GRAND-GL

Intel® Celeron® J4125 Processor (4M Cache, up to 2.70 GHz)

  • Overview

    ● Intel® Celeron® J4125 quad-core 2.0 GHz processor with AES-NI Encryption
    ● 2 x SODIMM Slots, up to 8GB memory with 2 x 4GB DIMMs
    ● 1 x PCIe x2 slot can support PCIe expansion card
    ● Storage expandable via USB 3.2 Gen1 port
  • Specifications

    • Hardware Spec.

      Spec Item Description
      Form Factor
      Form Factor 1U, Rackmount
      System
      CPU Intel® Celeron® J4125 Processor (4M Cache, up to 2.70 GHz)
      Memory Max. SODIMM x 2 (MAX. 8GB)
      Cooling method / System Fan 2 x 40mm, 12V
      Physical Characteristics
      Rack Height 1U, 4Bay
      Dimensions (LxWxH) (mm) 43.3 (H) x 482.6 (W) x 483.9 (D) mm
      Net Weight 8.12 kg
      Storage
      Storage 4 x 3.5” HDD Bay
      4 x SATA
      I/O Interface
      Display Output 1 x HDMI
      Ethernet 2 x LAN
      I/O Interface 2 x External USB 2.0
      2 x External USB 3.2 Gen1x1
      Environment
      Operating Temperature 0~40˚C
      Humidity 5 to 95% non-condensing, wet bulb:27˚C.
    • Ordering Info.

      Item No. Description
      GRAND-GL-04A-RP-R10 1U 4Bay front 3.5" HDD or SSD support, rackmount storage server (Barebone), Intel Celeron J4125, 2x 2.5GbE, 2 x 300W PSU
      GRAND-GL-04A-R10 1U 4Bay front 3.5" HDD or SSD support, rackmount storage server (Barebone), Intel Celeron J4125, 2x 2.5GbE, 250W PSU
    • Package Contents

      • Ethernet cable x 1

      • Power cord x 2 (non RP model only one power cord)

      • Flat head screws (for 2.5” HDD)

      • Flat head screws (for 3.5” HDD)
