1D/2D barcode reader4 x USB 2.0 (2 on the side)4 x USB 3.0 po ... 1 x RJ-11 for 1D/2D barcode reader
4 x USB 2.0 (2 on the side)
4 x USB 3.0 port
1 x HDMI output
2 x GbE LAN port
1 x RS-232/422/485
1 x 12~28V DC jack 		Size:24""
Resolution:1920 (W) x 1080 (H)
Brightness (cd/m²):250 Size:24""
Resolution:1920 (W) x 1080 (H)
Brightness (cd/m²):250
POCm-W22C-ULT3
Compare products

6th generation Intel® mobile ULT Core™ i7-6600U / Core™ i5-6300U /Celeron® ... 6th generation Intel® mobile ULT Core™ i7-6600U / Core™ i5-6300U /Celeron® 3855U 1 x PCIe Mini reserved for E-Window expansion 1 x PCIe Mini reserved for E-Window expansion 2 x USB 2.0 (side)4 x USB 3.0 port2 x HDMI output2 x GbE LAN port2 x RS-232 ... 2 x USB 2.0 (side)
4 x USB 3.0 port
2 x HDMI output
2 x GbE LAN port
2 x RS-232/422/485
1 x Audio out (side) + 1 x Mic in (side)
1 x Digital Mic
1 x DC jack 		Size:22＂
Resolution:1920 (W) x 1080 (H)
Brightness (cd/m²):250 Size:22＂
Resolution:1920 (W) x 1080 (H)
Brightness (cd/m²):250
POCm-W24C-ULT3
Compare products

6th generation Intel® mobile ULT Core™ i7-6600U / Core™ i5-6300U /Celeron® ... 6th generation Intel® mobile ULT Core™ i7-6600U / Core™ i5-6300U /Celeron® 3855U 1 x PCIe Mini reserved for E-Window expansion 1 x PCIe Mini reserved for E-Window expansion 2 x USB 2.0 (side)4 x USB 3.0 port2 x HDMI output2 x GbE LAN port2 x RS-232 ... 2 x USB 2.0 (side)
4 x USB 3.0 port
2 x HDMI output
2 x GbE LAN port
2 x RS-232/422/485
1 x Audio out (side) + 1 x Mic in (side)
1 x Digital Mic
1 x DC jack 		Size:24＂
Resolution:1920 (W) x 1080 (H)
Brightness (cd/m²):250 Size:24＂
Resolution:1920 (W) x 1080 (H)
Brightness (cd/m²):250
Bedside Terminal Panel PC
* Back I/O with 1.5kV isolated RS-232/422/485
* High performance with fanless system
* Monitor mode
CPU / Chipset Display Expansion I/O Features
BIS-W19C-ULT4
Compare products

Intel® Kabylake ULT platform Core™ i5-7300U and Celeron® 3865U Intel® Kabylake ULT platform Core™ i5-7300U and Celeron® 3865U LCD: 18.5” (16:9)Brightness (cd/m²): 250/350Max Resolution: 1366 (W) x 768 ... LCD: 18.5” (16:9)
Brightness (cd/m²): 250/350
Max Resolution: 1366 (W) x 768 (H) / 1920 (W) x 1080 (H) 		Rear 1 x 1.5kV isolation COM port 1 x 12~28V DC Jack 1 x GbE LAN port 2 x ... Rear
1 x 1.5kV isolation COM port
1 x 12~28V DC Jack
1 x GbE LAN port
2 x USB 3.0 port

Bottom
1 x RJ-11 for barcode scanner (1D/2D)
1 x GbE LAN port
2 x USB 3.0 port
1 x HDMI output

Side
1 x HDMI input
2 x USB 2.0 port
1 x Audio out
1 x Mic in
Fitness Panel PC
The fitness console developed by IEI can fulfill needs for those people who are not satisfied with the traditional workout experience. With the entertainment system provided by IEI Fitness console, people can watch TV, use social media such as Twitter or Facebook to connect with their friends, and use the virtual running programs to enjoy the scenery and the landscape of other countries while they are running or cycling.
CPU / Chipset Display Expansion I/O Features
FIT1-W10A-IMX6
Compare products

