Panel PC & Monitor

IEI panel PCs & monitors offer cost-effective, stable and easy to use solution to collect, transfer, process and manage data.
  • 製品一覧
    • >
  • パネルアプライアンス & モニタ
    • >
比較狀態 :
已設定.要比較機種數 :
已設定.要比較機種 :
列表區塊.Now 位置狀態 :
列表區塊.單位區塊寬 :
列表區塊.Now X 位置 :
列表區塊.目標 X 位置 :
顯示框寬 :
列表寬 :
重工業向けパネコン
オリジナルモジュール化モデル
* 15”~24" Panel PC with 8th Generation LGA 1151 Intel® Core™ i7/i5/i3
and Pentium® processor
* Four hot-swappable and accessible HDD drive bays, support RAID
0/1/5/10
* Two PCIe 3.0 by 4 and two PCIe 3.0 by 8 slots
* Dual M.2 2280 PCIe Gen 3.0 x4 NVMe™ SSD support
CPU / Chipset
Display
Expansion
I/O
Features

PPC-F15C-Q370

15” Intel® Coffee Lake panel PC
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ...
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370
LCD Size: 15”
Brightness(cd/m2): 450
Max Resolution: 1024x768
LCD Size: 15”
Brightness(cd/m2): 450
Max Resolution: 1024x768
2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ...
2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm)
6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ...
6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
View Products

PPC-F17C-Q370

17” Intel® Coffee Lake panel PC
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ...
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370
LCD Size: 17”
Brightness(cd/m2): 350
Max Resolution: 1280x1024
LCD Size: 17”
Brightness(cd/m2): 350
Max Resolution: 1280x1024
2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ...
2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm)
6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ...
6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
View Products

PPC-FW15C-Q370

15.6” Intel® Coffee Lake panel PC
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ...
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370
LCD Size: 15.6”
Brightness(cd/m2): 400
Max Resolution: 1366x768
LCD Size: 15.6”
Brightness(cd/m2): 400
Max Resolution: 1366x768
2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ...
2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm)
6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ...
6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
View Products

PPC-FW19C-Q370

18.5” Intel® Coffee Lake panel PC
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ...
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370
LCD Size: 18.5”
Brightness(cd/m2): 400
Max Resolution: 1366x768
LCD Size: 18.5”
Brightness(cd/m2): 400
Max Resolution: 1366x768
2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ...
2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm)
6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ...
6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
View Products

PPC-FW22C-Q370

21.5” Intel® Coffee Lake panel PC
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ...
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370
LCD Size: 21.5”
Brightness(cd/m2): 250
Max Resolution: 1920x1080
LCD Size: 21.5”
Brightness(cd/m2): 250
Max Resolution: 1920x1080
2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ...
2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm)
6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ...
6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
View Products

PPC-FW24C-Q370

23.8” Intel® Coffee Lake panel PC
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPUIntel® 300 Ser ...
8th Generation LGA1151 Intel® Core™ i7/i5/i3 and Pentium® CPU
Intel® 300 Series Chipsets Q370
LCD Size: 23.8”
Brightness(cd/m2): 250
Max Resolution: 1920x1080
LCD Size: 23.8”
Brightness(cd/m2): 250
Max Resolution: 1920x1080
2 x PCIe 3.0 by 8 (by 16 slot)2 x PCIe 3.0 by 4 (maximum card size supporte ...
2 x PCIe 3.0 by 8 (by 16 slot)
2 x PCIe 3.0 by 4 (maximum card size supported: 68 mm x 167 mm)
6 x USB 3.02 x RS-2322 x LAN1 x HDMI1 x Mic1 x Line out1 x Power switch1 x ...
6 x USB 3.0
2 x RS-232
2 x LAN
1 x HDMI
1 x Mic
1 x Line out
1 x Power switch
1 x Reset Button
1 x AT/ATX Switch
View Products

耐久性抜群堅牢モデル
Including UPC series panel PCs amd INOX.
*Fanless Design
*Sturdy & Durable
*High Waterproof Grade
CPU / Chipset
Display
Expansion
I/O
Features

