• Overview

    ● RoHS compliant design
    ● One 5.25” and one 3.5” drive bay
    ● Two 3.5” internal HDD bays
    ● Seven expansion slots, compatible with full-size SBC
    ● 7 expansion slots, compatible with full-size SBC
  • Specifications

    • Hardware Spec.

      Spec Item Description
      Form factor
      SBC Form Factor Full-size, slot CPU card
      I/O Interface
      I/O Openings 1 x LPT, 2 x COM
      Expansion Slots
      Expansion Slots 7 slots
      System
      Cooling method / System Fan 1 x 8 cm
      Drive Bays 1 x front-accessible 3.5"
      1 x 5.25"
      2 x 3.5" HDD
      Indicator&Buttons
      Buttons Power switch, reset
      Indicators Power, HDD
      Physical Characteristics
      Construction Metal with plastic front panel
      Color
      Color B: Black
      Dimensions
      Dimensions 433 mm x 233 mm x 253.7 mm(DxWxH)
      Weight
      Weight 6 kg/8.4 kg(Net/Gross)
      Environment
      Operating Temperature 0°C ~ 50°C
      Humidity 10% ~ 90%
    • Ordering Info.

      Item No. Description
      PAC-1700GB-R20/A130B 7-Slot Full-size Chassis,Black,1x 8cm fan,w/ACE-A130B-R10(300W ATX model)
