High performance thermal solutions
Hardware Spec.
| CPU Solution | |
|---|---|
| CPU Solution | Intel® Core™ i9/ i7/ i5/ i3 |
| Socket Solution | |
| Socket Solution | LGA1700 |
| Dimensions | |
| Dimensions | 72 x 48.5 x 73.5 mm |
| Material | |
| Material | Cu-Al |
| Bearing Type | |
| Bearing Type | Ball and Sleeve |
| Capability (Watt) | |
| Capability (Watt) | 80W |
| Fan Speed (RPM) | |
| Fan Speed (RPM) | 4900 |
| Noise Level (dBA) | |
| Noise Level (dBA) | 36 |
| Life Expectancy (hrs) | |
| Life Expectancy (hrs) | 40000 |
| Weight | |
| Weight | 456g |
| Key Features | |
| Key Features | LGA1700 CPU cooler, RoHS |
Ordering Information
| 19100-000333-00-RS | B646;COOLER MODULE;HEATSINK:72*48.5*73.5mm,FAN:60*60*25.4mm;LGA1700,80W;STANDARD;00;HF-SETT-5Q362-2210;CU BASE+AL FIN+SCREW SET*4+BACKPLATE;DC FAN:12V,4900RPM,2543-4P,L=210mm;Everflow;F126025DU(AF0D5aR);CCL;RoHS |
|---|
