  • Overview

    ● Intel® Ivy Bridge mobile chipset
    ● 15’’ 400 nits 1024 x 768 LCD with LED backlight
    ● Full IP 65 compliant die-casting aluminum chassis
    ● PCIe Mini card expasion
    ● Dual-DC input, 9V ~ 36V and 10.5V ~ 36V, switch automatically
    ● ACC power support
    ● Dual-band 2.4/5 GHz Wi-Fi 802.11a/b/g/n 3T3R MIMO design
    ● Reserved space for 3.75G HSUPA USB dongle
    ● Optional GPS receiver
    ● Optional EM or Mifare RFID reader
    ● Optional Bluetooth module
    ● Built-in 2-megapixel webcam with AF, AE and AWB capabilities
    ● CAN-bus interface with isolation
    ● F1 ~ F10 function keys with customization options
  • Specifications

    • Hardware Spec.

      Spec Item Description
      Display
      Backlight MTBF(hrs)50000
      Brightness(cd/m2)400
      Contrast Ratio700 : 1
      LCD Size15"
      Max Resolution1024(W) x 768(H)
      Environment
      Humidity10% to 95% (non-condensing)
      Operating Temperature-10°C~50°C
      Storage Temperature-20°C~60°C
      Expansion Slots
      Expansion Slots1 x PCIe Mini card
      I/O Interface
      I/O Ports and Switches3 x RS-232 (RJ-45)
      1 x RS-422/485 (RJ-45)
      1 x CAN-bus
      1 x VGA
      1 x HDMI port
      2 x GbE LAN
      2 x USB 2.0
      2 x USB 3.0
      1 x Reset button
      1 x Audio jack (Line out, MIC)
      RAMBuitl-in one 2 GB DDR3 memory (system max. 8GB: on board max. 4GB, socket max. 4GB)
      LCD
      LCD Color16.2M
      Pixel Pitch (mm)0.297mm x 0.297mm
      Viewing Angle (H-V)125° / 140°
      Other Features
      System CoolingFanless
      Physical Characteristics
      Cutout Dimensions390 x 290
      Dimensions (LxWxH) (mm)427.19 x 330.63 x 77.06
      Power
      Power adapter90 W ; 63040-010090-050-RS
      Requirement Power 1: 9V~36V(+/-0.3V)
      Power 2: 10.5V~36V(+/-0.3V)
      System
      ChipsetMobile Intel® QM77 Express Chipset
      CPUIntel® Celeron® 1047UE processor
      HDD1 x 2.5” SATA SSD bay
      SSDmSATA (SATA2 signal)
      Touch
      Touch ControllerDMC 9000
      Touch Screen5-wire resistive type with RS-232 interface
      Weight
      Weight6.5 kg / 8.8kg
      I/O Interface
      I/O Interface1 x Reset Button
      2 x LAN(GbE LAN)
      1 x HDMI
      1 x CAN-bus
      1 x AT/ATX Switch
      3 x RS-232((RJ-45))
      1 x RS-422/485((RJ-45))
      1 x Video
      2 x USB2.0
      2 x USB3.0
      1 x Mic
      2 x Power In(9-36V DC jack/9-36V terminal block)
      1 x Line out
    • Ordering Info.

      Item No. Description
      UPC-V315-QM77-i7/R/2G-R1015" 400cd/m² XGA fanless full IP65 panel PC with Mobile Intel® QM77 Express Chipset and Intel® Core™ i7-3517UE Processor, 802.11a/b/g/n wireless module, resistive touch screen, 2M camera,microphone,2GB DDR3 RAM, R10
      UPC-V315-QM77-i3/R/2G-R1015" 400cd/m² XGA fanless full IP65 panel PC with Mobile Intel® QM77 Express Chipset and Intel® Core™ i3-3217UE Processor, 802.11a/b/g/n wireless module, resistive touch screen, 2M camera,microphone,2GB DDR3 RAM, R10
      UPC-V315-QM77-C/R/2G-R1015" 400cd/m² XGA fanless full IP65 panel PC with Intel QM77 and Celeron Dual Core 1047UE Processor (2M Cache, 1.40 GHz), TDP 17W, 802.11a/b/g/n wireless module, resistive touch screen, 2M camera,microphone, 2GB DDR3 RAM, R10
    • Package Contents

      • 1 x Power Adpater

      • 1 x Screw Kit

      • 1 x Touch Pen
