Panel PC & Monitor

IEI panel PCs & monitors offer cost-effective, stable and easy to use solution to collect, transfer, process and manage data.
比較狀態 :
已設定.要比較機種數 :
已設定.要比較機種 :
列表區塊.Now 位置狀態 :
列表區塊.單位區塊寬 :
列表區塊.Now X 位置 :
列表區塊.目標 X 位置 :
顯示框寬 :
列表寬 :
Heavy Industrial Panel PC
Modular Panel PC
* 15”~24" Panel PC with 8th Generation LGA 1151 Intel® Core™ i7/i5/i3
and Pentium® processor
* Four hot-swappable and accessible HDD drive bays, support RAID
0/1/5/10
* Two PCIe 3.0 by 4 and two PCIe 3.0 by 8 slots
* Dual M.2 2280 PCIe Gen 3.0 x4 NVMe™ SSD support
CPU / Chipset
Display
Expansion
I/O
Features

PPC-F15D-ULT5

15” 8th gen Intel® Whiskey Lake-U Industrial Panel PC
8th Genertion Intel® Core™ i5-8365U 4.10GHz
8th Genertion Intel® Celeron® 4305U 2.20GHz, Intel® Whiskey Lake-U
LCD Size: 15”
Brightness(cd/m2): 450
Max Resolution: 1024 x 768
M.2 2230 A-Key(PCIe x1, USB 2.0; support Wi-Fi, BT)
M.2 2280 M-Key(PCIe x4; support NVMe SSD)
1 x HDMI
3 x LAN:: 2 x Support PoE(IEEE 802.3at/bt, optional)
4 x USB 3.2 Gen2x1
2 x RS-232:: 1 x RS-232/422/485, 1 x RS-232
1 x Line out
1 x DC Input Jack:: 12V Din 4Pin/lock
1 x Power Switch:: with LDE(Blue)
1 x Reset Button
1 x AT/ATX Switch
1 x Clear CMOS

PPC-F17C-Q370

17” Intel® Coffee Lake panel PC
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370
LCD Size: 17”
Brightness(cd/m2): 350
Max Resolution: 1280x1024
2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm)
6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch

PPC-F17D-ULT5

17” 8th gen Intel® Whiskey Lake-U Industrial Panel PC
8th Genertion Intel® Core™ i5-8365U 4.10GHz
8th Genertion Intel® Celeron® 4305U 2.20GHz, Intel® Whiskey Lake-U
LCD Size: 17”
Brightness(cd/m2): 350
Max Resolution: 1280 x 1024
M.2 2230 A-Key(PCIe x1, USB 2.0; support Wi-Fi, BT)
M.2 2280 M-Key(PCIe x4; support NVMe SSD)
1 x HDMI
3 x LAN:: 2 x Support PoE(IEEE 802.3at/bt, optional)
4 x USB 3.2 Gen2x1
2 x RS-232:: 1 x RS-232/422/485, 1 x RS-232
1 x Line out
1 x DC Input Jack:: 12V Din 4Pin/lock
1 x Power Switch:: with LDE(Blue)
1 x Reset Button
1 x AT/ATX Switch
1 x Clear CMOS

PPC-FW15C-Q370

15.6” Intel® Coffee Lake panel PC
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370
LCD Size: 15.6”
Brightness(cd/m2): 400
Max Resolution: 1366x768
2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm)
6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch

PPC-FW15D-ULT5

15.6” 8th gen Intel® Whiskey Lake-U Industrial Panel PC
8th Genertion Intel® Core™ i5-8365U 4.10GHz
8th Genertion Intel® Celeron® 4305U 2.20GHz, Intel® Whiskey Lake-U
LCD Size: 15.6”
Brightness(cd/m2): 400
Max Resolution: 1366 x 768
M.2 2230 A-Key(PCIe x1, USB 2.0; support Wi-Fi, BT)
M.2 2280 M-Key(PCIe x4; support NVMe SSD)
1 x HDMI
3 x LAN:: 2 x Support PoE(IEEE 802.3at/bt, optional)
4 x USB 3.2 Gen2x1
2 x RS-232:: 1 x RS-232/422/485, 1 x RS-232
1 x Line out
1 x DC Input Jack:: 12V Din 4Pin/lock
1 x Power Switch:: with LDE(Blue)
1 x Reset Button
1 x AT/ATX Switch
1 x Clear CMOS

PPC-FW19C-Q370

18.5” Intel® Coffee Lake panel PC
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370
LCD Size: 18.5”
Brightness(cd/m2): 400
Max Resolution: 1366x768
2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm)
6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch

