IEI Launches HYPER-AL PICO-ITX SBC supports Intel® 14nm Apollo Lake on-board SoC
IEI Product News


dot Features dotSpecifications dotDimension
dot Ordering Information dotPacking List
arrow PICO-ITX SBC supports Intel® 14nm Apollo Lake on-board SoC supports Intel® 14nm Apollo Lake on-board SoC
arrow Dual GbE LAN support
arrow Flexible expansion with M.2 A key 2230 and M.2 B key 2242 support
arrow HDMI and internal LVDS for independent display
arrow 12V only single voltage design for AT/ATX power by DC power jack

SoC Intel® Celeron® N3350 on-board SoC (up to 2.4GHz, dual-core, 2M Cache, TDP=6W)
Memory One 204-pin 1866/1600MHz single-channel DDR3L SDRAM unbuffered SO-DIMM slot (system max. 8GB)
Graphic Engine Intel® HD Graphics Gen9 Low Power, 18 Execution Units
4K Codec Decode & Encode for HEVC 4, H.264, VP8, SVC, MVC
Display Output 1 x HDMI
1 x LVDS (2x10 pin, single channel, 24bit)
Ethernet LAN1: Realtek RTL8111H controller
LAN2: Realtek RTL8111H controller
External I/O Interface 2 x USB 3.0 (on rear I/O)
Internal I/O Interface 1 x RS-232 (1x9 pin, P=1.25)
1 x SATA 6Gb/s (w/ 5V SATA PWR)
2 x USB 2.0 (2 by pin header) (2x4 pin, P=2.0)
Audio 1 x HD audio (2 x 5 pin, support 7.1 channel HD audiou by AC-KIT-892HD-R10)
Front Panel 1 x Front panel (1 x 8 pin, power LED, HDD LED, power buttom, reset buttom)
Expansion 1 x M.2 A key 2230 (PCIe, USB)
1 x M.2 B key 2242 (USB, SATA)
Digital I/O 1 x 8-bit DIO (2x5 pin, P=2.0)
Watchdog Timer Software programmable support 1~255 sec. system reset
Power Supply 12V DC input only (DC jack)
Support AT/ATX mode
Power Consumption 12V@2.36A (Intel® Celeron® N3350 with 8GB 1600MHz DDR3L memory)
Operating Temperature -20°C ~ 60°C
Storage Temperature -10°C ~ 70°C
Operating Humidity 5% ~ 95%, non-condensing
Dimensions 100mm x 72mm
Weight GW: 600g / NW: 250g
CE/FCC compliant

Ordering Information
Part No. Description
HYPER-AL-N1-R10 PICO-ITX SBC supports Intel® 14nm dual-core Celeron® N3350 2.4GHz on-board SoC with HDMI, LVDS, dual LAN, M.2, USB 3.0, SATA 6GB/s, COM and RoHS
34000-000706-RS Optional fanless heatsink module, 100mm x 72mm x 20.5mm
32001-008600-200-RS Dual port USB cable, 210mm, P=2.0
AC-KIT-892HD-R10 Realtek ALC892 7.1 Channel HD Audio peripheral board, RoHS

Packing List
1 x HYPER-AL single board computer (heat spreader by default) 1 x SATA cable kit
1 x COM port cable 1 x QIG (Quick Installation Guide)
