Overview
• 1 x Intel® Ethernet Controller I350-AM4• 4 x GbE RJ-45 connectors• 2 PCIe2.0 x4• LAN Bypass (by sku)• CE/FCC/RoHS compliant -
Features
Block Diagram
Hardware Installation
Install the PulM-1G4T-I350 series networking module into the slot of the PUZZLE series. The Slot A supports 8 lanes from CPU (1 PCIe x8 or 2 PCIe x4); the Slot B supports 8 lanes from PCH (2 PCIe x4 or 4 PCIe x2). The PulM-1G4T-I350 is can installed into the Slot A & Slot B.
-
Specifications
-
Hardware Spec.
Spec Item Description I/O Interface Ethernet 4 x LAN Falt-tolerance LAN Bypass Yes (by sku) Environment Operating Temperature 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature -20°C ~ 75°C (-4°F ~ 167°F) Humidity 5% ~ 90% RH, Non-condensing Certifications Safety & EMC CE/FCC/RoHS compliant Card Slot Interface PCIe 2 PCIe 2.0 x4 Card Features Speed GbE Controller Chip Intel® Ethernet Controller I350-AM4 -
Ordering Info.
Item No. Description PulM-1G4T-I350-R10 Intel® Ethernet Controller I350-AM4 based Network Interface Card with 4 x RJ-45 by 2 PCIe 2.0 x4 interface, RoHS. PulM-1G4T-I350-BP-R10 Intel® Ethernet Controller I350-AM4 based Network Interface Card with 4 x RJ-45 by 2 PCIe 2.0 x4 with bypass interface, RoHS. -
Package Contents
-
1 x PulM-1G4T-I350 or PulM-1G4T-I350-BP module
-
1 x L-shaped T10 Plum Wrench
-
2 x Torx Screws
-
1 x QIG
-
-
