Network Appliance

- All-in-One Solution, including Router, VPN, Switch, Firewall, UTM, etc
- Open Source Software
- ODM/OEM Service

[Learn More about PUZZLE Series]


比較狀態 :
已設定.要比較機種數 :
已設定.要比較機種 :
列表區塊.Now 位置狀態 :
列表區塊.單位區塊寬 :
列表區塊.Now X 位置 :
列表區塊.目標 X 位置 :
顯示框寬 :
列表寬 :
Network Appliance

Premium network appliances

The 1U and 2U rackmount network appliances feature the latest server-grade Intel® Xeon® D and Intel® Xeon® Scalable processors for enterprise network and cloud infrastructures. The network appliances offer high expandability, scaling throughputs and various copper, fiber and bypass Ethernet ports through optional 1GbE/10GbE/25GbE/100GbE NIC modules.
IEI PUZZLE-7030A intel 1U network appliance

PUZZLE-7030A

1U Rackmount Network Appliance with Intel® Xeon® D Processor series (Code Name: Ice Lake-D LCC)
PUZZLE-9030 1U Rackmount Network Appliance

PUZZLE-9030

1U Rackmount Network Appliance with 3rd Gen AMD® EPYC™ 7003 series processor
(request by order)

PUZZLE-9040

2U Rackmount Network Appliance with Intel® Xeon® Scalable processors (Code name: Sapphire Rapids)
(request by order)
PUZZLE-IN005 Intel® 2U Network Appliance

PUZZLE-IN005

2U Rackmount Network Appliance with 3rd Gen. Intel®Xeon® Scalable Processor,
Eight PulM Module Slots & One PCIe x8 Expansion
PUZZLE-IN004 1U Rackmount Network Appliance with Intel® Xeon® D Processor

PUZZLE-IN004

1U Rackmount Network Appliance with Intel® Xeon® D Processor support 8 x GbE, 4 x 10GbE SFP+ and 1 PCIe x8 slot

Performance-level network appliances

The 1U rackmount network appliances integrate with Intel® Xeon® E and Intel® Core™ processors. They are ideally to be deployed in various security applications such as firewall, VPN and UTM for medium-sized enterprises. Extra redundancy features are also included like hot-swappable PSUs and multiple network module slot (NMS) bays for flexible port configuration.

PUZZLE-5030

1U Rackmount Network Appliance with Intel® Xeon® E Processor (Codename: Rocket Lake) and the Intel® C256 chipset
PUZZLE-IN001A Network Appliance

PUZZLE-IN001A

1U Rackmount Network Appliance with Intel® Xeon® E and 8th & 9th Generation Intel® Core™ i3/Pentium®/Celeron® Processor, two PulM module slots and two PCIe slots
PUZZLE-IN002 Network Appliance with Intel CPU

PUZZLE-IN002

1U Rackmount Network Appliance with 8th & 9th Generation Intel® Core™ i7/i5/i3, Pentium® or Celeron® Processor, 1 PCIe slots
IEI PUZZLE-IN001 x86-based appliance

PUZZLE-IN001

1U Rackmount Network Appliance with Intel® Xeon® E, 8th Generation Intel® Core™/Pentium®/Celeron® Processor, up to 2 NMS and 2 PCIe slots

Entry-level network appliances

The compact and fanless network appliances are designed to meet the most cost-performance efficient and environmentally-friendly networking requirements for mainstream security applications.
iEi PUZZLE-3032 desktop network appliance

PUZZLE-3032

Desktop Network Appliance with Intel® Atom® Processor C3000 Processor, with 8 x 2.5 GbE and 2 x 10 GbE, 1 x eMMC 64GB
iEi PUZZLE-3034 desktop network appliance

PUZZLE-3034

Desktop Network Appliance with Intel® Atom® Processor C3000 Processor, with 8 x 2.5 GbE and 4 x 10 GbE, 1 x eMMC 64GB
PUZZLE-IN003A Desktop Network Appliance

PUZZLE-IN003A

Desktop Network Appliance with Intel® Atom® Processor C3000 Processor, up to 8 x 1 GbE on Board with 2 (by sku) bypass segments, 1 x eMMC 32GB
PUZZLE-IN003B compact network firewall appliance for SMB

PUZZLE-IN003B

Desktop Network Appliance with Intel® Atom® Processor C3000 Processor support up to 6 x 1 GbE, 2 x 10 GbE & 2 x M.2 slots, 1 x PCIe Mini, 1 x eMMC 32GB

ARM-based network appliances

The ARM-based network appliance can be expanded by open source applications supported in the OpenWrt community. It is ideally suited for a wide range of applications, such as SOHO and SMB networking infrastructure.
PUZZLE-M801 Network Appliance

PUZZLE-M801

1U Rackmount Network Appliance with Marvell® Armada® 8040 ARM v8 A72 quad-core System-on-Chip
PUZZLE-M902_Software-Defined-Router

