  • Overview

    ●Support Android 5.0
    ●Flexibie ID Design.(Open Frame or customized ID Design)
    ●IEI Customer Reference Board(10.1"" / 15.6"" / 18.5"" share the same main board)
    ●Freescale Quad Core - A9 1GHz processor
    ●10.1"" / 15.6"" / 18.5"" Color TFT LCD
    ●Waterproof:IPX5(For customized ID)
    ●Support BLE / ANT + NFC
    ●Support ATSC / DVBT TV Dongle
  • Specifications

    • Hardware Spec.

      Spec Item Description
      Communication
      BluetoothBT4.0
      Wi-Fi802.11 b/g/n
      Environment
      Humidity5%~95%
      Operating Temperature0°c~+40°c
      Storage Temperature-10°c~+50°c
      LCD
      Backlight MTBF30000
      Brightness (cd/m2)250 (cd/m²)
      Contrast Ratio600:1
      LCD Color16.7M
      Pixel Pitch (mm)0.1695 x 0.1695
      Resolution1280 (W) x 600 (H)
      Size10.1""
      Other Features
      Audio2 x 3W Audio
      Physical Characteristics
      ColorBlack
      Dimensions (LxWxH) (mm)256 x 187 x 77.3 mm
      Power
      Power consumption12V @1.5A
      Power Requirement12~36V
      System
      CPUFreescale iMX6 Cortex-A9 Quad Core 1.0 GHz
      Memory Max.2GB DDR3 SDRAM
      SBC ModelOS Support:Android 5.1
      Touch
      Touch ScreenProjected capacitive flat touch
      I/O Interface
      I/O Interface1 x USB 2.0
      1 x HDMI
      1 x LAN(10/100 Mbps Power over Ethernet)
      1 x SD Slot
