  • Overview

    ● RoHS compliant design
    ● Two USB ports on the front panel
    ● Two 8 cm cooling fans with replaceable fan filter
    ● One 5.25"" and one 3.5"" drive bays
    ● One 3.5"" internal hard drive bay
    ● Lockable door prevents unauthorized access
  • Specifications

    • Hardware Spec.

      Spec Item Description
      Form factor
      SBC Form Factor Full-size, slot CPU card
      I/O Interface
      I/O Ports 2 x USB
      Expansion Slots
      Expansion Slots 6 slots
      System
      Cooling method / System Fan 2 x 8 cm
      Drive Bays 1 x 5.25”
      1 x 3.5”
      1 x 3.5” HDD (internal)
      Indicator&Buttons
      Buttons Power switch, reset button
      Indicators Power, HDD
      Physical Characteristics
      Construction Heavy duty metal
      Color
      Color W: White/B: Black
      Dimensions
      Dimensions 448 mm x 431 mm x 88 mm
      Weight
      Weight 8.2 kg/12.4 kg(Net/Gross)
      Environment
      Operating Temperature 0°C ~ 50°C
      Humidity 10% ~ 90%
    • Ordering Info.

      Item No. Description
      RACK-220GW/A130B2U 6-slot Full-size for PICMG 1.0 SBC,White,2x 8cm fan,w/ACE-A130B-R10(300W ATX model)
      RACK-220GB/A130B2U 6-slot Full-size for PICMG 1.0 SBC,Black,2x 8cm fan,w/ACE-A130B-R10(300W ATX model)
      RACK-220GWATX/A130B2U microATX motherboard,White,2x 8cm fan,w/ACE-A130B-R10(300W ATX model)
      RACK-220GBATX/A130B2U microATX motherboard,Black,2x 8cm fan,w/ACE-A130B-R10(300W ATX model)