PPC-FW19D-ULT5

18.5” 8th gen Intel® Whiskey Lake-U Industrial Panel PC
8th Genertion Intel® Core™ i5-8365U 4.10GHz
8th Genertion Intel® Celeron® 4305U 2.20GHz, Intel® Whiskey Lake-U
LCD Size: 18.5”
Brightness(cd/m2): 400
Max Resolution: 1366 x 768
M.2 2230 A-Key(PCIe x1, USB 2.0; support Wi-Fi, BT)
M.2 2280 M-Key(PCIe x4; support NVMe SSD)
1 x HDMI
3 x LAN:: 2 x Support PoE(IEEE 802.3at/bt, optional)
4 x USB 3.2 Gen2x1
2 x RS-232:: 1 x RS-232/422/485, 1 x RS-232
1 x Line out
1 x DC Input Jack:: 12V Din 4Pin/lock
1 x Power Switch:: with LDE(Blue)
1 x Reset Button
1 x AT/ATX Switch
1 x Clear CMOS
Fanless Panel PC
IEI is dedicated to developing impeccable industrial panel PC products.The PPC and PPC-F series industrial panel PCs not only keep rugged design of IP65 protection but also enrich aesthetic experience by implementing the seamless mounting method. The projected capacitive touch option is added to these new series of products to provide up to 2 points multi-touch solution! Additionally, we also provide high performance H81 series and low power consumption Bay Trail series to meet customers’requests.
CPU / Chipset
Display
Expansion
I/O
Features

PPC-F08B-BT

5.7”/8”/10.4” Fanless Intel® Bay Trail Solution
Intel® Celeron® J1900 quad-core on-board SoC, 2GHz LCD Size:8”(4:3)
Brightness(cd/m2):500
Max Resolution:800(W) x 600(H)
Expansion Slots:1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)
1 x Half-size PCIe Mini slot for Wi-Fi modules
2 x LAN ((GbE))
1 x Power Switch
1 x RS-232 ((RJ-45))
1 x RS-422/485 ((DB-9))
1 x Reset Button
2 x USB2.0
2 x USB3.0
1 x AT/ATX Switch
1 x Audio (((line-out)))
1 x Power In ((9-30V Lockable power jack))

PPC-F10B-BT

5.7”/8”/10.4” Fanless Intel® Bay Trail Solution
Intel® Celeron® J1900 quad-core on-board SoC, 2GHz LCD Size:10.4”
Brightness(cd/m2):400
Max Resolution:800(W) x 600(H)
Expansion Slots:1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)
1 x Half-size PCIe Mini slot for Wi-Fi modules
2 x LAN ((GbE))
1 x Power Switch
1 x RS-232 ((RJ-45))
1 x RS-422/485 ((DB-9))
1 x Reset Button
2 x USB2.0
2 x USB3.0
1 x AT/ATX Switch
1 x Audio (((line-out)))
1 x Power In ((9-30V Lockable power jack))

PPC-F12B-BT

12” Fanless Intel® Bay Trail Solution
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) LCD Size:12.1""""(4:3)
Brightness(cd/m2):600
Max Resolution:1024 (W) x 768 (H)
1 x Full-size PCIe Mini card slot (with PCIe and USB signal)
1 x Full-size PCIe Mini card slot co-lay mSATA (SATA2 only) (with PCIe and USB signal)
2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out (PPC-F15B and PPC-17B only)
1 x Power switch

PPC-F15B-BT

15” Fanless Intel® Bay Trail Solution
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) LCD Size:15""""(4:3)
Brightness(cd/m2):400
Max Resolution:1024 (W) x 768 (H)
1 x Full-size PCIe Mini card slot (with PCIe and USB signal)
1 x Full-size PCIe Mini card slot co-lay mSATA (SATA2 only) (with PCIe and USB signal)
2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out (PPC-F15B and PPC-17B only)
1 x Power switch

PPC-F17B-BT

17” Fanless Intel® Bay Trail Solution
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) LCD Size:17""""(5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H)
1 x Full-size PCIe Mini card slot (with PCIe and USB signal)
1 x Full-size PCIe Mini card slot co-lay mSATA (SATA2 only) (with PCIe and USB signal)
2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out (PPC-F15B and PPC-17B only)
1 x Power switch

PPC-F19B-BT

19” Fanless Panel PC Intel® Bay Trail Solution
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz) LCD Size:19” (5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H)
1 x Full-size PCIe Mini slot ( mSATA/PCIe/USB signal)
1 x Full-size/half-size PCIe Mini slot (PCIe/USB signal)
2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out
1 x Power switch
Panel PC with Active Fan
15”~24" Panel PC with active fan
CPU / Chipset
Display
Expansion
I/O
Features

PPC-F15A-H81

Intelligent Industrial Panel PC
LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP LCD Size:15”(4:3)
Brightness(cd/m2):400
Max Resolution:1024 (W) x 768 (H)
1 x Full-size PCIe Mini card
1 x Full-size PCIe Mini card co-lay mSATA (SATA2 only)
2 x RJ-45 LAN Port
2 x USB 3.0
4 x USB 2.0
1 x HDMI output
4 x RS-232
1 x RS-422/485
1 x MIC-in
1 x Line-out
1 x VGA output
1 x AC/DC power plug
(DC model is by build to order manufacturing)
1 x AT/ATX switch
1 x Clear CMOS
1 x Reset button
1 x Power switch

PPC-F17A-H81

Intelligent Industrial Panel PC
LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP LCD Size:17”(5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H)
1 x Full-size PCIe Mini card
1 x Full-size PCIe Mini card co-lay mSATA (SATA2 only)
2 x RJ-45 LAN Port
2 x USB 3.0
4 x USB 2.0
1 x HDMI output
4 x RS-232
1 x RS-422/485
1 x MIC-in
1 x Line-out
1 x VGA output
1 x AC/DC power plug
(DC model is by build to order manufacturing)
1 x AT/ATX switch
1 x Clear CMOS
1 x Reset button
1 x Power switch
