IEI Launched New Desktop Netwok Appliance - PUZZLE-IN003 Series
IEI Event News
banner
Intel® QuickAssist Technology Integrated 10G Interface Bypass Function
Product Info Application

The PUZZLE-IN003 series is a desktop network device that easily places in space limited area. It comes with Intel® Atom® Processor C3000 series System On Chip which supports up to 128GB Dual-channels DDR4 2400 MHz ECC (UDIMM, or RDIMM), 32GB Embedded Multi Media Card (eMMC), and have high speed network data transmission from 6 x 1 GbE to 2 x 10 GbE SFP+.

In order to speed up the network solutions, it also offers Intel® QuickAssist Technology (Intel® QAT up to 20Gbps) to accelerate and compress cryptographic workloads. This series is very suitable for entry level integrator or SME markets.

Key values of PUZZLE-IN003 Series

*1: Only Support PUZZLE-IN003B Series
*2: Only Support PUZZLE-IN003A Series

Network Accelerator - Intel® QuickAssist Technology

In the 5G network, security is an indispensable requirement. The base station must use air interface security to connect to the user equipment (UE), and an IPsec connection to connect to the core network. The base station must support high-performance crypto algorithms like AES at the IP level and ZUC/Kasumi/Snow3G at the PDCP level.

To support these requirements the Intel Atom® C3000 processor series integrates Intel® QuickAssist Technology providing up to 20 Gbps of crypto performance, ensuring secure data transfer while reserving valuable processor cycles for other tasks.

Performance Single Intel® Atom® C3000-NS Solution
SSL 20 Gbps
Bulk Crypto + Authentication 20 Gbps
RSA Decrypt 1024 92K Ops/sec
RSA Decrypt 2048 20K Ops/sec
ZUC/Snow3G/Kasumi F82 12Gbps

Integrated 10G Interface

PUZZLE-IN003B designed with two integrated 10GbE SPF+ network ports providing high-speed connections to the core network while integrated networking helps contribute to the small form-factor design of the base station.


Uninterrupted Data Transmission - Bypass Function

PUZZLE-IN003A supports the bypass function to offer interrupted network traffic service under hardware / software failure status.

pic pic

Product Information
  PUZZLE-IN003A Series PUZZLE-IN003B Series
  PUZZLE-IN003A Series PUZZLE-IN003B Series
CPU Intel® Atom® processor C3000 series, up to 2.20 GHz
Ethernet Port Support up to 8 x 1 GbE RJ45 Support up to 4 x 1 GbE RJ45 & 2 x 10GbE SFP+
Bypass 1 or 2 bypass segments N/A
Memory 2 x DDR4 (by SKU)
R-DIMM 128GB
U-DIMM 64GB
non-ECC/ECC memory
4 x DDR4
R-DIMM 128GB
U-DIMM 64GB
non-ECC/ECC memory
Expansion 1 x M.2 A key (USB 2.0, PCIe x1), 1 x miniPCIe (USB 2.0, PCIe x1) with SIM card slot,
1 x eMMC 32GB
