  • Overview

    ● Support IEI iRIS-2400 IEI remote intelligent solution
    ● Scalable Intel® H81 chipset supports LGA1150 Intel® 4th generation Core™ i7/i5/i3, Pentium® or Celeron® processor with up to 65W TDP
    ● Robust IP65 aluminum front bezel
    ● Aesthetic ultra-thin bezel for seamless panel mount installation
    ● Projected capacitive multi-touch
    ● Dual full-size PCIe Mini card expansion
    ● AC/DC power input options (DC model by build to order manufacturing)
  • Specifications

    • Hardware Spec.

      Spec Item Description
      Display
      Backlight MTBF(hrs)30000
      Brightness(cd/m2)250
      Contrast Ratio125.000694444444
      LCD Size24”(16:9)
      Max Resolution1920 (W) x 1080 (H)
      Environment
      Humidity10% to 95% (non-condensing)
      IP LevelIP 65 compliant front panel
      Operating Temperature-10°C~50°C (14°F~122°F)
      Storage Temperature-20°C~60°C (-4°F~140°F)
      I/O Interface
      I/O Ports and Switches2 x RJ-45 LAN Port
      2 x USB 3.0
      4 x USB 2.0
      1 x HDMI output
      4 x RS-232
      1 x RS-422/485
      1 x VGA output
      1 x AC/DC power plug (DC model is by build to order manufacturing)
      1 x AT/ATX switch
      1 x Clear CMOS
      1 x Reset button
      1 x Power switch
      LCD
      LCD Color16.7M
      Pixel Pitch (mm)0.28 x 0.28
      Viewing Angle (H-V)178° / 178°
      Physical Characteristics
      Cutout Dimensions359.6 x 580.4
      Dimensions (LxWxH) (mm)382 x 600 x 71.7
      Power
      Power adapter12V DC
      Touch
      Touch Screen2-point projected capacitive touch window (EETI EXC7200), 6H
      Weight
      Weight10.5/14.8
    • Ordering Info.

      Item No. Description
      PPC-F24AA-H81i-P/4G/PC-R1024” 250 cd/m2 FHD Panel PC with Intel H81 chipset, Pentium Dual Core G3220 Processor (3M Cache, 3.00 GHz), TDP 53W, 2GB RAM*2, support iRIS-2400, black color, PSU ACE-A622A, projective capacitive touch window, R10
      PPC-F24AA-H81i-i3/4G/PC-R1024” 250 cd/m2 FHD Panel PC with Intel H81 chipset, Core i3 Dual Core i3-4330 Processor (4M Cache, 3.50 GHz), TDP 54W, 2GB RAM*2, support iRIS-2400, black color, PSU ACE-A622A, projective capacitive touch window, R10
      PPC-F24AA-H81i-i5/4G/PC-R1024” 250 cd/m2 FHD Panel PC with Intel H81 chipset, Core i5 Quad Core i5-4570S Processor (6M Cache, up to 3.60 GHz), TDP 65W, 2GB RAM*2, support iRIS-2400, black color, PSU ACE-A622A, projective capacitive touch window, R10
    • Package Contents

      • 1 x Power Cord 1 Depends on shipping region Screw Kit

      • 1 x Touch Pen