INOX-F15C-ULT3

Intel® Core™ i5 and Celeron® ULT Processor
6th generation Intel® Core™ i5 and Celeron® ULT processor,Intel® Skylake UL ...
6th generation Intel® Core™ i5 and Celeron® ULT processor,Intel® Skylake ULT
15” LCD
Brightness (cd/m²): 450
Max Resolution: 1024 x 768
15” LCD
Brightness (cd/m²): 450
Max Resolution: 1024 x 768
1 x Full-size PCIe Mini card slot (SATA 6Gb/s)1 x Full-size/half-size (PCIe ...
1 x Full-size PCIe Mini card slot (SATA 6Gb/s)
1 x Full-size/half-size (PCIe x1 and USB 2.0 signals)
1 x M.2 B-key slot (2242/2260/2280 with USB 3.0, PCIe x2 and SATA signals)
2 x 8-pin M12 connector for RS-232/422/4852 x 8-pin M12 X-Code connector fo ...
2 x 8-pin M12 connector for RS-232/422/485
2 x 8-pin M12 X-Code connector for GbE LAN
2 x 8-pin M12 connector for two USB 2.0
1 x 5-pin M12 connector for DC jack (9-36V DC)
1 x Power switch with power LED indicator
1 x Pressure relief valve
View Products

UPC-F12C-ULT3

Vertical Market Panel PC
6th generation Intel® Core™ i5 and Celeron® ULT processor, SOC
6th generation Intel® Core™ i5 and Celeron® ULT processor, SOC
12.1”, 600nits, 1024x768
12.1”, 600nits, 1024x768
1 x M.2 (B key 2242 with USB 2.0 and SATA signal)
1 x M.2 (B key 2242 with USB 2.0 and SATA signal)
M12 Type:1 x 8-pin M12 connector for RS-2321 x 8-pin M12 connector for RS-2 ...
M12 Type:
1 x 8-pin M12 connector for RS-232
1 x 8-pin M12 connector for RS-232/422/485
1 x 8-pin M12 connector for GbE LAN
2 x 8-pin M12 connector for two USB 2.0
1 x 5-pin M12 connector for DC jack (12V~36V DC)

Standard Type:
1 x DC jack (12V-36V DC)
1 x DC-in terminal block
(12V-36V DC)
1 x HDMI
1 x VGA
1 x RS-232 (COM1 RJ-45)
1 x RS-232/422/485 (COM2 RJ-45)
2 x LAN
2 x USB 2.0
2 x USB 3.0
View Products

ファンレスモデル
IEI is dedicated to developing impeccable industrial panel PC products.The PPC and PPC-F series industrial panel PCs not only keep rugged design of IP65 protection but also enrich aesthetic experience by implementing the seamless mounting method. The projected capacitive touch option is added to these new series of products to provide up to 2 points multi-touch solution! Additionally, we also provide high performance H81 series and low power consumption Bay Trail series to meet customers’requests.
CPU / Chipset
Display
Expansion
I/O
Features

PPC-F06B-BT

5.7”/8”/10.4” Fanless Intel® Bay Trail Solution
IntelR CeleronR N2807
dual-core processor, 1.58GHz
IntelR CeleronR N2807
dual-core processor, 1.58GHz
LCD Size:5.7”(4:3)
Brightness(cd/m2):550
Max Resolution:640(W) x 480(H)
LCD Size:5.7”(4:3)
Brightness(cd/m2):550
Max Resolution:640(W) x 480(H)
Expansion Slots:1 x Full-size PCIe Mini slot
(with mSATA, PCIe/USB signal)
Expansion Slots:1 x Full-size PCIe Mini slot
(with mSATA, PCIe/USB signal)
1 x LAN ((RJ-45)) 1 x Power Switch 1 x RS-232 (((DB-9))) 1 x RS-422/485 1 x ...
1 x LAN ((RJ-45))
1 x Power Switch
1 x RS-232 (((DB-9)))
1 x RS-422/485
1 x Reset Button
2 x USB2.0
2 x USB3.0
1 x AT/ATX Switch
1 x Audio (((line-out)))
1 x Power In ((9-30V Lockable power jack))
View Products

PPC-F08B-BT

5.7”/8”/10.4” Fanless Intel® Bay Trail Solution
IntelR CeleronR J1900 quad-core on-board SoC, 2GHz
IntelR CeleronR J1900 quad-core on-board SoC, 2GHz
LCD Size:8”(4:3)
Brightness(cd/m2):500
Max Resolution:800(W) x 600(H)
LCD Size:8”(4:3)
Brightness(cd/m2):500
Max Resolution:800(W) x 600(H)
Expansion Slots:1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)1 ...
Expansion Slots:1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)
1 x Half-size PCIe Mini slot for Wi-Fi modules
2 x LAN ((GbE)) 1 x Power Switch 1 x RS-232 ((RJ-45)) 1 x RS-422/485 ((DB-9 ...
2 x LAN ((GbE))
1 x Power Switch
1 x RS-232 ((RJ-45))
1 x RS-422/485 ((DB-9))
1 x Reset Button
2 x USB2.0
2 x USB3.0
1 x AT/ATX Switch
1 x Audio (((line-out)))
1 x Power In ((9-30V Lockable power jack))
View Products

