ICT-2000 AM

CFast Series MLC

End of Life

End of Life Notice

* Effective Date: 2020/07/01

CFast Series MLC

Hardware Spec.

ATA Security
ATA Security Yes
Capacity (GB)
Capacity (GB) 8GB~128GB
DC Power Input
DC Power Input 3.3V
Dimensions
Dimensions 42.8 x 36.4 x 3.6
Flash Type
Flash Type MLC
IDE Transfer Mode
IDE Transfer Mode Yes
Max. Power Consumpation
ConsumpationMax. Power Consumpation 525mA
P/N
STD(0°C~+70°C) ICT-2000IAM-8GB
ICT-2000IAM-16GB
ICT-2000IAM-32GB
ICT-2000IAM-64GB
ICT-2000IAM-128GB
WT(-40°C~+85°C) ICT-2000WAM-8GB
ICT-2000WAM-16GB
ICT-2000WAM-32GB
ICT-2000WAM-64GB
ICT-2000WAM-128GB
S.M.A.R.T
S.M.A.R.T Yes
Sequential R/W
Sequential R/W 310/240 MB/sec
Environment
Operating Temperature 0°C~+70°C (Standard)/-40°C~+85°C (Industrial)
Operating Vibration 15 (G), 10~2000 (Hz)
Operating Shock 1500G/0.5ms
Storage Temperature -55°C~+95°C

Ordering Information

ICT-2000IAM-8GB Flash Disk; Sata Interface CompactFlash, Standard, MLC, 0℃~70℃, R:200MB/s W:21MB/s, 8GB
ICT-2000IAM-16GB Flash Disk; Sata Interface CompactFlash, Standard, MLC, 0℃~70℃, R:205MB/s W:43MB/s, 16GB
ICT-2000IAM-64GB Flash Disk; Sata Interface CompactFlash, Standard, MLC, 0℃~70℃, R:305MB/s W:155MB/s, 64GB
ICT-2000IAM-128GB Flash Disk; Sata Interface CompactFlash, Standard, MLC, 0℃~70℃, R:310MB/s W:240MB/s, 128GB
ICT-2000WAM-128GB
ICT-2000IAM-32GB Flash Disk; Sata Interface CompactFlash, Standard, MLC, 0℃~70℃, R:205MB/s W:46MB/s, 32GB
ICT-2000WAM-8GB
ICT-2000WAM-16GB
ICT-2000WAM-32GB Flash Disk; Sata Interface CompactFlash, Standard, MLC, -40℃~85℃, R:205MB/s W:46MB/s, 32GB
ICT-2000WAM-64GB Flash Disk; Sata Interface CompactFlash, Standard, MLC, -40℃~85℃, R:305MB/s W:155MB/s, 64GB

Download Specs.
