  • Overview

    ●Support Android 5.0
    ●Flexibie ID Design.(Open Frame or customized ID Design)
    ●IEI Customer Reference Board(10.1"" / 15.6"" / 18.5"" share the same main board)
    ●Freescale Quad Core - A9 1GHz processor
    ●10.1"" / 15.6"" / 18.5"" Color TFT LCD
    ●Waterproof:IPX5(For customized ID)
    ●Support BLE / ANT + NFC
    ●Support ATSC / DVBT TV Dongle
  • Specifications

    • Hardware Spec.

      Spec Item Description
      Communication
      Bluetooth BT4.0
      Wi-Fi 802.11 b/g/n
      Environment
      Humidity 5%~95%
      Operating Temperature 0°c~+40°c
      Storage Temperature -10°c~+50°c
      LCD
      Backlight MTBF 50000
      Brightness (cd/m2) 300 (cd/m²)
      Contrast Ratio 500:1
      LCD Color 16.7M
      Pixel Pitch (mm) 0.2525 x 0.252
      Resolution 1366 (W) x 768 (H)
      Size 15.6""
      Other Features
      Audio 2 x 3W Audio
      Physical Characteristics
      Color Black
      Dimensions (LxWxH) (mm) 420 x 270 x 87mm
      Power
      Power consumption 12V @2.25A
      Power Requirement 12~36V
      System
      CPU Freescale iMX6 Cortex-A9 Quad Core 1.0 GHz
      Memory Max. 2GB DDR3 SDRAM
      SBC Model OS Support:Android 5.1
      Touch
      Touch Screen Projected capacitive flat touch
      I/O Interface
      I/O Interface 1 x USB 2.0
      1 x HDMI
      1 x LAN(10/100 Mbps Power over Ethernet)
      1 x SD Slot
