IEI offers PEMUX PICMG1.3, PICMG 1.0, PCI/PCI EXPRESS, PCISA and ISA backplane. --> Backplane Selection Table

CPU Socket / Chipset

Memory

Display

I/O / Slot

Features

BP-10S

10-slot backplane with ten ISA slots

ISA Slot:10

ISA Slot:10

BP-3S

3-slot backplane with three ISA slots

ISA Slot:3

ISA Slot:3

BP-4S

4-slot backplane with four ISA slots

ISA Slot:4

ISA Slot:4

BP-5S

5-slot backplane with firve ISA slots

ISA Slot:5

ISA Slot:5

BP-6S

6-slot backplane with six ISA slots

ISA Slot:6

ISA Slot:6

BP-7S

7-slot backplane with seven ISA slots

ISA Slot:7

ISA Slot:7

BP-8S

8-slot backplane with eight ISA slots

ISA Slot:8

ISA Slot:8

HPE-3S2

3-slot backplane with one PCI slot and one PCIe x4 slot

PCIe x 4:1
PCI Slot:2

PCIe x 4:1
PCI Slot:2

HPE-4S2

4-slot backplane with two PCI slots and one PCIe x4 slot

PCIe x 4:1
PCI Slot:2

PCIe x 4:1
PCI Slot:2

HPE-5S1

5-slot backplane with four PCI slots

PCI Slot:4

PCI Slot:4

HPE-6S1

6-slot backplane with four PCI slots and one PCIe x4 slot

PCIe x 4:1
PCI Slot:4

PCIe x 4:1
PCI Slot:4

HPE-8S0

7-slot backplane with four PCI slots and two PCIe x1 slots

PCIe x 1:2
PCI Slot:4

PCIe x 1:2
PCI Slot:4

HPXE2-5S1

5-slot PICMG 1.3 backplane for half-size SBC, with two PCI slots and one PCIe x16 slot (x16 signal)

PCIe x 16:1
PCI Slot:2

PCIe x 16:1
PCI Slot:2

HPXE2-8S1

8-slot PICMG 1.3 backplane for half-size SBC, with four PCI

PCIe x 8:2
PCI Slot:4

PCIe x 8:2
PCI Slot:4

IP-10S

10-slot backplane with four PCI slots and five ISA slots

PCI Slot:4
ISA Slot:5

PCI Slot:4
ISA Slot:5

IP-3S

3-slot backplane with two PCI slots

PCI Slot:2

PCI Slot:2

IP-5SA2

5-slot backplane with four PCI slots

PCI Slot:4

PCI Slot:4

IP-6S

6-slot backplane with three PCI slots and two ISA slots

PCI Slot:3
ISA Slot:2

PCI Slot:3
ISA Slot:2

IP-6SA

6-slot backplane with three PCI slots and two ISA slots

PCI Slot:3
ISA Slot:2

PCI Slot:3
ISA Slot:2

PCI-10S

10-slot backplane with four PCI slots and five ISA slots

PCI Slot:4
ISA Slot:5

PCI Slot:4
ISA Slot:5

PCI-12S

12-slot backplane with four PCI slots and seven ISA slots

PCI Slot:4
ISA Slot:7

PCI Slot:4
ISA Slot:7

PCI-14S

14-slot backplane with four PCI slots and nine ISA slots

PCI Slot:4
ISA Slot:9

PCI Slot:4
ISA Slot:9

PCI-5S2A backplane

PCI-5S2A

5-slot ATX power backplane with four PCI slots and one ISA slot

PCI Slot:4
ISA Slot:1

PCI Slot:4
ISA Slot:1

PCI-5SD6

2U chassis backplane with four PCI slots

PCI Slot:L2+R2

PCI Slot:L2+R2

PCI-6S

6-slot backplane with four PCI slots and two ISA slots

PCI Slot:4
ISA Slot:2

PCI Slot:4
ISA Slot:2

PCI-6SD

2U chassis backplane with two PCI slots and two ISA slots

PCI Slot:L1+R1
ISA Slot:L1+R1

PCI Slot:L1+R1
ISA Slot:L1+R1

PCI-7S

7-slot backplane with four PCI slots and three ISA slots

PCI Slot:4
ISA Slot:3

PCI Slot:4
ISA Slot:3

PE-10S

10-slot backplane with one PCIe x16 slot, four PCIe x1 slots and four PCI slots

PCIe x 16:1
PCIe x 1:4
PCI Slot:4

PCIe x 16:1
PCIe x 1:4
PCI Slot:4

PE-10S2

10-slot backplane with one PCIe x16 slot, four PCIe x1 slots and four PCI slots

PCIe x 16:1
PCIe x 1:4
PCI Slot:4

PCIe x 16:1
PCIe x 1:4
PCI Slot:4

PE-2SD1

2-slot backplane with one PCIe slot

PCIe x 16:1

PCIe x 16:1

PE-4S

4-slot backplane with one PCIe x16 slot, one PCIe x4 slot and one PCI slot

PCIe x 16:1
PCIe x 4:1
PCI Slot:1

PCIe x 16:1
PCIe x 4:1
PCI Slot:1

PE-5S

5-slot backplane with one PCIe x16 slot, one PCIe x4 slot and two PCI slots RACK-500G 5U 5-slot full-size

