» Compatible with ATX and microATX and Mini-ITX motherboards
» Two USB ports on the front panel
» Two 8 cm cooling fans
» Two 3.5” and two 2.5” drive bays
» RoHS compliant design
Hardware Spec.
| Form factor | |
|---|---|
| SBC Form Factor | ATX and microATX and Mini-ITX motherboards |
| I/O Interface | |
|---|---|
| I/O Ports | 2 x USB (Front panel) |
| Expansion Slots | |
|---|---|
| Expansion Slots | 7 slots (Half-height size) |
| System | |
|---|---|
| Cooling method / System Fan | 2 x 80 mm Fan |
| Drive Bays | 2 x 3.5” HDD bay 2 x 2.5” HDD bay |
| Indicator&Buttons | |
|---|---|
| Buttons | Power switch, Reset button |
| Indicators | Power Led |
| Physical Characteristics | |
|---|---|
| Construction | Heavy duty metal |
| Color | |
|---|---|
| Color | Black |
| Dimensions | |
|---|---|
| Dimensions | 431.6 x 495 x 88 mm |
| Weight | |
|---|---|
| Weight | 5.6kg / 9.6kg |
| Environment | |
|---|---|
| Operating Temperature | -10°C ~ 60°C |
| Humidity | 10% ~ 90% |
| Operating Vibration | Half-sine wave shock 5G, 11ms, 100 shocks per axis (SSD) |
| Operating Shock | MIL-STD-810F 514.5C-1 (SSD) |
| Safety & EMC | CE/FCC compliant |