PPC-F10B-BT

5.7”/8”/10.4” Fanless Intel® Bay Trail Solution
IntelR CeleronR J1900 quad-core on-board SoC, 2GHz
IntelR CeleronR J1900 quad-core on-board SoC, 2GHz
LCD Size:10.4”
Brightness(cd/m2):400
Max Resolution:800(W) x 600(H)
LCD Size:10.4”
Brightness(cd/m2):400
Max Resolution:800(W) x 600(H)
Expansion Slots:1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)1 ...
Expansion Slots:1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)
1 x Half-size PCIe Mini slot for Wi-Fi modules
2 x LAN ((GbE)) 1 x Power Switch 1 x RS-232 ((RJ-45)) 1 x RS-422/485 ((DB-9 ...
2 x LAN ((GbE))
1 x Power Switch
1 x RS-232 ((RJ-45))
1 x RS-422/485 ((DB-9))
1 x Reset Button
2 x USB2.0
2 x USB3.0
1 x AT/ATX Switch
1 x Audio (((line-out)))
1 x Power In ((9-30V Lockable power jack))
View Products

PPC-F12B-BT

12” Fanless Intel® Bay Trail Solution
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz)
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz)
LCD Size:12.1""""(4:3) Brightness(cd/m2):600 Max Resolution:1024 (W) x 768 ...
LCD Size:12.1""""(4:3)
Brightness(cd/m2):600
Max Resolution:1024 (W) x 768 (H)
1 x Full-size PCIe Mini card slot (with PCIe and USB signal)1 x Full-size P ...
1 x Full-size PCIe Mini card slot (with PCIe and USB signal)
1 x Full-size PCIe Mini card slot co-lay mSATA (SATA2 only) (with PCIe and USB signal)
2 x RJ-45 LAN port2 x USB 3.02 x USB 2.01 x HDMI2 x RS-2321 x RS-232/422/48 ...
2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out (PPC-F15B and PPC-17B only)
1 x Power switch
View Products

PPC-F15B-BT

15” Fanless Intel® Bay Trail Solution
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz)
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz)
LCD Size:15""""(4:3) Brightness(cd/m2):400 Max Resolution:1024 (W) x 768 (H ...
LCD Size:15""""(4:3)
Brightness(cd/m2):400
Max Resolution:1024 (W) x 768 (H)
1 x Full-size PCIe Mini card slot (with PCIe and USB signal)1 x Full-size P ...
1 x Full-size PCIe Mini card slot (with PCIe and USB signal)
1 x Full-size PCIe Mini card slot co-lay mSATA (SATA2 only) (with PCIe and USB signal)
2 x RJ-45 LAN port2 x USB 3.02 x USB 2.01 x HDMI2 x RS-2321 x RS-232/422/48 ...
2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out (PPC-F15B and PPC-17B only)
1 x Power switch
View Products

PPC-F17B-BT

17” Fanless Intel® Bay Trail Solution
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz)
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz)
LCD Size:17""""(5:4) Brightness(cd/m2):350 Max Resolution:1280 (W) x 1024 ( ...
LCD Size:17""""(5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H)
1 x Full-size PCIe Mini card slot (with PCIe and USB signal)1 x Full-size P ...
1 x Full-size PCIe Mini card slot (with PCIe and USB signal)
1 x Full-size PCIe Mini card slot co-lay mSATA (SATA2 only) (with PCIe and USB signal)
2 x RJ-45 LAN port2 x USB 3.02 x USB 2.01 x HDMI2 x RS-2321 x RS-232/422/48 ...
2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out (PPC-F15B and PPC-17B only)
1 x Power switch
View Products

PPC-F19B-BT

19” Fanless Intel® Bay Trail Solution
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz)
Intel® Celeron® processor J1900 (2M cache, up to 2.42 GHz)
LCD Size:19” (5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H)
LCD Size:19” (5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H)
1 x Full-size PCIe Mini slot ( mSATA/PCIe/USB signal)1 x Full-size/half-siz ...
1 x Full-size PCIe Mini slot ( mSATA/PCIe/USB signal)
1 x Full-size/half-size PCIe Mini slot (PCIe/USB signal)
2 x RJ-45 LAN port2 x USB 3.02 x USB 2.01 x HDMI2 x RS-2321 x RS-232/422/48 ...
2 x RJ-45 LAN port
2 x USB 3.0
2 x USB 2.0
1 x HDMI
2 x RS-232
1 x RS-232/422/485
1 x VGA
1 x 9 V~36 V DC jack (4-pin)
1 x 9 V~36 V DC terminal block
1 x Line-out
1 x Power switch
View Products