PCIe x 16:1
PCIe x 4:1
PCI Slot:2

PCIe x 16:1
PCIe x 4:1
PCI Slot:2

PE-5S2

5-slot backplane with one PCIe x16 slot and three PCIe x1 slots

PCIe x 16:1
PCIe x 1:3

PCIe x 16:1
PCIe x 1:3

PE-6S

6-slot backplane with one PCIe x16 slot, two PCIe x1 slots and two PCI slots

PCIe x 16:1
PCIe x 1:2
PCI Slot:2

PCIe x 16:1
PCIe x 1:2
PCI Slot:2

PE-6S2

6-slot backplane with one PCIe x16 slot, one PCIe x4 slot and three PCI slots

PCIe x 16:1
PCIe x 4:1
PCI Slot:3

PCIe x 16:1
PCIe x 4:1
PCI Slot:3

PE-6SD

5-slot backplane with one PCIe x16 slot and three PCIe x1 slots

PCIe x 16:1
PCIe x 1:3

PCIe x 16:1
PCIe x 1:3

PE-6SD3

5-slot backplane with one PCIe x16 slot, one PCIe x4 slot and two PCI slots

PCIe x 16:1
PCIe x 4:1
PCIe x 1:3
PCI Slot:2

PCIe x 16:1
PCIe x 4:1
PCIe x 1:3
PCI Slot:2

PE-7S

7-slot backplane with one PCIe x16 slot, two PCIe x1 slots and three PCI slots

PCIe x 16:1
PCIe x 1:2
PCI Slot:3

PCIe x 16:1
PCIe x 1:2
PCI Slot:3

PE-8S

8-slot backplane with one PCIe x16 slots, three PCIe x1 slots and three PCI slots

PCIe x 16:1
PCIe x 1:3
PCI Slot:3

PCIe x 16:1
PCIe x 1:3
PCI Slot:3

PE-9S

9-slot backplane with one PCIe x16 slot, four PCIe x1 slots and three PCI slots

PCIe x 16:1
PCIe x 1:4
PCI Slot:3

PCIe x 16:1
PCIe x 1:4
PCI Slot:3

PXE-11S1

PICMG 1.3 Passive Backplane

1 x PCIe x16 (x8 signal)
1 x PCIe x1
3 x PCIe x4 (x4 signal)
1 x PCIe x4 (x2 signal)
4 x PCI Slots
1 x M.2 A key

1 x PCIe x16 (x8 signal)
1 x PCIe x1
3 x PCIe x4 (x4 signal)
1 x PCIe x4 (x2 signal)
4 x PCI Slots
1 x M.2 A key

PXE-13S

13-slot backplane with one PCIe x16 slot, three PCIe x1 slots and eight PCI slots

PCIe x 16:1
PCIe x 1:3
PCI Slot:8

PCIe x 16:1
PCIe x 1:3
PCI Slot:8

PXE-14S1

PICMG 1.3 Passive Backplane

1 x PCIe x16（Gen3 x16 signal）
12 x PCI

1 x PCIe x16（Gen3 x16 signal）
12 x PCI

SPE-6S

6-Slot PICMG 1.3 PCIe to PCI Bridge Backplane,5 PCIe x4,RoHS

PCIe x 4:5

PCIe x 4:5

SPE-9S

7-Slot PICMG 1.3 PCIe to PCI Bridge Backplane,1 PCIe x8 w/ x16 slots,3 PCIe x4,3 PCI,RoHS

PCIe x 8:1
PCIe x 4:3
PCI Slot:3

PCIe x 8:1
PCIe x 4:3
PCI Slot:3

SPXE-11S

IEI Server Grade Backplane Solution, PICMG 1.3 Backplane for 4U rack-mount chassis

2 x PCIE x4 from CPU
1 x PCIE x4 from PCH
Slot type: X4 signal with X16 slot
3 x PCIE x4 from CPU via PLX8724
Slot type: X4 signal with X16 slot
4 x PCI from CPU card

2 x PCIE x4 from CPU
1 x PCIE x4 from PCH
Slot type: X4 signal with X16 slot
3 x PCIE x4 from CPU via PLX8724
Slot type: X4 signal with X16 slot
4 x PCI from CPU card

2 x ATX power connector (24pin + 4pin)
Power LED
1 x IOPWR (20 pin)
1 x SM BUS connector (2 pin)
1 x PWRGD connector (2 pin)
1 x Reset connector (2 pin)
1 x PWRBTN connector (2 pin)
4 x Fan connector (3 pin)
1 x ATXCTL connector (3 pin)
Mounting hole compatible with PCI-14S

2 x ATX power connector (24pin + 4pin)
Power LED
1 x IOPWR (20 pin)
1 x SM BUS connector (2 pin)
1 x PWRGD connector (2 pin)
1 x Reset connector (2 pin)
1 x PWRBTN connector (2 pin)
4 x Fan connector (3 pin)
1 x ATXCTL connector (3 pin)
Mounting hole compatible with PCI-14S

SPXE-14S

14-Slot PICMG 1.3 PCIe to PCI Bridge Backplane,1 PCIe x8 w/ x16 slot,12 PCIe x1,RoHS

PCIe x 8:1
PCIe x 1:12

PCIe x 8:1
PCIe x 1:12
