Embedded Computer

By using IEI embedded computer, you can easily build feature-rich embedded system for industrial, medical, military, transportation and commercial applications.
比較狀態 :
已設定.要比較機種數 :
已設定.要比較機種 :
列表區塊.Now 位置狀態 :
列表區塊.單位區塊寬 :
列表區塊.Now X 位置 :
列表區塊.目標 X 位置 :
顯示框寬 :
列表寬 :
Add-on Card
LCD Converter Board
iDP (IEI Internal Display Port) connector is provided on the IEI products. Through the IEI iDP converter cards, the iDP connector can support different display specification, such as VGA, HDMI, DVI-D and LVDS.
CPU Socket / Chipset
Memory
Display
I/O / Slot
Features

DP-DP

DisplayPort Expansion Board (DP-DP-R10 for IEI iDP Connector)
1 x IEI iDP connector

DP-DVI

DisplayPort to DVI Converter Board (for IEI iDP Connector)
1 x IEI iDP connector

DP-HDMI

DisplayPort to HDMI 1.3a Converter Board (for IEI iDP DP-HDMI-R10 connector)
IEI iDP connector

DP-LVDS

DisplayPort to 24-bit Dual-channel LVDS Converter Board DP-LVDS-R10 (for IEI iDP Connector)
1 x IEI iDP connector

DP-VGA

DisplayPort to VGA Converter Board (for IEI iDP Connector)
1 x IEI iDP connector
PCI/PCIe Expansion Card
IEI provides industrial communication cards for different expasion and application through ISA, PCI or PCI Express.
CPU Socket / Chipset
Memory
Display
I/O / Slot
Features

GPOE-2P

PCI Express Power over Ethernet card, 2-port 1000 Base(T), 802.3at compliant, low profile, RoHS
1. PCI Express® x1 compliant
2. Support IEEE 802.3at for PoE (Power over Ethernet) with 30 watts per port
3. Support link aggregation/jumbo frames (9 Kbyte)
4. Supports 12V~24V DC input power

GPOE-4P

PCI Express Power over Ethernet card, 4-port 1000 Base(T), 802.3at/af compliant, low profile, RoHS
1. PCI Express® x1 compliant
2. Support for total 90 watts under full load
3. Support link aggregation/jumbo frames (9 Kbyte)
4. Supports 12V~24V DC input power
IEI GPOE-6P add-on card

GPOE-6P

PCI Express Power over Ethernet card, 6-port 1000 Base(T), 802.3at / bt compliant, RoHS
1. Provide 6 x10/100/1000Base-T(X) PoE (P.S.E.) ports
2. Total 180 Watts power budget with maximum 90 Watts per port
3. PoE power sourced from 12 ~ 24VDC of ATX power
4. Each LAN port supports both PoE and Non-PoE connections (Auto Detect & Classification)
5. Supports SW/RDK (IEI GPOE Management Software Tools)
6. Compatible with x4, x8 and x16 PCIe slots
7. IEEE 802.3at/bt PoE compliant

IPCIE-4POE

PCI Express Power over ethernet card
PCI Express Power over ethernet card
LAN-100G2SF-E810 Intel® Ethernet Controller E810 based Network Interface Card
icon-new

LAN-100G2SF

Intel® Ethernet Controller E810 based Network Interface Card 2 x 100GbE with 2 x QSFP28, PCIe 4.0 x 16 interface.
Intel® Ethernet Controller E810 based Network Interface Card 2 x 100GbE with 2 x QSFP28, PCIe 4.0 x 16 interface.
Wireless Module
PCIe Mini card *Solid design with external antenna diversity *Low power consumption and high performance
CPU Socket / Chipset
Memory
Display
I/O / Slot
Features

EMB-WIFI-KIT

PCIe Mini card wireless LAN module kit
● Half size PCIe Mini card form factor
● High speed wireless connection
● Low power consumption and high performance
● Fully qualified Bluetooth 4.0
● Solid design with external antenna diversity
Mini-PCIe Module
PCI Express Mini Card *IO Interface converter *RoHs
CPU Socket / Chipset
Memory
Display
I/O / Slot
Features

IGCME-1300

PCIe Mini VGA Adapter Card,
PCI Express Mini card

1 x 10-pin (2x5) box header by 2.0mm pitch

MPCIE-3G

PCI Express Mini 3G Adapter Card, RoHS
PCI Express Mini 3G Adapter Card, RoHS

MPCIE-CAN

USB to dual isolated CANbus 2.0B Module
Mini PCIe interface (USB interface)
2 x CANBus 2.0B port module

MPCIE-DLAN

PCI Express Mini Dual Intel® GbE LAN Module, Full Size
PCI Express Mini GbE LAN Module

MPCIE-LAN

PCI Express Mini GbE LAN Module, Full Size
PCI Express mini card

MPCIE-UART-KIT01

PCI Express Mini Card Supports Quad-port RS-232/422/485, Full Size
PCI Express Mini Card

MPCIE-UART-KIT02

PCI Express Mini Card Supports Dual-port RS-232/422/485, 16-bit GPIO, Full Size
PCI Express Mini Card
TPM Module
Hardware-based security solution for data protection and reliable authentication via TPM that stores key, passwords and digital certificates.
CPU Socket / Chipset
Memory
Display
I/O / Slot
Features

TPM-IN01

Hardware-based security solution for data protection and reliable authentication via TPM that stores key, passwords and digital certificates.
1. TPM management
2. File & Folder En/De-cryption
3. Personal secure drive
4. Secure Email
5. Key transferring
6. Security policy configuration

TPM-IN02

Hardware-based security solution for data protection and reliable authentication via TPM that stores key, passwords and digital certificates.
1. TPM management
2. File & Folder En/De-cryption
3. Personal secure drive
4. Secure Email
5. Key transferring
6. Security policy configuration

TPM-IN03

SPI TPM 2.0 module, software management tool, firmware v7.85
Infineon SPI TPM 2.0 with SLB9670VQ2.0 FW7.85
SPI TPM 2.0 module, software management tool, firmware v7.85
Audio Kit

Audio Board

CPU Socket / Chipset
Memory
Display
I/O / Slot
Features
AC-KIT-888S  Audio Kit
icon-new

AC-KIT-888S

Realtek ALC888S 7.1 Channel HD Audio peripheral board,RoHS
Realtek ALC888S HD Audio codec
1 x Mic-in connector
1 x Line-in connector
1 x Front-out connector
1 x Rear-out connector
1 x Center/Subwoofer connector
1. Realtek ALC888S HD Audio codec IC supported
2. Five audio jacks for microphone, 7.1+2-channel high definition audio input and output
3. High performance 7.1+2-channel high definition audio board provides 7.1-channel sound playback and multiple streaming through the front panel stereo outputs
4. Digital to Analog Converter (DAC) with 97dB Signal to Noise Ratio (SNR)
5. Analog to Digital Converter (ADC) with 90dB Signal to Noise Ratio (SNR)
6. All the Digital to Analog Converter (DAC) supports 44.1k/48k/96k/192kHz sampling rate
7. All the Analog to Digital Converter (ADC) supports 44.1k/48k/88.2k/96k/192kHz sample rate
8. Driver supports Windows® 2000/2003/XP/Vista/7/10 (32/64 bits) and Linux (Ubuntu or Debian)
9. CE/FCC compliant
