End of Life Notice
* Effective Date: 2017/12/31
» Two 204-pin DDR3 SO-DIMM slot (system max. 16GB) pre-installed with 4GB (2GB x 2)
» Projected capacitive touchscreen supported
» Wi-Fi 802.11b/g/n high speed wireless
» EM or Mifare RFID reader
» Programmable colorful LED light bar
» Built-in two 3W speakers and microphone
» Auto dimming control
» Light fanless design
» Wide range 9~36 VDC input
Hardware Spec.
| Communication | |
|---|---|
| Wi-Fi | IEEE 802.11b/g/n |
| Dimensions | |
| Dimensions | 546.85 x 345.82 x 70.35 |
| Environment | |
| Operating Temperature | -10°C~50°C |
| Storage Temperature | -20°C~60°C |
| I/O Interface | |
| I/O Ports and Switches |
2 x RS232 (DB9 Connector) 1 x RS422/485 COM Port (DB9 connector) 2 x GbE LAN (RJ-45 connector) 3 x USB 2.0 2 x USB 3.0 1 x HDMI™ |
| RAM |
Support two 204-pin DDR3 SO-DIMM slot (max. 16GB) preinstalled with 4GB (2GB x 2) |
| LCD | |
| Backlight MTBF | 30000 (LED backlight panel) |
| Brightness (cd/m2) | 250 |
| Contrast Ratio | 1000:1 |
| LCD Color | 16.7M |
| Pixel Pitch (mm) | 0.248 (H) x 0.248 (V) |
| Resolution | 1920 x 1080 |
| Size | W21.5"(16:9) |
| Viewing Angle (H-V) | 170º/160º |
| Other Features | |
| Camera | 2-megapixel camera with low light function |
| Microphone | Digital Microphone |
| System Cooling | Fanless |
| Power | |
| Power Requirement | 9~36 VDC |
| Storage | |
| Storage | 1 x 2.5″ SATA 3Gb/s HDD Bay |
| System | |
| Chipset | Intel® ICH61 |
| CPU | Intel® Core™ i7/i5/i3 and Pentium® processors |
| Touch | |
| Touch Controller | EETI EXC7200 & EXC5404 |
| Touch Screen | projected capacitive type with USB interface |
| Weight | |
| Weight | 8.27Kg |
| I/O Interface | |
| I/O Interface | 1 x Type K connector |
| 3 x USB 2.0 | |
| 2 x USB 3.0 | |
| 1 x Reset Button | |
| 1 x RS-422/485((DB-9)) | |
| 2 x RS-232((DB-9)) | |
| 1 x Power Switch | |
| 1 x Mic | |
| 1 x Line out | |
| 2 x LAN(GbE LAN (RJ-45 connector)) | |
| 1 x HDMI™ | |
| 1 x DC Input Jack(9-36V DC jack) | |
| 1 x AT/ATX switch | |
| 1 x VGA((DB-15)) | |
| 1 x Clear CMOS Button | |
Ordering Information
| AFL2-W21A-H61-P/PC-R11 | 21.5" 250cd/m² FHD panel PC, Pentium Dual Core G6xxT CPU (Above 2.2GHz), TDP 35W, 2GB DDR3 RAM*2, 802.11b/g/n wireless module, projected capacitive touchscreen, 2M camera, microphone,R11 |
|---|---|
| AFL2-W21AB-H61-i5/PC-R11 | 21.5" 250cd/m2 FHD panel PC, Core i5 Dual Core 2xxxT CPU (Above 2.7GHz), TDP 35W, 2GB DDR3 RAM*2, 802.11b/g/n wireless module, projected capacitive touchscreen, 2M camera, microphone, without LED bar, R11 |
| AFL2-W21A-H61-i3/PC-R11 | 21.5" 250cd/m² FHD panel PC, Core i3 Dual Core 2xxxT CPU (Above 2.5GHz), TDP 35W, 2GB DDR3 RAM*2, 802.11b/g/n wireless module, projected capacitive touchscreen, 2M camera, microphone,R11 |
| AFL2-W21AB-H61-P/PC-R11 | 21.5" 250cd/m2 FHD panel PC, Pentium Dual Core G6xxT CPU (Above 2.2GHz), TDP 35W, 2GB DDR3 RAM*2, 802.11b/g/n wireless module, projected capacitive touchscreen, 2M camera, microphone, without LED bar, R11 |
| AFL2-W21A-H61-i5/PC-R11 | 21.5" 250cd/m² FHD panel PC, Core i5 Dual Core 2xxxT CPU (Above 2.7GHz), TDP 35W, 2GB DDR3 RAM*2, 802.11b/g/n wireless module, projected capacitive touchscreen, 2M camera, microphone,R11 |
| AFL2-W21AB-H61-i3/PC-R11 | 21.5" 250ccd/m2 FHD panel PC, Core i3 Dual Core 2xxxT CPU (Above 2.5GHz), TDP 35W, 2GB DDR3 RAM*2, 802.11b/g/n wireless module, projected capacitive touchscreen, 2M camera, microphone, without LED bar, R11 |
Package Contents
| Package Content |
|
|---|
