» Support IEEE 802.3at for PoE (Power over Ethernet) with 30 watts per port
» Support link aggregation/jumbo frames (9 Kbyte)
Hardware Spec.
| Form Factor | |
|---|---|
| Form Factor | TANK-XM81 series customization 8 x PCI Express® x1 |
| System | |
| Chipset | Intel® I225-V controller |
| Physical Characteristics | |
| Dimensions (LxWxH) (mm) | 170.94 x 131.22 |
| I/O Interface | |
| Ethernet | 8 x LAN(2.5GbE) |
| Environment | |
| Operating Temperature | 0°C ~ 60°C |
| Humidity | 5% ~ 95%, non-condensing |
| Certifications | |
| Safety & EMC | CE/FCC compliant |
Ordering Information
| TXIOB-XM81-8P2-R10 | Tank 81 Series Expansion IO Board module,8x2.5G Lan |
|---|---|
| GPOE-XM81-8P-R10 | Tank 81 Series Expansion IO Board module,8x2.5G Lan With POE |
Package Contents
| Package Content |
|
|---|