ファン付きモデル
15”~24" Panel PC with active fan
CPU / Chipset
Display
Expansion
I/O
Features

PPC-F15A-H81

Intelligent Industrial Panel PC
LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processo ...
LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP
LCD Size:15”(4:3)
Brightness(cd/m2):400
Max Resolution:1024 (W) x 768 (H)
LCD Size:15”(4:3)
Brightness(cd/m2):400
Max Resolution:1024 (W) x 768 (H)
1 x Full-size PCIe Mini card1 x Full-size PCIe Mini card co-lay mSATA (SATA ...
1 x Full-size PCIe Mini card
1 x Full-size PCIe Mini card co-lay mSATA (SATA2 only)
2 x RJ-45 LAN Port2 x USB 3.04 x USB 2.01 x HDMI output4 x RS-2321 x RS-422 ...
2 x RJ-45 LAN Port
2 x USB 3.0
4 x USB 2.0
1 x HDMI output
4 x RS-232
1 x RS-422/485
1 x MIC-in
1 x Line-out
1 x VGA output
1 x AC/DC power plug
(DC model is by build to order manufacturing)
1 x AT/ATX switch
1 x Clear CMOS
1 x Reset button
1 x Power switch
View Products

PPC-F17A-H81

Intelligent Industrial Panel PC
LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processo ...
LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP
LCD Size:17”(5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H)
LCD Size:17”(5:4)
Brightness(cd/m2):350
Max Resolution:1280 (W) x 1024 (H)
1 x Full-size PCIe Mini card1 x Full-size PCIe Mini card co-lay mSATA (SATA ...
1 x Full-size PCIe Mini card
1 x Full-size PCIe Mini card co-lay mSATA (SATA2 only)
2 x RJ-45 LAN Port2 x USB 3.04 x USB 2.01 x HDMI output4 x RS-2321 x RS-422 ...
2 x RJ-45 LAN Port
2 x USB 3.0
4 x USB 2.0
1 x HDMI output
4 x RS-232
1 x RS-422/485
1 x MIC-in
1 x Line-out
1 x VGA output
1 x AC/DC power plug
(DC model is by build to order manufacturing)
1 x AT/ATX switch
1 x Clear CMOS
1 x Reset button
1 x Power switch
View Products

PPC-F22A-H81

Intelligent Industrial Panel PC
LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processo ...
LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP
LCD Size:21.5”(16:9) Brightness(cd/m2):250 Max Resolution:1920 (W) x 1080 ( ...
LCD Size:21.5”(16:9)
Brightness(cd/m2):250
Max Resolution:1920 (W) x 1080 (H)
1 x Full-size PCIe Mini card1 x Full-size PCIe Mini card co-lay mSATA (SATA ...
1 x Full-size PCIe Mini card
1 x Full-size PCIe Mini card co-lay mSATA (SATA2 only)
2 x RJ-45 LAN Port2 x USB 3.04 x USB 2.01 x HDMI output4 x RS-2321 x RS-422 ...
2 x RJ-45 LAN Port
2 x USB 3.0
4 x USB 2.0
1 x HDMI output
4 x RS-232
1 x RS-422/485
1 x MIC-in
1 x Line-out
1 x VGA output
1 x AC/DC power plug
(DC model is by build to order manufacturing)
1 x AT/ATX switch
1 x Clear CMOS
1 x Reset button
1 x Power switch
View Products

PPC-F24A-H81

Intelligent Industrial Panel PC
LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processo ...
LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP
LCD Size:24”(16:9)
Brightness(cd/m2):250
Max Resolution:1920 (W) x 1080 (H)
LCD Size:24”(16:9)
Brightness(cd/m2):250
Max Resolution:1920 (W) x 1080 (H)
1 x Full-size PCIe Mini card1 x Full-size PCIe Mini card co-lay mSATA (SATA ...
1 x Full-size PCIe Mini card
1 x Full-size PCIe Mini card co-lay mSATA (SATA2 only)
2 x RJ-45 LAN Port2 x USB 3.04 x USB 2.01 x HDMI output4 x RS-2321 x RS-422 ...
2 x RJ-45 LAN Port
2 x USB 3.0
4 x USB 2.0
1 x HDMI output
4 x RS-232
1 x RS-422/485
1 x MIC-in
1 x Line-out
1 x VGA output
1 x AC/DC power plug
(DC model is by build to order manufacturing)
1 x AT/ATX switch
1 x Clear CMOS
1 x Reset button
1 x Power switch
View Products