Freescale™ i.MX6 Cortex™-A9 quad core 1.0 GHz Freescale™ i.MX6 Cortex™-A9 quad core 1.0 GHz LCD Size: 10.1""
Resolution: 1280(W) x 800(H) LCD Size: 10.1""
Resolution: 1280(W) x 800(H) 		1 x Enthernet1 x Csafe2 x Hand Pulse1 x TV 1 x HDMI In1 x Keypad 1 x USB 2. ... 1 x Enthernet
1 x Csafe
2 x Hand Pulse
1 x TV
1 x HDMI In
1 x Keypad
1 x USB 2.0
1 x LCB 		(Ready for ODM / OEM)Support Android 5.1 OSFlexible ID Design (Open Frame)I ... (Ready for ODM / OEM)
Support Android 5.1 OS
Flexible ID Design (Open Frame)
IEI Customer Reference Board (10.1""/15.6""/18.5"" share the same main board)
Waterproof : IPX5 (For customized ID)
Support BLE / ANT+ / NFC
Support ATSC / DVBT TV Dongle
FIT1-W15A-IMX6
Compare products

Freescale™ i.MX6 Cortex™-A9 quad core 1.0 GHz Freescale™ i.MX6 Cortex™-A9 quad core 1.0 GHz LCD Size: 15.6""
Resolution: 1366(W) x 768(H) LCD Size: 15.6""
Resolution: 1366(W) x 768(H) 		1 x Enthernet1 x Csafe2 x Hand Pulse1 x TV 1 x HDMI In1 x Keypad 1 x USB 2. ... 1 x Enthernet
1 x Csafe
2 x Hand Pulse
1 x TV
1 x HDMI In
1 x Keypad
1 x USB 2.0
1 x LCB 		(Ready for ODM / OEM)Support Android 5.1 OSFlexible ID Design (Open Frame)I ... (Ready for ODM / OEM)
Support Android 5.1 OS
Flexible ID Design (Open Frame)
IEI Customer Reference Board (10.1""/15.6""/18.5"" share the same main board)
Waterproof : IPX5 (For customized ID)
Support BLE / ANT+ / NFC
Support ATSC / DVBT TV Dongle
FIT1-W18A-IMX6
Compare products

Freescale™ i.MX6 Cortex™-A9 quad core 1.0 GHz Freescale™ i.MX6 Cortex™-A9 quad core 1.0 GHz LCD Size: 18.5""
Resolution: 1366(W) x 768(H) LCD Size: 18.5""
Resolution: 1366(W) x 768(H) 		1 x Enthernet1 x Csafe2 x Hand Pulse1 x TV 1 x HDMI In1 x Keypad 1 x USB 2. ... 1 x Enthernet
1 x Csafe
2 x Hand Pulse
1 x TV
1 x HDMI In
1 x Keypad
1 x USB 2.0
1 x LCB 		(Ready for ODM / OEM)Support Android 5.1 OSFlexible ID Design (Open Frame)I ... (Ready for ODM / OEM)
Support Android 5.1 OS
Flexible ID Design (Open Frame)
IEI Customer Reference Board (10.1""/15.6""/18.5"" share the same main board)
Waterproof : IPX5 (For customized ID)
Support BLE / ANT+ / NFC
Support ATSC / DVBT TV Dongle
Transportation Panel PC
In-vehicle Panel PC
IEI in-vehicle panel PC adopts Linux and Android system with a powerful Rockchip RK3399 for transportation solutions in AI.
CPU / Chipset Display Expansion I/O Features
AFOKAR-08A
Compare products

