IEI Launches HYPER-RK39 Pico-ITX SBC supports Rockchip RK3399 Processor
IEI Product News

HYPER-RK39-pico-itx-sbc

Features Specifications Dimensions
Ordering Information Packing List Options
Features
HYPER-RK39-IO
HYPER-RK39-SBC-features
Pico-ITX SBC supports Rockchip RK3399
HDMI and eDP dual display support
OS: Android 7.1 & Ubuntu 16.04
HYPER-RK39-SBC-application

Specifications
Model HYPER-RK39
Chassis Dimensions (WxHxD) (mm) Single board: 100mm x 72mm
Motherboard CPU Rockchip RK3399 (Dual-core Cortex-A72 up to 1.8GHz + Quad-core Cortex-A53 up to 1.5GHz)
System Memory 2GB LPDDR3-1866
Storage SD Card 1 x Micro SD slot
Flash 16GB eMMC NAND FLASH
Communication WLAN 802.11 a/b/g/n/ac
Bluetooth Bluetooth V4.1
WWAN PCIe Mini LTE (optional)
I/O Interfaces COM port 1 x RS-232/422/485
GPIO 8 bit (4 in / 4 out)
Ethernet 1 x GbE RJ45 by RTL8211E
USB 3.0 1 x USB 3.0 Type A
1 x USB 3.0 Type-C (for OS update)
USB 2.0 1 x USB 2.0 Type A
Display 1 x HDMI out
1 x eDP port
Others 1 x I²C
Expansions PCIe Mini 1 x Full-size PCIe Mini (reserved for WWAN)
Multimedia Audio 1 x 2 pin for speaker (2W)
1 x 10 pin (Line in / Line out)
Camera 1 x MIPI CSI interfaces for Camera
Power Power Input 1 x 2 pin DC 12V in wafer connector
Reliability Operating Temperature -10°C ~ 50°C with air flow
Storage Temperature -20°C ~ 60°C
Humidity 10% ~ 95%, non-condensing
Weight (Net) 80 g
Safety/EMC CE/FCC compliant
OS Supported OS Android 7.1 or Linux Ubuntu 16.04
Watchdog Timer Yes

Dimensions
HYPER-RK39-SBC-Dimension

Ordering Information
Part No. Description
HYPER-RK39-R10 PICO-ITX SBC with Rockchip 3399 Processor, 2GB LPDDR3 , 16GB eMMC Flash, Android 7.1, HDMI, eDP, GbE LAN, PCIe mini, USB3.0, USB2.0, COM, RoHS
HYPER-RK39-R10-TW PICO-ITX SBC with Rockchip 3399 Processor, 2GB LPDDR3 , 16GB eMMC Flash, Android 7.1, HDMI, eDP, GbE LAN, PCIe mini, USB3.0, USB2.0, COM, Wi-Fi TW reg, ROHS
HYPER-RK39-R10-US PICO-ITX SBC with Rockchip 3399 Processor, 2GB LPDDR3 , 16GB eMMC Flash, Android 7.1, HDMI, eDP, GbE LAN, PCIe mini, USB3.0, USB2.0, COM, Wi-Fi US reg, ROHS
HYPER-RK39-R10-EU PICO-ITX SBC with Rockchip 3399 Processor, 2GB LPDDR3 , 16GB eMMC Flash, Android 7.1, HDMI, eDP, GbE LAN, PCIe mini, USB3.0, USB2.0, COM, Wi-Fi EU reg, ROHS
HYPER-RK39-CN-R10-CN PICO-ITX SBC with Rockchip 3399 Processor, 2GB LPDDR3 , 16GB eMMC Flash, Android 7.1, HDMI, eDP, GbE LAN, PCIe mini, USB3.0, USB2.0, COM, Wi-Fi CN reg, ROHS
HYPER-RK39-R10-U-TW PICO-ITX SBC with Rockchip 3399 Processor, 2GB LPDDR3 , 16GB eMMC Flash, Ubuntu 16.04, HDMI, eDP, GbE LAN, PCIe mini, USB3.0, USB2.0, COM, Wi-Fi TW reg, ROHS
HYPER-RK39-R10-U-US PICO-ITX SBC with Rockchip 3399 Processor, 2GB LPDDR3 , 16GB eMMC Flash, Ubuntu 16.04, HDMI, eDP, GbE LAN, PCIe mini, USB3.0, USB2.0, COM, Wi-Fi US reg, ROHS
HYPER-RK39-R10-U-EU PICO-ITX SBC with Rockchip 3399 Processor, 2GB LPDDR3 , 16GB eMMC Flash, Ubuntu 16.04, HDMI, eDP, GbE LAN, PCIe mini, USB3.0, USB2.0, COM, Wi-Fi EU reg, ROHS
HYPER-RK39-R10-U-CN PICO-ITX SBC with Rockchip 3399 Processor, 2GB LPDDR3 , 16GB eMMC Flash, Ubuntu 16.04, HDMI, eDP, GbE LAN, PCIe mini, USB3.0, USB2.0, COM, Wi-Fi CN reg, ROHS
HYPER-RK39-R10-U PICO-ITX SBC with Rockchip 3399 Processor, 2GB LPDDR3 , 16GB eMMC Flash, Ubuntu 16.04, HDMI, eDP, GbE LAN, PCIe mini, USB3.0, USB2.0, COM, RoHS

Packing List
1 x Hyper-RK single board 1 x Heatsink set
1 x Two pin to DC in power cable 1 x RTC battery

Options
Item Part No. Description
Power Adapter 63040-010060-120-RS Vin:90~264VAC;60W;Φ2.5/Φ5.5/lock
GPIO Cable 32133-030000-100-RS FEMALE 2*5P P=1.0*2;(B)PIN HEADER 2*5P P=2.54*2
Audio Cable 32107-005200-100-RS Audio Jack:Ø3.5,6P
Power Switch Cable 19S00-015600-100-RS ROCKER SWITCH:250V/6A,2P,ON/OFF
ePD Cable 32602-030700-100-RS CABLE;;2;300MM;34AWG;(A)I-PEX:20454-240T P=0.5+PULL BAR*2
ePD Panel 23000-01160PS01-RS LCD-TFT;11.6";Panasonic;1920*1080;280cd/ ㎡ ;LED;;VVX12F045J00;eDP 8BIT;;RoHS
Speaker 19800-025000-100-RS SPEAKER+CABLE MODULE;;;2;300MM;28AWG;(A)Speaker:26.6*15.6*9.0MM,8Ω,1.5W
IPEX to SMA cable 32501-000705-100-RS RF CABLE FOR DVBT;LINE DIAMETER:1.37mm;213MM;50Ω;Exceltek;0-6GHz
Wi-Fi Antenna 32505-004800-100-RS WLAN;2.4G+5G WI-FI ANTENNA
Camera module 7I001-COC794A5SFE-RS Image Module; 2592*1944
LTE Antenna 32505-004200-100-RS WLAN;LTE FULL BAND ANTENNA
* Use LTE module need to add a SIM card slot board.
