TPM-IN01

Hardware-based security solution for data protection and reliable authentication via TPM that stores key, passwords and digital certificates.

  • Overview

    1. TPM management
    2. File & Folder En/De-cryption
    3. Personal secure drive
    4. Secure Email
    5. Key transferring
    6. Security policy configuration
  • Specifications

    • Hardware Spec.

      Spec Item Description
      Physical Characteristics
      Dimensions (LxWxH) (mm)26 X 25 X 2.6
      Net Weight5g
      Other Features
      TPMTPM 1.2
      Environment
      Operating Temperature0°C ~ 60°C
      Storage Temperature-10°C ~ 70°C
      Humidity5% ~95%, non-condensing
      Card Slot Interface
      OtherLow pin count
    • Ordering Info.

      Item No. Description
      TPM-IN01-R20 20-pin INFINEON TPM Module,S/W managementTool,Firmware V4.4