Marine Panel PC
The maritime field faces critical environmental challenges, making reliable and rugged systems essential. IEI provides maritime professionals and marine-grade panel PCs and monitors and embedded box that use leading technologies and reliable designs which are perfect for applications on the dock, on the open deck, or in the control room or bridge.
CPU / Chipset Display Expansion I/O Features
S19A-QM87
Compare products

Intel® 22nm 4th generation Mobile Core™ i5-4400E 2.7GHz processor Intel® QM ... Intel® 22nm 4th generation Mobile Core™ i5-4400E 2.7GHz processor
Intel® QM87 		LCD Size:19""
Brightness(cd/m2):300
Max Resolution:1280(W) x 1024(H) LCD Size:19""
Brightness(cd/m2):300
Max Resolution:1280(W) x 1024(H) 		2 x Antenna SMA ((reserved)) 2 x CAN-bus (terminal block) 1 x Power In (Iso ... 2 x Antenna SMA ((reserved))
2 x CAN-bus (terminal block)
1 x Power In (Isolated 18-36V DC terminal block)
1 x DVI-D
1 x HDMI
2 x LAN (RJ-45 for Gbe)
1 x Line in
1 x Line out
1 x Mic
1 x PS/2
1 x Power Switch
1 x RS-232 ((non-isolated))
4 x RS-422/485 ((2.5 kv isolation protection))
2 x USB2.0
2 x USB3.0
1 x VGA
S24A-QM87
Compare products

Intel® 22nm 4th generation Mobile Core™ i5-4400E 2.7GHz processor Intel® QM ... Intel® 22nm 4th generation Mobile Core™ i5-4400E 2.7GHz processor
Intel® QM87 		LCD Size:24""
Brightness(cd/m2):300
Max Resolution:1920(W) x 1080(H) LCD Size:24""
Brightness(cd/m2):300
Max Resolution:1920(W) x 1080(H) 		2 x Antenna SMA ((reserved)) 2 x CAN-bus (terminal block (2.5 kv isolation ... 2 x Antenna SMA ((reserved))
2 x CAN-bus (terminal block (2.5 kv isolation protection))
1 x Power In (Isolated 18-36V DC terminal block)
1 x DVI-D
1 x HDMI
2 x LAN (RJ-45 for Gbe)
1 x Line in
1 x Line out
1 x Mic
1 x PS/2
1 x Power Switch
1 x RS-232 ((DB-9))
4 x RS-422/485 ((2.5 kv isolation protection))
2 x USB2.0
2 x USB3.0
1 x VGA
Industrial Monitor
Industrial Display
Durable waterproof displays are essential in today’s commercial and industrial applications. IEI’s versatile lines of flat-bezel IP 65 compliant industrial displays with shock and vibration resistance are designed specifically to endure the rigorous demands of modern commerce and industrial environments. These displays are easily integrated into automation applications, ATM machines and human machine interfaces.
CPU / Chipset Display Expansion I/O Features
DM-F08A
Compare products

LCD Size:8”(4:3)
Brightness(cd/m2):500
Max Resolution:800 (W) x 600 (H) LCD Size:8”(4:3)
Brightness(cd/m2):500
Max Resolution:800 (W) x 600 (H) 		1 x VGA (DB-15)1 x DVI1 x USB 2.0 (touch)1 x RS-232 (reserved for resistive ... 1 x VGA (DB-15)
1 x DVI
1 x USB 2.0 (touch)
1 x RS-232 (reserved for resistive touch ATO)
1 x Lockable 12V DC jack
DM-F12A
Compare products

LCD Size:12”(4:3)
Brightness(cd/m2):600
Max Resolution:1024 (W) x 768 (H) LCD Size:12”(4:3)
Brightness(cd/m2):600
Max Resolution:1024 (W) x 768 (H) 		1 x VGA (DB-15)1 x HDMI1 x DisplayPort 1.11 x USB 2.0 (touch)1 x RS-232 (re ... 1 x VGA (DB-15)
1 x HDMI
1 x DisplayPort 1.1
1 x USB 2.0 (touch)
1 x RS-232 (reserved for resistive touch ATO)
1 x Lockable 9V-36V DC jack
1 x 9V-36V terminal block
DM-F15A
Compare products

