Overview
● Half-Height, Half-Length, Double-slot.● Power-efficiency, low-latency.● Supported OpenVINO™ toolkit, AI edge computing ready device.● FPGAs can be optimized for different deep learning tasks.● Intel® FPGAs supports multiple float-points and inference workloads.Warning: DO NOT install the Mustang-F100-A10 into the TANK AIoT Dev. Kit before shipment. It is recommended to ship them with their original boxes to prevent the Mustang-F100-A10 from being damaged.
*Due to the OpenVINO™ toolkit version is upgraded periodically, IEI strongly recommend users to purchase FPGA programmer kit (7Z000-00FPGA00) to upgrade the FPGA bitstreams to get best performance.If you would like to buy FPGA Download Cable kit, please email to online@ieiworld.com or place an order on IEI USA e-shop, thank you. -
Features
Mustang-F100-A10
Accelerate To The Future
An Intel® Vision Accelerator Design Product
Intel® Vision Accelerator Design with Intel® Arria® 10 FPGA
A Perfect Choice for AI Deep Learning Inference Workloads
Powered by Open Visual Inference & Neural Network Optimization (OpenVINO™) toolkit
- Half-Height, Half-Length, Double-Slot.
- Power-efficiency, low-latency. Supported OpenVINO™ toolkit, AI edge computing ready device.
- FPGAs can be optimized for different deep learning tasks.
- Intel® FPGAs supports multiple float-points and inference workloads.OpenVINO™ toolkit
OpenVINO™ toolkit is based on convolutional neural networks (CNN), the toolkit extends workloads across Intel® hardware and maximizes performance.
It can optimize pre-trained deep learning model such as Caffe, MXNET, Tensorflow into IR binary file then execute the inference engine across Intel®-hardware heterogeneously such as CPU, GPU, Intel® Movidius™ Neural Compute Stick, and FPGA.
Applications
Machine Vision
Smart Retail
Surveillance
Medical Diagnostics
IEI New Product Launch - Acceleration Card Mustang-F100-A10 Introduction
Dimension
FAQ
Issue Solution Files 1. Bitstream mismatch of OpenVINO verison Get FPGA download cable than follow the step to update FPGA bitstream 2. Can not recognize hardware via "lspci" command Download patch to fix Mustang can not be recognized in some motherboards issue Mustang-F100_patch If you would like to buy FPGA Download Cable kit, please email to online@ieiworld.com or place an order on IEI USA e-shop, thank you. -
Specifications
-
Hardware Spec.
Spec Item Description Form factor Form factor PCIe Gen3x8 System Chipset Intel® Arria® 10 GX1150 FPGA Memory Max. 8G on board DDR4 Supported OS Ubuntu 16.04.3 LTS 64-bit, CentOS 7.4 64-bit (Support Windows® 10 64 bit in the end of 2018 & more OS are coming soon) I/O Interface Other On-board Devices and Interfaces Dip Switch & LED indicator Power Input Preserved PCIe 6-pin 12V external power Power consumption 40W Typical Environment Operating Temperature 5~60℃ Safety & EMC CE FCC Part B, UL, CB Humidity 5~90℃ Dimensions Dimensions 169.5x67.6x33.7mm -
Ordering Info.
Item No. Description 7Z000-00FPGA00 OTHERS PERIPHERAL DEVICE;FPGA Download Cable;IEI USB DOWNLOAD CABLE;Macnica;USB Download+USB CABLE+IDE CABLE+FPGA CABLE Mustang-F100-A10-R10 PCIe FPGA Highest Performance Accelerator Card with Arria 10 1150GX support DDR4 2400Hz 8GB, PCIe Gen3 x8 interface -
Package Contents
1 X Full height bracket
1 x External power cable
1 x QIG
-
-
