Cloud Based IPC built-in QTS Gateway OS for IIOT

End of Life

End of Life Notice

* Effective Date: 2019/12/20

» Built-in QTS Gateway operating system that can be visualized immediately
» Supports remote connection (myQNAPcloud) and hybrid backup (Hybrid Backup Sync)
» QRM+ easily monitors IPMI equipment, servers, PCs and production line equipment
» Q’center centralizes management of multiple QNAP NAS and the IPC equipped with QTS Gateway
» Surveillance Station for remote video surveillance, 24/7 security
» Seven levels of data security protection to protect your valued data

Hardware Spec.

Form factor
SBC Form Factor CPU: Intel® Atom™ E3845 1.91 GHz
Cooling method / System Fan Fanless
Chipset SoC
Memory Max. Two 2 GB 204-pin DDR3L SO-DIMM pre-installed
Drive Bays 1 x 2.5” SATA 6Gb/s HDD/SSD bay
Indicators Power/HDD/Com port/DIO
I/O Interface
Display 1 x VGA, 1 x HDMI™
Audio 1 x Line-out, 1 x Mic-in
I/O Interface 2 x USB 3.0
2 x USB 2.0
2 x RJ-45
1 x PCIe GbE by Intel® I210 controller
1 x PCIe GbE by Intel® I211 controller
1 x 802.11b/g/n 1T1R (optional)
Digital I/O Digital I/O:8-bit digital I/O, 4-bit input/4-bit output
Serial 2 x RS-232 (DB-9 w/3KV isolation protection*)
2 x RS-422/485 (DB-9 w/3KV isolation protection*)
Input 3-pin terminal block: 9 V ~ 30 V DC
Power consumption 12V@2.1A
Operating Temperature -20°C ~ 70°C with air flow (SSD) i5-4400E
Safety & EMC CE/FCC, MIL-STD-810F 514.5C-2 (with SSD)
Physical Characteristics
Construction Extruded aluminum alloys
Dimensions 74.08 x 140 x 171.5
Weight 1.4 kg/2.5 kg
Color Black
Expansion Slots
Expansion Slots 1 x Half-size PCIe Mini slot (w/o USB signal)
iRIS 1 x iRIS-2400 (Optional)

Ordering Information

DRPC-120-QGW-E5-LED/4G-R10 Fanless embedded system with Intel® Bay-Trail E3845 1.91 GHz, TDP 10W,4 GB DDR3L pre-installed memory, with QTS-Gateway, 1 x VGA, 1 x HDMI™, 8 CH DIO, iRIS-2400 optional,9 V~30 V DC, LED indicators, RoHs

Package Contents

Package Content
  • 1 x Screw kit

  • 1 x Mounting bracket

  • 1 x SATA cable & SATA power cable