LCD Size:15”(4:3)
Brightness(cd/m2):450
Max Resolution:1024 (W) x 768 (H) LCD Size:15”(4:3)
Brightness(cd/m2):450
Max Resolution:1024 (W) x 768 (H) 		1 x VGA (DB-15)1 x HDMI1 x DisplayPort 1.11 x USB 2.0 (touch)1 x RS-232 (re ... 1 x VGA (DB-15)
1 x HDMI
1 x DisplayPort 1.1
1 x USB 2.0 (touch)
1 x RS-232 (reserved for resistive touch ATO)
1 x Lockable 9V-36V DC jack
1 x 9V-36V terminal block
DM-F17A
Compare products

LCD Size:17”(5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H) LCD Size:17”(5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H) 		1 x VGA (DB-15)1 x VGA (DB-15)1 x DVI (F19A only)1 x HDMI (F17A only)1 x Di ... 1 x VGA (DB-15)
1 x VGA (DB-15)
1 x DVI (F19A only)
1 x HDMI (F17A only)
1 x DisplayPort 1.1
1 x USB 2.0 (touch)
1 x RS-232 (reserved for resistive touch ATO)
1 x Lockable 9V-36V DC jack
1 x 9V-36V terminal block
DM-F19A
Compare products

LCD Size:19”(4:3)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H) LCD Size:19”(4:3)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H) 		1 x VGA (DB-15)1 x VGA (DB-15)1 x DVI (F19A only)1 x HDMI (F17A only)1 x Di ... 1 x VGA (DB-15)
1 x VGA (DB-15)
1 x DVI (F19A only)
1 x HDMI (F17A only)
1 x DisplayPort 1.1
1 x USB 2.0 (touch)
1 x RS-232 (reserved for resistive touch ATO)
1 x Lockable 9V-36V DC jack
1 x 9V-36V terminal block
DM-F22A
Compare products

LCD Size:21.5”(16:9) Brightness(cd/m2):250 Max Resolution:1920 (W) x 1080 ( ... LCD Size:21.5”(16:9)
Brightness(cd/m2):250
Max Resolution:1920 (W) x 1080 (H) 		1 x VGA (DB-15)1 x HDMI1 x DisplayPort 1.11 x USB 2.0 (touch)1 x RS-232 (re ... 1 x VGA (DB-15)
1 x HDMI
1 x DisplayPort 1.1
1 x USB 2.0 (touch)
1 x RS-232 (reserved for resistive touch ATO)
1 x Lockable 9V-36V DC jack
1 x 9V-36V terminal block
DM-F24A
Compare products

LCD Size:24”(16:9)
Brightness(cd/m2):250
Max Resolution:1920 (W) x 1080 (H) LCD Size:24”(16:9)
Brightness(cd/m2):250
Max Resolution:1920 (W) x 1080 (H) 		1 x VGA (DB-15)1 x HDMI1 x DisplayPort 1.11 x USB 2.0 (touch)1 x RS-232 (re ... 1 x VGA (DB-15)
1 x HDMI
1 x DisplayPort 1.1
1 x USB 2.0 (touch)
1 x RS-232 (reserved for resistive touch ATO)
1 x Lockable 9V-36V DC jack
1 x 9V-36V terminal block
DM-F65A
Compare products

LCD Size:6.5”(4:3)
Brightness(cd/m2):800
Max Resolution:640 (W) x 480 (H) LCD Size:6.5”(4:3)
Brightness(cd/m2):800
Max Resolution:640 (W) x 480 (H) 		1 x VGA (DB-15)1 x DVI1 x USB 2.0 (touch)1 x RS-232 (reserved for resistive ... 1 x VGA (DB-15)
1 x DVI
1 x USB 2.0 (touch)
1 x RS-232 (reserved for resistive touch ATO)
1 x Lockable 12V DC jack
New
DM-FW15A
Compare products

