IEI launches Mustang-200 x86 computing accelerator
2018-edm-banner

Mustang-200 Accelerate to The Future

Features
Mustang-200 Video Transcoding (MVT) Overview
Specifications
Ordering Information
Packing List

  title_point Features

Dual 10Gbps network based x86 computing accelerator
Decentralized computing architecture for independent tasks
PCI Express x4 delivers scalable and flexible solution
Two Intel® Core™ i7-7567U/i5-7267/Celeron® 3865U processors, up to 4.00 GHz
Support high-end graphics engine - Intel® Iris™ Plus Graphics 650
Pre-installed 32 GB DDR4 (max. 64 GB) and 1 TB NVMe (max. 2 TB)
top
  title point Mustang-200 Video Transcoding (MVT) Overview

Video Processing and Graphic Rendering Made Easy
Video transcoding and streaming are also ideal applications of the Mustang-200. The powerful processors of the Mustang-200 can easily process high-definition 360° surround videos. The networked structure of the Mustang-200 is also perfectly applicable for render farms where a lot of parallel computing resources are needed. The Mustang-200 can help creative professionals streamline their workflows and accelerate their processes.
• Transcoding Applications
For-Transcoding-Applications

• Transcoding with GPU Accelerated Computing
  • Mustang-200 uses a graphics processing unit (GPU) together with a CPU to accelerate media transcoding, AI (VR & deep learning), big data analytics, and other engineering applications.
  • As an add-on card, Mustang-200 offers quick and scalable integration with existing and standard server architectures to meet demands of video streaming platform providers
  • Mustang-200 offers full hardware transcoding (encoding & decoding)
Transcoding with GPU Accelerated Computing
top

  title point Specifications

Model Name Mustang-200
Main Chipset Two (2) Intel Kabylake ULT CPU
Intel® Core™ i7-7567U (28 W) (4M Cache, up to 4.00 GHz)
Intel® Core™ i5-7267U (28 W) (4M Cache, up to 3.50 GHz)
Intel® Celeron® 3865U (15W) (2M Cache, 1.80 GHz)
Processor Graphics Intel® Core™ i7-7567U & i5-7267U support Iris™ Plus
Graphics 650 (GT3e)
•Graphics base frequency 300 MHz
•Graphics max dynamic frequency: 1.05 GHz
•Embedded graphics DRAM per GPU: 64 MB
Intel® Celeron® 3865U supports Intel® HD Graphics 610
•Graphics base frequency 300 MHz
•Graphics max dynamic frequency: 900 MHz
Hardware Video Decode H.264, H.265/HEVC
MPEG2, M/JPEG
VC-1
VP8(8 bit)/VP9(10 bit)
Hardware Video Encode H.264, H.265/HEVC
MPEG2, M/JPEG
VC-1
VP8 (8-bit)
Display Output 2 x Micro HDMI for debugging
USB 2.0 4 x USB 2.0 (pin header ) for debugging
Memory (2 SO-DIMMs per CPU)
4 x DDR4 8GB SO-DIMM (Core™ i7/i5 SKU)
4 x DDR4 2GB SO-DIMM (Celeron® 3865U SKU)
Storage 2 x Intel® SSD 600P series (Core™ i7/i5 SKU only)
(512GB M.2 80mm PCIe 3.0 x4, 3D1, TLC)
Dataplane Interface PCI Express x4
Compliant with PCI Express Specification V2.0
Compatible with PCI Express x4, x8, and x16 slots
External Interfaces Reset button
Power button
Indicator Seven segment (indicate card number and debug code)
Power Input 12V PCIe 6-pin power input
Power Consumption 12V@7.41A (Intel® Core™ i7-7567U SKU)
Operating Temperature 0°C~40°C
Fan Dual fan
Dimensions (DxWxH) 40mm x 210mm x 111mm
Operating Humidity 10% ~ 90%
top

  title point Ordering Information

Part No. Description
Mustang-200-i7-1T/32G-R10 Computing Accelerator Card supports Two Intel® Core™ i7-7567U with Intel® 600P 1TB (512GB x2) SSD, 32GB (8GB x4) DDR4, PCIe x4 interface, QTS-Lite, and RoHS
Mustang-200-i5-1T/32G-R10 Computing Accelerator Card supports Two Intel® Core™ i7-7267U with Intel® 600P 1TB (512GB x2) SSD, 32GB (8GB x4) DDR4, PCIe x4 interface, QTS-Lite, and RoHS
Mustang-200-C-8G-R10 Computing Accelerator Card supports Two Intel® Celeron® 3865U with 8GB (2GB x4) DDR4, PCIe x4 interface, QTS-Lite, and RoHS (without NVMe storage)
19B00-000396-00-RS Mustang-200 dual-port USB cable
top



  title point Packing List

1 x Mustang-200
1 x QIG
1 x 4 pin to PCIe power cable
