» 50W (4.17A@12V) output
» 28Wh for more than 60 minutes operation time (depending on panel PC power requirements)
» Rugged metal enclosure for Din-rail,standard VESA 75 and Wall mounting
» Web-based, remote network management, no software installation required
» Local PC-based monitoring software for input detection and battery status monitoring
» Auto shut down when battery low
» Remote DC output on/off switch for external switch installation
» Provides stable power to the PC during line sags and spikes and absorbs power surges and transients, protecting expensive equipment
Hardware Spec.
| Environment | |
|---|---|
| Operating Temperature | 0°C ~ 40°C |
| Storage Temperature | -20°C ~ 50°C |
| Input | |
| Voltage | 12-24V DC |
| Output | |
| Voltage | 12V DC |
| General | |
| Watt | 50W |
| Dimensions | 151.7 x 101.35 x 29.2 |
| Output Connector |
1 x DC JACK (Input) 1 x DC JACK (Output) 1 x 2 Pin Terminal block 1 x RJ45 1 x USB2.0 Type-A |
| Weight | |
| Weight | 0.75/1.2 kg |
Ordering Information
| AUPS2-A20-R10 | VESA 75, DC 12~14V input 60W UPS module with 7.26V;5600mAH, 2S2P Li-Ion battery, R10 |
|---|
Package Contents
| Package Content |
|
|---|
