Embedded Computer

DP-HDMI

DisplayPort to HDMI™ 1.3a Converter Board (for IEI iDP DP-HDMI™-R10 connector)

IEI iDP connector

DP-LVDS

DisplayPort to 24-bit Dual-channel LVDS Converter Board DP-LVDS-R10 (for IEI iDP Connector)

1 x IEI iDP connector

iDPM-eDP

eDP to eDP Connector converter board (Only for IEI iDPM slot)

1 x eDP connect

iDPM-LVDS

eDP to LVDS Connector converter board (Only for IEI iDPM slot)

1 x LVDS connect

iDPM-VGA

eDP to VGA Connector converter board (Only for IEI iDPM slot)

1 x VGA pin-header

산업용 통신 카드

IEI provides industrial communication cards for different expasion and application through ISA, PCI or PCI Express.

CPU Socket / Chipset

Memory

Display

I/O / Slot

Features

GPOE-2P

PCI Express Power over Ethernet card, 2-port 1000 Base(T), 802.3at compliant, low profile, RoHS

1. PCI Express® x1 compliant
2. Support IEEE 802.3at for PoE (Power over Ethernet) with 30 watts per port
3. Support link aggregation/jumbo frames (9 Kbyte)
4. Supports 12V~24V DC input power

GPOE-4P

PCI Express Power over Ethernet card, 4-port 1000 Base(T), 802.3at/af compliant, low profile, RoHS

1. PCI Express® x1 compliant
2. Support for total 90 watts under full load
3. Support link aggregation/jumbo frames (9 Kbyte)
4. Supports 12V~24V DC input power

GPOE-6P

PCI Express Power over Ethernet card, 6-port 1000 Base(T), 802.3at / bt compliant, RoHS

1. Provide 6 x10/100/1000Base-T(X) PoE (P.S.E.) ports
2. Total 180 Watts power budget with maximum 90 Watts per port
3. PoE power sourced from 12 ~ 24VDC of ATX power
4. Each LAN port supports both PoE and Non-PoE connections (Auto Detect & Classification)
5. Supports SW/RDK (IEI GPOE Management Software Tools)
6. Compatible with x4, x8 and x16 PCIe slots
7. IEEE 802.3at/bt PoE compliant

GPOE-XM81

8-Port PoE LAN Card

● 8 x PCI Express® x1 (TANK-XM81 series customization)
● Support IEEE 802.3at for PoE (Power over Ethernet) with 30 watts per port
● Support link aggregation/jumbo frames (9 Kbyte)

LAN-100G2SF

Intel® Ethernet Controller E810 based Network Interface Card 2 x 100GbE with 2 x QSFP28, PCIe 4.0 x 16 interface.

TXIOB-XM81-A

Expansion IO Board Module

● 8 x PCI Express® x1 (TANK-XM81 series customization)
● Support Full-Size PCIe Mini
● Support M.2 A Key 2230
● Support M.2 B Key 3042/52/80 with SIM Slot

무선 모듈

PCIe Mini card *Solid design with external antenna diversity *Low power consumption and high performance

CPU Socket / Chipset

Memory

Display

I/O / Slot

Features

EMB-WIFI-KIT

PCIe Mini card wireless LAN module kit

● Half size PCIe Mini card form factor
● High speed wireless connection
● Low power consumption and high performance
● Fully qualified Bluetooth 4.0
● Solid design with external antenna diversity

EMB-WIFI-KIT02I3

M.2 A/E Key WI-FI 6E module kit

● M.2 2230 AE Key form factor
● High speed wireless connection,WI-FI 6E
● Low power consumption and high performance
● Fully qualified Bluetooth 5.2
● Solid design with external antenna diversity

미니 PCIe 모듈

PCI Express Mini Card *IO Interface converter *RoHs

CPU Socket / Chipset

Memory

Display

I/O / Slot

Features

IGCME-1300

PCIe Mini VGA Adapter Card,

PCI Express Mini card

1 x 10-pin (2x5) box header by 2.0mm pitch

MPCIE-3G

PCI Express Mini 3G Adapter Card, RoHS

PCI Express Mini card
Antenna 50Ohms. Main GSM/UMTS antenna
USB 2.0 High Speed (480Mbit/s) device
interface, Full Speed (12Mbit/s)

MPCIE-DLAN

PCI Express Mini Dual Intel® GbE LAN Module, Full Size

PCI Express Mini GbE LAN Module

MPCIE-LAN

PCI Express Mini GbE LAN Module, Full Size

PCI Express mini card

MPCIE-UART-KIT01

PCI Express Mini Card Supports Quad-port RS-232/422/485, Full Size

PCI Express Mini Card

MPCIE-UART-KIT02

PCI Express Mini Card Supports Dual-port RS-232/422/485, 16-bit GPIO, Full Size

PCI Express Mini Card

TPM 모듈

Hardware-based security solution for data protection and reliable authentication via TPM that stores key, passwords and digital certificates.

CPU Socket / Chipset

Memory

Display

I/O / Slot

Features

TPM-IN01

Hardware-based security solution for data protection and reliable authentication via TPM that stores key, passwords and digital certificates.

1. TPM management
2. File & Folder En/De-cryption
3. Personal secure drive
4. Secure Email
5. Key transferring
6. Security policy configuration

TPM-IN02

Hardware-based security solution for data protection and reliable authentication via TPM that stores key, passwords and digital certificates.

1. TPM management
2. File & Folder En/De-cryption
3. Personal secure drive
4. Secure Email
5. Key transferring
6. Security policy configuration

TPM-IN03

SPI TPM 2.0 module, software management tool

Infineon SPI TPM 2.0 with SLB9670VQ2.0 FW7.85

SPI TPM 2.0 module, software management tool, firmware v7.85

Audio Kit

Audio Board

CPU Socket / Chipset

Memory

Display

I/O / Slot

Features

AC-KIT-888S

Realtek ALC888S 7.1 Channel HD Audio peripheral board,RoHS

Realtek ALC888S HD Audio codec

1 x Mic-in connector
1 x Line-in connector
1 x Front-out connector
1 x Rear-out connector
1 x Center/Subwoofer connector

1. Realtek ALC888S HD Audio codec IC supported
2. Five audio jacks for microphone, 7.1+2-channel high definition audio input and output
3. High performance 7.1+2-channel high definition audio board provides 7.1-channel sound playback and multiple streaming through the front panel stereo outputs
4. Digital to Analog Converter (DAC) with 97dB Signal to Noise Ratio (SNR)
5. Analog to Digital Converter (ADC) with 90dB Signal to Noise Ratio (SNR)
6. All the Digital to Analog Converter (DAC) supports 44.1k/48k/96k/192kHz sampling rate
7. All the Analog to Digital Converter (ADC) supports 44.1k/48k/88.2k/96k/192kHz sample rate
8. Driver supports Windows® 2000/2003/XP/Vista/7/10 (32/64 bits) and Linux (Ubuntu or Debian)
9. CE/FCC compliant