PUZZLE-M902

軟體定義路由器
PUZZLE-M901 Software Defined Router for Small and Medium Business

PUZZLE-M901

軟體定義路由器
ARM-based network appliances
PUZZLE-100 Right
icon-new

PUZZLE-100

Desktop network appliance with Marvell Armada 7040 CPU
儲存伺服器

Intel® CPU

IEI 為公司提供值得信賴的機架式儲存伺服器系統,支援多樣操作系統。我們的儲存伺服器系列有1U、2U、3U規格,支援 4到30驅動器托架。
-支援RAID系統
-具備10GbE網路支援
-可擴充的儲存系統。
[更多關於GRAND系列儲存伺服器]

CPU
Chipset
Rack Height
Form factor
Controller chip
Ethernet
Speed
PCIe
Supported device

GRAND-GL

Intel® Celeron® J4125 Processor (4M Cache, up to 2.70 GHz)
Intel® Celeron® J4125 quad-core 2.0 GHz processor with AES-NI Encryption
Intel® Celeron® J4125 quad-core 2.0 GHz processor with AES-NI Encryption
SoC
SoC
1U, 4Bay
1U, 4Bay

AMD® CPU

IEI 為公司提供值得信賴的機架式儲存伺服器系統,支援多樣操作系統。我們的儲存伺服器系列有1U、2U、3U規格,支援 4到30驅動器托架。
-支援RAID系統
-具備10GbE網路支援
-可擴充的儲存系統。
[更多關於GRAND系列儲存伺服器]

CPU
Chipset
Rack Height
Form factor
Controller chip
Ethernet
Speed
PCIe
Supported device

GRAND-RE

AMD Ryzen™ Embedded V1500B quad-core 2.2 GHz processor
AMD Ryzen™ Embedded V1500B quad-core 2.2 GHz processor
AMD Ryzen™ Embedded V1500B quad-core 2.2 GHz processor
SoC
SoC
2U, 8Bay
2U, 8Bay
Network Module

100GbE Network Module

100GbE Smart NIC Module with Intel®  Chipset

[PulM Series Selection Guide]

CPU
Chipset
Rack Height
Form factor
Controller chip
Ethernet
Speed
PCIe
Supported device
PulM-100G2SF-E810 100GbE Network Module

PulM-100G2SF

Intel® Ethernet Controller EZE810CAM2 based Network Interface Card with 2 x QSFP28 by 1 PCIe 4.0 x8 interface
Intel® Ethernet Controller EZE810CAM2
Intel® Ethernet Controller EZE810CAM2
2 x QSFP28
2 x QSFP28
100 GbE
100 GbE
1 PCIe 4.0 x8
1 PCIe 4.0 x8

PulM-100G2SF-CX6

Mellanox ConnectX-6 Lx based Network Interface Card with 2 x QSFP28 by 1 PCIe 4.0 x16 interface
Mellanox ConnectX-6 Dx
Mellanox ConnectX-6 Dx
2 x QSFP28
2 x QSFP28
1/10/25/40/50/100 Gb/s
1/10/25/40/50/100 Gb/s
1 PCIe 4.0 x16
1 PCIe 4.0 x16

25GbE Network Module

25GbE Smart NIC Module with Mellanox®  Chipset

[PulM Series Selection Guide]

CPU
Chipset
Rack Height
Form factor
Controller chip
Ethernet
Speed
PCIe
Supported device

PulM-25G2SF

Mellanox ConnectX-4 Lx based Network Interface Card support Dual 25GbE with 2 x SFP28 and PCIe 3.0 x8 Interface
Mellanox ConnectX-4 Lx EN
Mellanox ConnectX-4 Lx EN
2 x SFP+ (SFP28)
2 x SFP+ (SFP28)
25GbE
25GbE
PCIe 3.0 x8
PCIe 3.0 x8

10GbE Network Module

10GbE Smart NIC Module with Intel®, Mellanox® and AQUANTIA® Chipset

[PulM Series Selection Guide]

CPU
Chipset
Rack Height
Form factor
Controller chip
Ethernet
Speed
PCIe
Supported device
PulM-10G2SF-X710 網路介面控制器

PulM-10G2SF

Intel® Ethernet Controller X710-BM2 based Network Interface Card with 2 x SFP+ by PCIe 3.0 x8 interface
Intel® Ethernet Controller X710-BM2
Intel® Ethernet Controller X710-BM2
2 x SFP+
2 x SFP+
10GbE
10GbE
PCIe 3.0 x8
PCIe 3.0 x8

PulM-10G4SF

Intel® Ethernet Controller XL710-BM1 based Network Interface Card with four 10GbE Fiber ports, two pair Bypass.
Intel® Ethernet Controller XL710-BM1
Intel® Ethernet Controller XL710-BM1
4 x SFP+
4 x SFP+
10GbE
10GbE
PCIe 3.0 x8
PCIe 3.0 x8

