IEI 推出全新 tKINO-ULT3 Mini ITX Skylake 主板




tKINO-ULT3

特征 规格 订购信息 包装清单

   特征


tKINO-ULT3

tKINO-ULT3 Application
Mini ITX form fator 采用 Intel® Skylake-U 处理器,支持 DDR4-2133 内存
宽量程 9~36V 直流输入
支持双 HDMI (1 个 HDMI/DP combo ),LVDS/eDP
Intel® GbE LAN 支持 Intel® AMT 11.0
支持 SATA 6Gb/s、mSATA 和 eMMC 5.0 (可选)
高速 I/O 适用于 USB 3.0、PCIe x4、全长 PCIe mini
Top

   规格


型号 tKINO-ULT3
CPU 6th generation Intel® mobile ULT on-board processor
Intel® Core™ i7-6600U (up to 3.4GHz, dual-core, 4M Cache, TDP=15W)
Intel® Core™ i5-6300U (up to 3.0GHz, dual-core, 3M Cache, TDP=15W)
Intel® Core™ i3-6100U (up to 2.3GHz, dual-core, 3M Cache, TDP=15W)
Intel® Celeron® 3955U (up to 2.0GHz, dual-core, 2M Cache, TDP=15W)
Intel® Celeron® 3855U (up to 1.6GHz, dual-core, 2M Cache, TDP=15W)
BIOS AMI UEFI BIOS
内存 2 x SO-DIMM DDR4 2133MHz, system maximun up to 32GB
图像引擎 Intel® HD graphic
显示输出 1 x HDMI 1.4 (up to 4096x2160@24Hz)
1 x HDMI/DP (up to 4096x2160@24Hz)
1 x LVDS/eDP (select by switch)
Ethernet LAN1: Intel® I219 (with Intel® AMT11.0 support)
LAN2: Intel® I211 PCIe controller with NCSI support
外部 I/O 接口 4 x USB 3.0
内部 I/O 接口
1 x eMMC 5.0 (optional, up to 32G) 4 x RS-232 (2x5 pin, P=2.0)
2 x RS-232/422/485 (2x5 pin, P=2.0) 4 x USB 2.0 (2x4 pin, P=2.0)
2 x SATA with 5V output
音频 Realtek ALC662 HD Audio Codec support 5.1 Channel
2 x Audio jacks (line-out, mic-in) on rear IO
1 x Front audio (2x5-pin)
前面板 1 x Front panel (2x7 pin, power LED, HDD LED,power button, reset button)
LAN LED 2 x LAN LED(1x2 pin)
SMBus 1 x SMBus (1x4 pin)
I²C 1 x I²C (1x4 pin)
数字 I/O 8-bit digital I/O (2x5 pin)
扩展 1 x PCIe x4 slot
1 x Full-size PCIe Mini card slot (support mSATA, colay SATA2)
1 x Full-size PCIe Mini card slot (with SIM holder)
*3855U belongs to Skylake ULT Base series CPU, PCIe signal support only PCIe Gen 2
看门狗定时器 Software programmable support 1~255 sec. system reset by Super I/O
机箱材质 1 x Chassis intrusion connector (1x2 pin)
风扇连接器 1 x CPU smart fan (1x4 pin)
1 x System fan (1x3 pin)
电源 9~36V DC input
1 x Internal power connector (2x2 pin)
1 x External DC power Jackc (Ø5.5mm)
Support AT/ATX mode
功耗 12V@4.68A (Intel® Core™ i7-6600U up to3.4GHz CPU with 16GB(8GB x 2) DDR4-2133 memory running in 3.2GHz)
工作温度 -20°C ~ 60°C
工作湿度 5% ~ 95%, non-condensing
尺寸 170mm x 170 mm
重量 GW: 900g / NW: 375g
Top

   订购信息


料号 描述
tKINO-ULT3-i7-R10 Thin Mini-ITX SBC supports Intel® 6th Generation Mobile Core™ i7-6600U (15W) on-board Processor (ULT), 9~36V DC input, Dual HDMI, LVDS, eDP, SATA 6 Gb/s, Dual Intel® GbE, USB 3.0, Mini PCIe, eMMC 5.0, HD audio and RoHS
tKINO-ULT3-i5-R10 Thin Mini-ITX SBC supports Intel® 6th Generation Mobile Core™ i5-6300U (15W) on-board processor (ULT), 9~36V DC input, Dual HDMI, LVDS, eDP,SATA 6 Gb/s, Dual Intel® GbE, USB 3.0, Mini PCIe, eMMC 5.0, HD audio and RoHS
tKINO-ULT3-i3-R10 Thin Mini-ITX SBC supports Intel® 6th Generation Mobile Core™ i3-6100U (15W) on-board processor (ULT), 9~36V DC input, Dual HDMI, LVDS, eDP, SATA 6 Gb/s, Dual Intel® GbE, USB 3.0, Mini PCIe, eMMC 5.0, HD audio and RoHS
tKINO-ULT3-C-R10 Thin Mini-ITX SBC supports Intel® 6th Generation Mobile Celeron® 3955U (15W) on-board processor (ULT), 9~36V DC input, Dual HDMI, LVDS, eDP, SATA 6 Gb/s, Dual Intel® GbE, USB 3.0, Mini PCIe, eMMC 5.0, HD audio and RoHS
tKINO-ULT3-CE-R10 Thin Mini-ITX SBC supports Intel® 6th Generation Mobile Celeron® 3855U (15W) on-board processor (ULT), 9~36V DC input, Dual HDMI, LVDS, eDP, SATA 6 Gb/s, Dual Intel® GbE, USB 3.0, Mini PCIe, eMMC 5.0, HD audio and RoHS
32205-002700-100-RS RS-232 cable, 200mm, P=2.0
32205-003700-100-RS RS-232/422/485 cable, 230mm, P=2.0
34000-000645-RS Fanless heatsink module, 93.5 x 84 x 30mm
Top

   包装清单


1 x tKINO-ULT3 single board computer with CPU cooler 1 x One Key Recovery CD
2 x SATA cable 1 x QIG
1 x I/O shielding 1 x Utility CD
Top
