» 10th Gen Intel® Xeon® & Core™ processor platform with Intel® Q470 chipset
» PCIe x4 slot supports capture cards or other applications
» Compact edge device with great computing & graphics performance
» PCIe x16 slot supports NVIDIA GPU Acceleration Card
» Two 260-pin 2666/2133MHz Dual-Channel DDR4 SODIMM unbuffered Memory supported up to 128GB
IEI AI Box PC HTB-210-Q470 Product Introduction
Hardware Spec.
| Form factor | |
|---|---|
| Form factor |
|
| 系統 | |
|---|---|
| 冷卻方式/系統風扇 | Smart Fan |
| 擴充槽 | |
|---|---|
| 擴充槽 | 1 x PCIe 3.0 x4 slot 1 x PCIe 3.0 x16 slot 1 x M.2 A key 2230 slot (PCIe x2 and USB 2.0) 1 x M.2 M key 2280 slot (PCIe x4 and SATA) |
| 輸出/入介面 | |
|---|---|
| 輸出/入介面 | 1 x USB Type C (USB/DP) 2 x USB 3.2 GEN1 2 x USB 2.0 (front side) 2 x Intel® I225-V PCIe controller (2.5GbE) 1 x RS-232/422/485 1 x HDMI™ (up to 4096 x 2304@30Hz) |
| 指示燈與按鈕 | |
|---|---|
| 按鈕 | 1 x Power button 1 x AT/ATX switch |
| 指示燈 | 1 x Power LED |
| 外觀 | |
|---|---|
| 顏色 | White |
| 機殼結構 | Metal housing (SECC) |
| 重量（淨重, kg） | 2.8 |
| 外觀尺寸（mm） | 140 x 306.7 x 171 |
| 環境 | |
|---|---|
| 操作溫度 | 0°C ~ 40°C |
| 濕度 | 10% ~ 95% (non-condensing) |