PulM-10G4SF-XL710

Intel® Ethernet Controller XL710-BM1 based Network Interface Card with 4 x SFP+ by 1 PCIe 3.0 x8 interface
Intel® Ethernet Controller XL710-BM1
Intel® Ethernet Controller XL710-BM1
4 x SFP+
4 x SFP+
10GbE
10GbE
PCIe 3.0 x8
PCIe 3.0 x8

PulM-10G4T

Aquantia AQC107 based Network Interface Card with 4 x 10GBASE-T by 4 PCIe 3.0 x2 Interface
Aquantia AQC107
Aquantia AQC107
4 x 10GBASE-T
4 x 10GBASE-T
10GbE
10GbE
4 PCIe 3.0 x2
4 PCIe 3.0 x2

1GbE 模組化網路介面控制器

1GbE Smart NIC Module with Intel®, Mellanox®, BROADCOM® and AQUANTIA® Chipset
CPU
Chipset
Rack Height
Form factor
Controller chip
Ethernet
Speed
PCIe
Supported device

PulM-1G4SF

Intel® Ethernet Controller I350-AM4 based Network Interface Card with  4 x SFP by 2 PCIe 2.0 x4 interface.
Intel Ethernet Controller I350-AM4
Intel Ethernet Controller I350-AM4
4 x SFP
4 x SFP
1 GbE
1 GbE
2 PCIe 2.0 x4
2 PCIe 2.0 x4

PulM-1G4T-I350

Intel® Ethernet Controller I350-AM4 based Network Interface Card with 4 x RJ-45 by 2 PCIe 2.0 x4 interface, RoHS
Intel® Ethernet Controller I350-AM4
Intel® Ethernet Controller I350-AM4
4 x RJ45
4 x RJ45
1 GbE
1 GbE
2 PCIe 2.0 x4
2 PCIe 2.0 x4
PulM-1G8SF-I350 network interface controller

PulM-1G8SF

Intel® Ethernet Controller I350-AM4 based Network Interface Card with 8 x SFP by 2 PCIe 2.0 x4 interface, RoHS
Intel® Ethernet Controller I350-AM4
Intel® Ethernet Controller I350-AM4
8 x SFP
8 x SFP
1 GbE
1 GbE
2 PCIe 2.0 x4
2 PCIe 2.0 x4

PulM-1G8T-BCM5720

Broadcom BCM5720 based Network Interface Card with 8 x RJ-45 by 4 PCIe 2.0 x 2 Interface
Broadcom BCM5720
Broadcom BCM5720
8 x RJ45
8 x RJ45
1 GbE
1 GbE
4 PCIe 2.0 x2
4 PCIe 2.0 x2

PulM-1G8T-I350

Intel® Ethernet Controller I350-AM4 based Network Interface Card with 8 x RJ-45 by 2 PCIe 2.0 x4 interface, RoHS
Intel® Ethernet Controller I350-AM4
Intel® Ethernet Controller I350-AM4
8 x RJ45
8 x RJ45
1 GbE
1 GbE
2 PCIe 2.0 x4
2 PCIe 2.0 x4

Other Network Module

Expansion Proprietary Smart NIC Module

[PulM Series Selection Guide]

CPU
Chipset
Rack Height
Form factor
Controller chip
Ethernet
Speed
PCIe
Supported device
IEI PulM-2P1M Network Module

PulM-2P1M

Two Mini-PCIe and One M.2 Expansion Card Support the Wi-Fi or LTE Module, RoHS
● ASM1812 (PCIe Gen2x4 )
● FL1100EX (PCI-E To USB 3.0 (4 Port))
● ASM1812 (PCIe Gen2x4 )
● FL1100EX (PCI-E To USB 3.0 (4 Port))
● 2 x PCIe Mini (PCIe, USB 2.0) with SIM card slots
● 1 x 2230/2242 M.2 B key (PCIe 2.0, USB 3.2 Gen1) with SIM card slot
● 2 x PCIe Mini (PCIe, USB 2.0) with SIM card slots
● 1 x 2230/2242 M.2 B key (PCIe 2.0, USB 3.2 Gen1) with SIM card slot
PUZZLE-IN001,
PUZZLE-IN001A,
PUZZLE-IN004,
PUZZLE-IN005,
PUZZLE-A001,
PUZZLE-A001A
PUZZLE-IN001,
PUZZLE-IN001A,
PUZZLE-IN004,
PUZZLE-IN005,
PUZZLE-A001,
PUZZLE-A001A

PulM-M2-2S

M.2 PCIe SSD expansion card supports two M.2 2280 PCIe NVMe (3.0 x4) SSDs; two PCIe 3.0 x4 host interface
N/A
N/A
N/A
N/A
N/A
N/A
2 PCIe 3.0 x4
2 PCIe 3.0 x4

Network Accelerator Card

Computing Acceleration Smart NIC Module

[PulM Series Selection Guide]

Mustang-QA100 Intel QAT accelerator

Mustang-QA100

Intel® QAT accelerator for Crypto and Compression with lewisburg chipset, PCIe gen3 x16, RoHS
