  • Overview

    ● RoHS compliant design
    ● Two USB ports on the front panel
    ● One 8 cm hot swappable cooling fan with fan filter
    ● 2 x 5.25”, 1 x 3.5” HDD, 1 x front-accessible 3.5” drive bays
    ● Lockable door prevents unauthorized access
  • Specifications

    • Hardware Spec.

      Spec Item Description
      Form factor
      SBC Form Factor Full-size, slot CPU card
      I/O Interface
      I/O Openings 1 x LPT, 1 x COM
      I/O Ports 2 x USB
      Expansion Slots
      Expansion Slots 10 slots
      System
      Cooling method / System Fan 1 x 8 cm
      Drive Bays 2 x 5.25”
      1 x Front accessible 3.5”
      1 x 3.5” HDD
      Indicator&Buttons
      Buttons Power switch, reset
      Indicators Power, HDD
      Physical Characteristics
      Construction Heavy duty metal
      Color
      Color W: White
      Dimensions
      Dimensions 420 mm x 321 mm x 176 mm(DxWxH)
      Weight
      Weight 7.2 kg/10.4 kg(Net/Gross)
      Environment
      Operating Temperature 0°C ~ 50°C
      Humidity 10% ~ 90%
    • Ordering Info.

      Item No. Description
      PAC-125GW-R22/A130B10-Slot Full-size Chassis,White,1x 8cm fan,w/ACE-A130B-R10(300W ATX model)
      PAC-125GW-R22/ACE-925AP10-Slot full Size chassis,White,W/ACE-925AP-U PSU(200W),RoHS