LCD Size: 15.6” (16:9)Brightness(cd/m2): 400Max Resolution: 1366 (W) X 768 ... LCD Size: 15.6” (16:9)
Brightness(cd/m2): 400
Max Resolution: 1366 (W) X 768 (H)
Contrast Ratio: 500:1
Backlight MTBF(hrs): 50000 		1 x VGA (DB-15) 1 x HDMI 1 x DisplayPort 1.1 1 x USB 2.0 (touch) 1 x RS-232 ... 1 x VGA (DB-15)
1 x HDMI
1 x DisplayPort 1.1
1 x USB 2.0 (touch)
1 x RS-232 (reserved for resistive touch ATO)
1 x Lockable 9V-36V DC jack
1 x 9V-36V terminal block
New
DM-FW19A
Compare products

LCD Size:18.5” (16:9)Brightness(cd/m2): 400Max Resolution: 1366 (W) X 768 ( ... LCD Size:18.5” (16:9)
Brightness(cd/m2): 400
Max Resolution: 1366 (W) X 768 (H)
Contrast Ratio: 1000:1
Backlight MTBF(hrs): 50000 		1 x VGA (DB-15) 1 x DVI (F19A only) 1 x HDMI (F17A & FW19A only) 1 x Displa ... 1 x VGA (DB-15)
1 x DVI (F19A only)
1 x HDMI (F17A & FW19A only)
1 x DisplayPort 1.1
1 x USB 2.0 (touch)
1 x RS-232 (reserved for resistive touch ATO)
1 x Lockable 9V-36V DC jack
1 x 9V-36V terminal block
Marine Monitor
* IP66 Front / IP22 Rear
*-15°C ~ +55°C Wide Temperature and Flat-bezel Projected Capacitive Touchscreen
*Excellent Visual Performance
• Full OSD function configuration
• 0%~100% full range dimming
• 178°/178° wide viewing angles
CPU / Chipset Display Expansion I/O Features
S19M
Compare products

LCD Size:19""
Brightness(cd/m2):300
Max Resolution:1280(W) x 1024(H) LCD Size:19""
Brightness(cd/m2):300
Max Resolution:1280(W) x 1024(H) 		2 x BNC (Input/Output) 1 x Buzzer 2 x DVI-D 1 x LAN (RJ-45) 2 x Power In (1 ... 2 x BNC (Input/Output)
1 x Buzzer
2 x DVI-D
1 x LAN (RJ-45)
2 x Power In (100-240V AC/18-36V DC(Terminal Block))
1 x RS-422/485
1 x Touchscreen (USB Type A connector (female))
3 x VGA (Input x 2,Output x1)
S24M
Compare products

LCD Size:24""
Brightness(cd/m2):300
Max Resolution:1920(W) x 1080(H) LCD Size:24""
Brightness(cd/m2):300
Max Resolution:1920(W) x 1080(H) 		2 x BNC (Input/Output) 1 x Buzzer 2 x DVI-D 1 x LAN (RJ-45) 2 x Power In (1 ... 2 x BNC (Input/Output)
1 x Buzzer
2 x DVI-D
1 x LAN (RJ-45)
2 x Power In (100)
1 x RS-422/485
1 x Touchscreen (UUSB Type A connector (female))
3 x VGA (Input x 2/Output x 1)
QTS Gateway
PPC Series Panel PC
  • Built-in QTS Gateway operating system that can be visualized immediately
  • Supports remote connection (myQNAPcloud) and hybrid backup (Hybrid Backup Sync)
  • QRM+ easily monitors IPMI equipment, servers, PCs and production line equipment Surveillance Station for remote video surveillance, 24/7 security
    • PPC-F12B-BT-QGW
    Compare products

    PPC-F15B-BT-QGW
    Compare products

    PPC-F17B-BT-QGW
    Compare products
