Embedded System

IEI, the leading embedded system provider, continues to extend the product footprint from component level to system integration service. Our strong knowledge of market and technology innovation offers reliability, flexibility and interoperability for all of our embedded products with choices of size, performance and features.
比較狀態 :
已設定.要比較機種數 :
已設定.要比較機種 :
列表區塊.Now 位置狀態 :
列表區塊.單位區塊寬 :
列表區塊.Now X 位置 :
列表區塊.目標 X 位置 :
顯示框寬 :
列表寬 :
Din-rail
DRPC Series
Fanless DIN Rail embedded system.
*User friendly installation design.
*OLED indicator function
*Fully integrated I/O
CPU
Chipset
I/O
Expansion

DRPC-120-BT

Fanless DIN-Rail Embedded System,Intel® E3845 1.91GHz Solution
CPU:
Intel® Atom™ E3845 1.91 GHz
Chipset:SoC 2 x USB 3.0
2 x USB 2.0
2 x RJ-45
1 x PCIe GbE by IntelR I210 controller
1 x PCIe GbE by IntelR I211 controller
2 x DB-9 w/3KV isolation protection
2 x DB-9 w/3KV isolation protection
8-bit digital I/O, 4-bit input/4-bit output
1 x VGA, 1 x HDMI
802.1 b/g/n 2T2R (optional)
1 x Half-size PCIe Mini slot (w/o USB signal)
1 x Full-size PCIe Mini slot (supports mSATA, colay with SATA)

DRPC-130-AL

Fanless DIN-Rail Embedded System
Intel® Atom™ x5-E3930 1.3GHz (up to 1.8 GHz, dual core, TDP=6.5W)
SoC
SoC ●USB:4 x USB 3.0
●Ethernet:2 x RJ-45 (PCIe GbE by Intel® I211 controller)
●COM Port:4 x RS-232/422/485
●Digital I/O:8-bit digital I/O , 4-bit input / 4-bit
●CAN-Bus:1 x DB-9 w/ 2.5kV Isolation protection, supporting 2-port CAN-bus
●Display:2 x HDMI 1.4b
PCIe Mini:
1 x Half-size PCIe Mini slot
1 x Full-size PCIe Mini slot (supports mSATA, colay with SATA)
IEI DRPC-230-ULT5 Fanless Din-rail Embedded System
icon-new

DRPC-230-ULT5

Fanless DIN-Rail Embedded System with Intel® Core™ CPU
Intel® Whiskey Lake Core™ i5-8365UE
Intel® Whiskey Lake Celeron™ 4205U
SoC
SoC ●6 x USB 3.2 Gen2 (DRPC-230-ULT5-C/8G/S-R10 has 4 x USB 3.2 Gen2 & 2 x USB 2.0)
●Ethernet:
3 x RJ-45
2 x PCIe GbE by Intel® I211 controller
1 x PCIe GbE by Intel® I219 controller
●COM Port:
4 x RS-232/422/485 with AFC (DB-9)
2 x RS-232 (RJ45)
●Digital I/O:
8-bit digital I/O , 4-bit input / 4-bit
●Display:
1 x HDMI 1.4b (lockable)
1 x DP
●TPM:
1 x TPM 2.0 (optional)
●M.2:
1 x 2230 A key (PCIe/ USB2.0)
Celeron SKU: 1 x 2230 A key (PCIe)
●PCIe Mini:
1 x Full-size (PCIe/ USB 3.0/ SATA)
●Backplane:
1 x PCIe by 4
(No backplane signal for Celeron SKU)
